GERMANY

MODE

PSI

BAR

SCHRADER/AUTO SCLAVERAND/PRESTA

MANUAL AIRCHECKER 10001¬ ¬

ALLROAD ROAD MOUNTAIN

1. Putting into Operation/Battery Change

1.1 Lift/open the battery compartment using a narrow and at screwdriver.

1.2 Use a narrow and at screwdriver to release and remove the battery from the battery compartment.

1.3 Remove and dispose of the protective foil.

1.4 Insert the battery with the »+« pole facing upward.

1.5 Close the battery compartment again.

2. Measuring the Air Pressure:

2.1 Switch the device on by pressing the button (acoustic signal).

2.2 Briey press the button and select BAR or PSI (acoustic signal)

2.3 Remove the valve cap (also open the valve head if using the SV)

2.4 Set the AIRCHECKER duohead to SV or AV (turn it 90° to the L or R) (Image)

2.5 Place the AIRCHECKER duohead on fast and make the measurement. A successful measurement is conrmed by an acoustic signal and the measured

value is permanently displayed.

3. Pressure Release Function with Realtime Measuring:

3.1 Press the button to switch on.

3.2 Press the button and select BAR or PSI (acoustic signal).

3.3 Remove the valve cap (also open the valve head if using the SV)

3.4 Set the AIRCHECKER duohead to SV or AV (turn it 90° to the L or R) (Image)

3.5 Place the AIRCHECKER duohead on fast and make the measurement.

3.6 To carry out a permanent realtime measurement, press the MODE button (the display ashes)

3.7 Release pressure in a controlled manner by using the DEFLATE button. The reduced pressure is measured automatically and is displayed… (the display ashes).

3.8 A pressing of the MODE button freezes the value that was measured last.

Switching off:

1. Press the BAR/PSI button for 3 sec.

2. Or AutoOff after approx. 30 sec.

Pressure

real-time

measurements

Display

PSI/BAR

Control elements

deate

Push
