Side 1/65

Version date: 08.06.18

FR Défonceuse plongeante 1 020 W

DE Oberfräse, 1020 W

ES Fresadora 1020 W

IT Fresatrice a immersione 1020 W

NL 1020 W bovenfreesmachine

PL Frezarka górnowrzwecionowa 1020 W

DIY 1020W Plunge Router 8mm & 1⁄4"

silverlinetools.com

329863

26 27

21 22

silverlinetools.com 3

A B C

D E

I II III

IV V

VII VIII

silverlinetools.com 5

English 06 ................

Français 14 ...............

Deutsch 22 ................

Español 30 ................

Italiano 38 ................

Nederlands 46 ..........

Polski 54 ..................

Technical Abbreviations Key

WARNING: Always wear ear protection where the sound level exceeds 85dB(A) and limit the time

of exposure if necessary. If sound levels are uncomfortable, even with ear protection, stop using the

tool immediately and check the ear protection is correctly tted and provides the correct level of

sound attenuation for the level of sound produced by your tool.

WARNING: User exposure to tool vibration can result in loss of sense of touch, numbness, tingling

and reduced ability to grip. Long-term exposure can lead to a chronic condition. If necessary, limit

the length of time exposed to vibration and use anti-vibration gloves. Do not operate the tool with

hands below a normal comfortable temperature, as vibration will have a greater effect. Use the

gures provided in the specication relating to vibration to calculate the duration and frequency

of operating the tool.

Sound and vibration levels in the specication are determined according to EN60745 or similar

international standards. The gures represent normal use for the tool in normal working conditions.

A poorly maintained, incorrectly assembled, or misused tool, may produce increased levels of noise

and vibration. www.osha.europa.eu provides information on sound and vibration levels in the

workplace that may be useful to domestic users who use tools for long periods of time.

VVolts , DC Direct current

~, AC Alternating current W, kW Watt, kilowatt

A, mA /min or minAmpere, milli-Amp -1 Operations per minute

n0No load speed rpm Revolutions per minute

° dB(A)Degrees Decibel sound level (A weighted)

ØDiameter

m/s2Metres per second squared

(vibration magnitude)

Hz Hertz

Introduction

Thank you for purchasing this Silverline tool. This manual contains information necessary

for safe and effective operation of this product. This product has unique features and, even if

you are familiar with similar products, it is necessary to read this manual carefully to ensure

you fully understand the instructions. Ensure all users of the tool read and fully understand

this manual.

Original Instructions

Voltage: . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 230-240V~ 50Hz

Power: . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1020W

No load speed: . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11,500-34,000min

-1

Max cutting depth: 36mm. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Max router cutter diameter: Ø32mm . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Plunge stroke: 0-40mm . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Turret stop: 3 position with adjustable heights . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Max Collet size: 8mm . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Base shape:. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Combined circular & at

Guide Bush: Ø16mm (internal), Ø18mm (external) . . . . . . . . . . . . . . . . . . . . . . . .

Dust extraction connector:. . . . . . . . . . . . . . Ø34mm (internal), Ø40mm (external)

Duty Cycle: S1 (continuous operation) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Ingress protection: . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .IP20

Protection class: . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Power cord length: 2.5m . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Dimensions (L x W x H): 250 x 110 x 250mm. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Weight: . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2.9kg

As part of our ongoing product development, specications of

Silverline products may alter without notice.

Sound and vibration information:

Sound pressure LPA

: . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .92dB(A)

Sound power L

WA : 103dB(A) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Uncertainty K: . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3dB(A)

Weighted vibration a

h:. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5.59m/s

Uncertainty K: . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1.5m/s

The sound intensity level for the operator may exceed 85dB(A)

and sound protection measures are necessary.

Specication

Description of Symbols

The rating plate on your tool may show symbols. These represent important information about the

product or instructions on its use.

Wear hearing protection.

Wear eye protection.

Wear breathing protection.

Wear head protection.

Wear hand protection.

Read instruction manual.

Caution!

Always disconnect from the power supply when adjusting, changing accessories,

cleaning, carrying out maintenance and when not in use!

Toxic fumes or gases!

Warning: Sharp blades or teeth!

WARNING: Moving parts can cause crush and cut injuries

Class II construction (double insulated for additional protection)

Environmental Protection

Waste electrical products should not be disposed of with household waste.

Please recycle where facilities exist. Check with your local authority or retailer

for recycling advice.

Conforms to relevant legislation and safety standards.

1020W Plunge Router329863

silverlinetools.com

General Safety

WARNING Read all safety warnings and all instructions. Failure to follow the warnings and

instructions may result in electric shock, re and/or serious injury.

WARNING: This appliance is not intended for use by persons (including children) with

reduced, physical or mental capabilities or lack of experience or knowledge unless they

have been given supervision or instruction concerning use of the appliance by a person

responsible for their safety. Children must be supervised to ensure that they do not play with

the appliance.

Save all warnings and instructions for future reference.

The term “power tool” in the warnings refers to your mains-operated (corded) power tool or battery-

operated (cordless) power tool.

1) Work area safety

a) Keep work area clean and well lit. Cluttered or dark areas invite accidents.

b) Do not operate power tools in explosive atmospheres, such as in the presence of

ammable liquids, gases or dust. Power tools create sparks which may ignite the dust

or fumes.

c) Keep children and bystanders away while operating a power tool. Distractions can cause

you to lose control.

2) Electrical safety

a) Power tool plugs must match the outlet. Never modify the plug in any way. Do not use

any adapter plugs with earthed (grounded) power tools. Unmodied plugs and matching

outlets will reduce risk of electric shock.

b) Avoid body contact with earthed or grounded surfaces, such as pipes, radiators, ranges

and refrigerators. There is an increased risk of electric shock if your body is earthed or grounded.

c) Do not expose power tools to rain or wet conditions. Water entering a power tool will increase

the risk of electric shock.

d) Do not abuse the cord. Never use the cord for carrying, pulling or unplugging the

power tool. Keep cord away from heat, oil, sharp edges or moving parts. Damaged or entangled

cords increase the risk of electric shock.

e) When operating a power tool outdoors, use an extension cord suitable for outdoor use.

Use of a cord suitable for outdoor use reduces the risk of electric shock.

f) If operating a power tool in a damp location is unavoidable, use a residual current device

(RCD) protected supply. Use of an RCD reduces the risk of electric shock.

3) Personal safety

a) Stay alert, watch what you are doing and use common sense when operating a power

tool. Do not use a power tool while you are tired or under the inuence of drugs, alcohol

or medication. A moment of inattention while operating power tools may result in serious

personal injury.

b) Use personal protective equipment. Always wear eye protection. Protective equipment

such as dust mask, non-skid safety shoes, hard hat, or hearing protection used for appropriate

conditions will reduce personal injuries.

c) Prevent unintentional starting. Ensure the switch is in the off-position before connecting

to power source and/or battery pack, picking up or carrying the tool. Carrying power tools

with your nger on the switch or energising power tools that have the switch on invites accidents.

d) Remove any adjusting key or wrench before turning the power tool on. A wrench or a key

left attached to a rotating part of the power tool may result in personal injury.

e) Do not overreach. Keep proper footing and balance at all times. This enables better control

of the power tool in unexpected situations.

f) Dress properly. Do not wear loose clothing or jewellery. Keep your hair, clothing and gloves

away from moving parts. Loose clothes, jewellery or long hair can be caught in moving parts.

g) If devices are provided for the connection of dust extraction and collection facilities,

ensure these are connected and properly used. Use of dust collection can reduce

dust-related hazards.

4) Power tool use and care

a) Do not force the power tool. Use the correct power tool for your application. The correct

power tool will do the job better and safer at the rate for which it was designed.

b) Do not use the power tool if the switch does not turn it on and off. Any power tool that

cannot be controlled with the switch is dangerous and must be repaired.

c) Disconnect the plug from the power source and/or the battery pack from the power tool

before making any adjustments, changing accessories, or storing power tools. Such

preventive safety measures reduce the risk of starting the power tool accidentally.

d) Store idle power tools out of the reach of children and do not allow persons unfamiliar

with the power tool or these instructions to operate the power tool. Power tools are

dangerous in the hands of untrained users.

e) Maintain power tools. Check for misalignment or binding of moving parts, breakage of

parts and any other condition that may affect the power tool’s operation. If damaged,

have the power tool repaired before use. Many accidents are caused by poorly maintained

power tools.

f) Keep cutting tools sharp and clean. Properly maintained cutting tools with sharp cutting edges

are less likely to bind and are easier to control.

g) Use the power tool, accessories and tool bits etc. in accordance with these instructions,

taking into account the working conditions and the work to be performed. Use of the power

tool for operations different from those intended could result in a hazardous situation.

5) Service

a) Have your power tool serviced by a qualied repair person using only identical

replacement parts. This will ensure that the safety of the power tool is maintained.

Router Safety

• Hold the power tool by insulated gripping surfaces only, because the cutter may contact

its own cord. Cutting a "live" wire may make exposed metal parts of the power tool "live" and

could give the operator an electric shock.

• Use clamps or another practical way to secure and support the workpiece to a stable

platform. Holding the work by your hand or against the body leaves it unstable and may lead to

loss of control.

• If the replacement of the supply cord is necessary, this has to be done by the

manufacturer or his agent in order to avoid a safety hazard.

• It is strongly recommended that the tool always be supplied via a residual current device

with a rated residual current of 30 mA or less.

a) Use safety equipment including safety goggles or shield, ear protection, dust mask and

protective clothing including safety gloves

b) Cloths, cord, string etc should never be left around the work area

c) Ensure the mains supply voltage is the same as the tool rating plate voltage

d) Ensure any cable extensions used with this tool are in a safe electrical condition, and have

the correct ampere rating for the tool

e) Completely unwind cable drum extensions to avoid potential overheating

f) Use appropriate detectors to determine if utility cables or pipes are below the surface of

the work area. Consult utility companies for assistance if necessary. Contact with electric cables

can lead to electric shock and re. Damaging a gas pipe can lead to explosion. Contact with water

lines can lead to major property damage

g) Ensure embedded objects such as nails and screws have been removed from the

workpiece before commencing operation

h) Handle router bits with care as they can be extremely sharp

i) Before use, check the bit carefully for signs of damage or cracks. Replace damaged or

cracked bits immediately

j) Ensure router cutters/bits are sharp and maintained correctly. Dull cutting edges can lead to

uncontrolled situations including stalling, increased heat and possible injury

k) ALWAYS use both handles and maintain a rm grip on the router before proceeding with

any work

l) Keep handles and gripping surfaces dry, clean and free of oil and grease to ensure the

tool can be securely held in use

m) Before using the tool to make a cut, switch on and let it run for a while. Vibration could

indicate an improperly installed bit

n) Take notice of the direction of rotation of the bit and the direction of feed

o) Keep your hands away from the routing area and router bit cutter. Hold the auxiliary handle

or an insulated gripping surface with your second hand

p) NEVER start the router while the cutter is touching the workpiece

q) Ensure the plunge spring is always tted when using hand-held

r) Ensure the cutter has completely stopped before plunging to the collet lock position

s) The maximum speed of the router bit/cutter must be at least as high as the maximum

speed of the power tool

t) Parts of the router bits may become hot during operation. Do not handle immediately after

use to avoid risk of burns

u) Do not allow parts to come into contact with combustible materials

v) The shank size of the router cutter/bit must be matched to the exact same size collet

tted to the router. Incorrectly tted router cutter/bits will rotate irregularly and have increased

vibration that could lead to loss of control

w) DO NOT press the spindle lock button, or attempt to switch the tool into bit change mode

while the router is operating

x) Keep pressure constant while cutting into the workpiece, allowing the router bit cutter to

dictate the speed of cut. DO NOT force the tool and overload the motor

y) Ensure rating labels and safety warnings on the tool remain clear to read and are replaced

if marked or damaged

z) When operating the router, be prepared for the router bit cutter stalling in the workpiece

and causing loss of control. Always ensure the router is rmly held and the on/off switch is

immediately released in such circumstances

• After switching on the router, check the router bit is rotating evenly (not ‘wobbling’) and

there is no additional vibration due to the router bit being incorrectly tted. Operating the

router with an incorrectly tted router bit can lead to loss of control and severe injury

• EXTREME care must be taken when using cutters with a diameter greater than 2" (50mm).

Use very slow feed rates and/or multiple shallow cuts to avoid overloading the motor

• ALWAYS switch off and wait until the bit has come to a complete standstill before

removing the machine from the workpiece

• Disconnect from the power supply before carrying out any adjustment, servicing or

maintenance

Produkt Specifikationer

Mærke:	Silverline
Kategori:	Router
Model:	329863

Har du brug for hjælp?

Hvis du har brug for hjælp til Silverline 329863 stil et spørgsmål nedenfor, og andre brugere vil svare dig

Dit navn*

Din email*

Skriv dit spørgsmål her

Router Silverline Manualer

Silverline 128999 Manual

4 August 2024

Silverline 124799 Manual

2 August 2024

Silverline 264895 Manual

20 Juli 2024

Silverline 329863 Manual

26 Februar 2023

Router Manualer

Nyeste Router Manualer

Eero Pro 7 Manual

8 April 2025

WyreStorm EXP-SW-0401-H2 Manual

22 Marts 2025

TP-Link Archer BE550 Pro Manual

9 Marts 2025

Devolo WiFi 6 Router 3600 5G LTE Manual

6 Marts 2025

Huawei E5785-320 Manual

23 Februar 2025

Huawei E5785-330 Manual

23 Februar 2025

Xiaomi Router AX3000T Manual

22 Februar 2025

Huawei E5180 Manual

20 Februar 2025

Digital Forecast Bridge RS 16*16 Manual

20 Februar 2025

Teltonika RUTM52 Manual

12 Februar 2025
