Side 1/51

© 2020 by Snow Joe
®, LLC
All rights reserved. Original instructions. SAVE THESE INSTRUCTIONS
1
EN
A Division of Snow Joe
® , LLC Model SJ626E Form No. SJ-SJ626E-880E-MR2
OPERATOR’S MANUAL
ELECTRIC SNOW THROWER
22-INCH | 14.5-AMP
R
IMPORTANT!
Safety Instructions
All Operators Must Read These
Instructions Before Use
Any electrical appliance can be dangerous if used incorrectly.
Some of the safety precautions given in this manual apply
generally to many appliances. Other warnings are specic
to the use of this snow thrower. Keep this manual for future
reference.
General Safety WARNINGS!
You and any other operator of this snow thrower must read,
understand, and follow these instructions in their entirety, and
should reread them at the start of each snow season.
Failure to follow these instructions may result in ELECTRIC
SHOCK, FIRE, and/or serious PERSONAL INJURY.
Notice the personal safety alert symbol m used in this
manual to draw your attention to a WARNING given along
with the particular operating instruction. This means that
the operation requires special ATTENTION, CAUTION,
and AWARENESS.
1. Keep work area clean and well lit. Cluttered, dark areas
invite accidents.
2. Do not operate the snow thrower in an explosive
atmosphere, such as in the presence of ammable
liquids, gases, or dust. Electrical appliances create sparks
that may ignite the dust or fumes.
3. Keep children, pets, and bystanders away from the
work area. Be aware that the normal noise of the
machine when turned on may make it dicult for you to
hear approaching people. Spectators should wear safety
glasses and be kept a safe distance away from the work
area. Do not let spectators touch the snow thrower or the
extension cord.
4. Electrical plugs must match the outlet. Never modify
the plug in any way. Do not use any adapter plugs with
grounded appliances. Unmodied plugs and matching
outlets will reduce the risk of electric shock.
5. Avoid body contact with earthed or grounded surfaces
(i.e. upper and lower water pipes, radiators, ranges,
refrigerators, microwave ovens, and outer frames of
heating equipment). Take necessary precautions to avoid
electric shock. There is an increased risk of electric shock
if your body is earthed or grounded.
6. Do not abuse the cord. Keep the cord away from heat,
oil, sharp edges, or moving parts. Never carry the snow
thrower by its cord or yank the cord to disconnect it from
the electrical outlet. Damaged or entangled cords increase
the risk of electric shock.
7. Replace or properly repair damaged cords. If the cord
becomes damaged in any manner while plugged into the
wall receptacle, immediately pull the extension cord plug
from the receptacle.
8. Contact with water while operating the snow thrower
can result in electric shock and serious bodily injury.
Do not use the snow thrower in damp or wet locations or
expose to rain. Do not handle the plug or the appliance
with wet hands or while standing in water.
9. mWARNING – Use outdoor extension cords marked
SW-A, SOW-A, STW-A, STOW-A, SJW-A, SJOW-A,
SJTW-A, or SJTOW-A. These cords are rated for outdoor
use and reduce the risk of electric shock.
10. Turnothepowerswitchanddisconnectthepower
cable before making any adjustments to the unit and
before inspecting, servicing, changing accessories, or
cleaning the snow thrower. Follow the same procedure
if any other dangerous conditions are present during
operation. Any adjustments to the unit should be
performed after revolving parts inside the snow thrower
stop completely. Such preventative safety measures
reduce the risk of starting the power tool accidentally.
11. Ifyoundthemainpowercableortheextensioncable
damaged, please pull out the plug from the socket and
disconnect the power immediately. Repair the cable or
replace it if necessary.
12. When replacing any parts, you must strictly observe
the instructions and procedures described in this
operator's manual. Special care should be paid to any
rubber parts, since these parts may increase the engine
load and decrease its mechanical power if damaged.
13. Do not move or transport the snow thrower when the
plug is connected to the power socket and the switch
is turned on.

2
14. If, during use, you notice that the unit runs unstably
or hear abnormal sounds from the motor, stop the
machine, disconnect the power immediately and
contact an authorized Snow Joe® + Sun Joe®
service center.
Electrical Safety
1. Ground fault circuit interrupter (GFCI) protection should
be provided on the circuit(s) or outlet(s) to be used for the
snow thrower. Receptacles are available having built-in
GFCI protection and may be used for this measure of
safety.
2. To prevent electric shock, use only with an extension cord
suitable for outdoor use, such as SW-A, SOW-A, STW-A,
STOW-A, SJW-A, SJOW-A, SJTW-A, or SJTOW-A.
Before use, check that the extension cord is in good
condition. When using an extension cord, make sure to
use one heavy enough to carry the current your product
will draw. An undersized cord will cause a drop in line
voltage resulting in loss of power and overheating.
3. To reduce the risk of electric shock, this appliance has
a polarized plug (i.e. one blade is wider than the other).
Use this appliance only with a polarized UL-, CSA-,
or ETL-rated extension cord for outdoor, all-weather use.
The appliance plug will t into a polarized extension
cord only one way.
If the appliance plug does not t fully into the extension
cord, reverse the plug. If the plug still does not t, obtain
a correct polarized extension cord. A polarized extension
cord will require the use of a polarized wall outlet.
The extension cord plug will t into the polarized wall
outlet only one way. If the plug does not t fully into the
wall outlet, reverse the plug. If the plug still does not t,
contact a qualied electrician to install the proper wall
outlet. Do not modify the appliance plug, extension cord
receptacle, or extension cord plug in any way.
4. To prevent the appliance cord from disconnecting from the
extension cord during operation, use the on-board cord
restraint hook and/or make a knot with the two cords as
shown in Table 1.
Extension Cord
Length
Wire Gauge (A.W.G.):
Up to 50 ft
(15 m)
+50 ft - 100 ft
(+15 m - 30 m)
14 12
m WARNING m
Electric shock may cause SEVERE INJURY or
DEATH. Heed these warnings:
• Do not allow any part of the electric snow thrower to
make contact with water while it is in operation. If the
appliance becomes wet while turned o, wipe dry
before starting.
• Use only a UL-, CSA- or ETL-rated extension cord
for outdoor, all-weather use, such as the Snow Joe®+
Sun Joe® SJTW-A 14-gauge 50-foot extension cord
with lighted end (Model PJEXT50-B). Visit
snowjoe.com to purchase this extension cord online
or, to order by phone, call 1-866-SNOWJOE
(1-866-766-9563).
• Do not use an extension cord over 100 ft (30 m).
• Do not touch the appliance or its plug with wet hands
or while standing in water. Wearing rubber boots
oers some protection.
EXTENSION CORD CHART
(B) Connect plug and receptacle
Cord set Appliance
cord
(A) Tie cord as shown
Table 1. Method of Securing Extension Cord

3
5. Do not abuse the cord. Never pull the snow thrower by the
cord or yank the cord to disconnect it from the receptacle.
Keep the cord away from heat, oil, and sharp edges.
Personal Safety
1. Stay alert – Watch what you are doing and use common
sense when operating the snow thrower. Do not use the
machine when tired, ill, or under the inuence of drugs,
alcohol, or medication. A moment of inattention may result
in serious personal injury.
2. Wear proper clothing – Wearing rubber boots oers
additional protection from electric shock. Do not wear
loose clothing or jewelry that may become caught in the
machine. Wear protective headgear to keep hair away
from revolving parts of the machine. Safety glasses oer
better protection than everyday eyeglasses.
3. Moving parts present risks – Keep your face, hair,
clothing, hands, and feet away from moving parts.
All guards and safety attachments must be installed
properly before using the unit. Shut o and disconnect the
cord before touching any parts other than the handles and
the switch.
4. Surfaces – This snow thrower is intended for use on
paved surfaces. Do not use on gravel, stone, or other
unpaved surfaces unless the snow thrower is adjusted for
such surfaces according to the instructions given in this
operator’s manual.
5. Avoid accidental starting – Make sure the switch is in the
o position before plugging in the unit. Do not carry the
snow thrower with your nger on the switch.
6. Body position – Maintain proper footing and balance
at all times. Place heels rmly on the ground and tightly
grasp the handle bar. Watch for uneven surfaces and do
not overreach. In case you fall or collide with the snow
thrower, inspect the unit for any damage or cracks.
When stepping backwards, be careful to avoid obstacles
beneath your feet or behind you to avoid falling.
7. If the snow thrower strikes any object, immediately
stop the snow thrower, then inspect for damage –
Repair any damage before restarting and operating the
snow thrower.
Safety Instructions for Walk-Behind
Snow Throwers
• Readtheoperator’smanualcarefully–Learn your
snow thrower’s applications and limitations as well as the
specic potential hazards related to this machine. Do not
use this machine for any purpose other than the one for
which it was designed. Otherwise, it may cause mechanical
defaults, serious damage, or personal injury.
• Preliminaryunitinspection–Thoroughly inspect the unit
before use. Make sure all the parts are secure and installed
correctly. If you notice any abnormalities, do not use the
machine until it has been properly repaired.
Always perform a test run the rst time you use the snow
thrower or after replacing parts to ensure that the unit is
functioning properly.
• Preliminaryareainspection–Clear the area to be plowed
before each use. Remove all objects, such as rocks, broken
glass, nails, wire, or string, which can be thrown by or
become entangled in the snow thrower. Keep the area of
operation clear of all spectators, particularly children
and pets.
• Excessiveforce–The snow thrower was designed to
respond at a certain rate for various snow conditions for
optimum safety and performance. Do not force it; keep
pressure constant.
• Malfunctioningswitch–Do not use the snow thrower
if the switch does not turn it on and o. Any electrical
appliance that cannot be controlled by the switch is not
safe to use and must be repaired.
• Hittinganobject–If the snow thrower accidentally strikes
an object, follow these steps:
i) Stop the snow thrower and unplug the unit
ii) Inspect for damage
iii) Repair or replace any damaged part before restarting
and operating the snow thrower.
• Discharge chute safety – Never direct the snow discharge
chute at the operator, at bystanders, at vehicles, or at
windows. The discharged snow stream and foreign objects
accidentally picked up by the snow thrower can cause
serious damage and personal injury. Do not use your hands
to unclog the discharge chute. Stop the motor before
removing debris.
• Hand-heldoperatingposition–Operation of the snow
thrower in the hand-held position is unsafe.
• Abnormaloperation–If you notice the snow thrower
running in an unstable state or hear abnormal sounds from
the engine, immediately stop the machine, disconnect the
power, and contact an authorized Snow Joe® + Sun Joe®
dealer or the Snow Joe® + Sun Joe® customer service
center at 1-866-SNOWJOE (1-866-766-9563).
• Noisecontrol–When using the snow thrower, you must
respect local laws and regulations regarding noise control
and environmental protection. To avoid noise disturbance,
you should carefully decide upon an appropriate operation
time and consider the surrounding conditions.
• Whenworkiscompleted–Disconnect the snow
thrower from the power source when not in use, when
changing accessories, and before performing any
maintenance function.

6
Know Your Electric Snow Thrower
Read the owner’s manual and safety rules carefully before operating your electric snow thrower. Compare the illustration below
to the actual unit in order to familiarize yourself with the location of the various controls and adjustments. Save this manual for
future reference.
Technical Data
Motor 14.5A ...............................................................................
Rated Voltage 120V ~ 60 Hz
.....................................................
No Load Speed 2700 rpm
........................................................
Clearing Width 22 in. (55.9 cm)
.................................................
Clearing Depth 13 in. (33 cm)
...................................................
Throw Distance Max 25 ft (7.6 m)
..............................................
Plowing Capacity Max 850 lbs/min (385 kg/min)
......................
Directional Control 180º adjustable chute
.................................
Rotor 4 rubber-tipped steel blades
...........................................
Type of Snow
..........................................................
Light, uy
Net Weight 34 lbs (15.5 kg)
.......................................................
1. Soft grip
2. ON/OFF switch
3. Safety lock button
4. Switch box
5. Appliance cord
6. Extension cord restraint hook
7. Upper handle knobs and bolts
(2 sets)
8. Middle frame
9. Cable clips (3)
10. Lower frame
11. Lower handle knobs and bolts
(2 sets)
12. Wheels (2)
13. Skid shoes (2)
14. Rubber blade assembly
15. Auger assembly
16. Scraper bar
17. Discharge chute
18. Deector knob
19. Chute deector
20. Lower chute crank
21. Crank rod connector
22. Thumbscrew
23. Upper chute crank
24. Rubber ring
25. Upper frame
1
2
3
4
5
6
7
8
9
10
11
12
13 14 16
17
18
19
20
21
22
23
24
25
15

7
Unpacking
Carton Contents:
• Electric snow thrower with middle frame and upper frame
• Upper crank rod
• Lower crank rod
• Extension cord restraint hook
• Cable clips (3)
• Handle knobs and bolts (4 sets)
• Manuals with registration card
1. Carefully remove the electric snow thrower and check to
see that all of the above items are supplied.
2. Inspect the product carefully to make sure no breakage or
damage occurred during shipping. If you nd damaged or
missing parts, DO NOT return the unit to the store. Please
call the Snow Joe® + Sun Joe® customer service center at
1-866-SNOWJOE (1-866-766-9563).
Do not discard the shipping carton and packaging NOTE:
material until you are ready to use your new electric snow
thrower. The packaging is made of recyclable materials.
Properly dispose of these materials in accordance with
local regulations or save the packaging for long-term
product storage.
IMPORTANT! The equipment and packaging material are not
toys. Do not let children play with plastic bags, foils, or small
parts. These items can be swallowed and pose a suocation
risk!
Assembly
mWARNING! Inspect wiring, which, if damaged during
shipping, may cause serious bodily injury during equipment
use. If any damage is seen or suspected, do not assemble.
Instead, contact the Snow Joe® + Sun Joe® customer service
center at 1-866-SNOWJOE (1-866-766-9563) for assistance.
Handle with care during assembly so that electrical wiring does
not become damaged.
Handle Frame Assembly
1. For easy assembly, the unit comes complete with
most parts already connected. To complete the handle
assembly, simply pull the middle frame back and pull the
upper frame up (Fig. 1).
2. Secure the connection of the middle frame to the lower
frame by fastening the rst set of knobs and bolts on each
side (Fig. 2).
3. Before securing the upper frame, slide the extension cord
restraint hook up the upper frame (Fig. 3).
Fig. 1
Upper frame
Middle frame
Lower frame
Fig. 2
Lower frame
Middle
frame
Knob + bolt

8
4. Secure the connection of the upper frame to the middle
frame by fastening the second set of knob and bolt on
each side (Fig. 4).
5. Clip on the 3 cable clips on the frame, and insert the cable
inside the cable clips (Fig. 5).
Chute Crank Assembly
1. Remove the cotter pin from the lower chute crank (Fig. 6).
2. Install the lower crank rod by inserting it into the opening
at the back of the housing with holes aligned (Fig. 7).
3. Secure the lower chute crank in place with the cotter pin
(Fig. 8).
4. Remove the thumbscrew on the crank rod connector by
hand (Fig. 9).
Fig. 3
Upper frame
Extension
cord restraint
hook
Fig. 4
Middle frame
Upper
frame
Knob + bolt
Fig. 5
Cable clips Cable
Fig. 6 Cotter Pin
Lower chute crank
Fig. 7 Lower chute crank
Align the holes
Fig. 8
Cotter pin

9
5. Slide the upper chute crank through the rubber ring
located on the middle frame (Fig. 10).
6. Slide the upper chute crank into the crank rod connector
(Fig. 11).
7. Align the screw holes and tighten the thumbscrew by hand
(Fig. 12).
Operation
NOTE: Before using this machine, make sure that the power
source you will use complies with the specications detailed
in this manual. Before inserting the plug into the socket, verify
that the snow thrower’s auger and rubber plates are rmly
secured with screws, and that the rubber plates are facing the
correct direction. Perform a test run to ensure that the rotor
turns freely.
Securing the Extension Cord
1. For safe and ecient use of your snow thrower, use only
a UL-rated extension cord recommended for outdoor use.
Refer to the on page 2.Extension Cord Chart
2. Push the loop of the extension cord through the slot from
the opposite side of the restraint hook. Position the loop
over the hook and pull the cable back through the slot
(Fig. 13).
3. Insert the female end of the extension cord into the
appliance's polarized male plug (Fig. 14).
Fig. 9
Thumbscrew
Lower chute
crank
Crank
rod
connector
Fig. 10
Rubber ring
Upper chute crank
Fig. 11
Upper chute
crank
Crank rod
connector
Fig. 12
Thumbscrew
Fig. 13
Extension cord
restraint hook
Extension cord

10
mWARNING! Damaged electrical cords present risk of
re,electricalshock,andseriousbodilyinjury.
Before operating the snow thrower, carefully examine the
electrical cord. If the cord is damaged, do not use the snow
thrower. Replace or repair the damaged cord immediately.
If you need assistance, contact an authorized Snow Joe® +
Sun Joe® dealer or the Snow Joe® + Sun Joe® customer
service center at 1-866-SNOWJOE (1-866-766-9563).
PoweringOn+O
mWARNING! The auger starts rotating immediately after
the snow thrower is switched on. Keep hands and feet away
from the auger.
1. To power on, depress and hold the safety lock button
found alongside the switch housing (Fig. 15).
2. While depressing the safety lock button, pull the
ON/OFF switch lever toward you. Once the machine
powers on, release the safety lock button and begin
operation (Fig. 15). The machine can only be started
by depressing the safety lock button rst, followed by
squeezing the ON/OFF switch lever; reverse operation will
not start the machine.
3. To power o, release your grip on the ON/OFF
switch lever.
Moving the Machine + Plowing the Snow
mWARNING! Foreign objects, such as rocks, broken
glass, nails, wire, or string, can be picked up and thrown by
the snow thrower, causing serious personal injury.
Remove all foreign objects from the area to be plowed before
operating the snow thrower.
1. Keep the area of operation free of foreign objects that can
become thrown by the rotor blades. Perform a thorough
inspection of the area since some objects may be hidden
from view by surrounding snow. If the snow thrower hits
an obstruction or picks up a foreign object during use,
stop the snow thrower, disconnect the extension cord,
remove the obstruction, and inspect the unit for damage.
Repair or replace any damaged part before restarting and
operating the unit.
2. Keep children, pets, and bystanders away from the area of
operation. Be aware that the normal noise of the machine
when turned on may make it dicult for you to hear
approaching people.
3. When moving the snow thrower, use the wheels on one
side as the pivot point. Slightly tilt the snow thrower on
this pivot point to move it forward or backward.
4. Start your clearing path near the electrical outlet and
work outward, throwing snow in a back and forth motion.
To clear in the opposite direction, step over the cord
and pivot the snow thrower on its wheels. Make sure to
overlap clearing paths.
5. Note the wind direction. If possible, move in the same
direction as the wind so that the snow is not thrown
against the wind (and thus back into your face and onto
the just cleared path).
6. While moving the snow thrower, do not drag the power
cable violently or roughly. The snow thrower should move
within the range that the cable can reach.
7. Do not push the snow thrower with excessive force.
You should push the machine gently and evenly in
accordance with the unit’s throw rate.
8. Do not apply additional man-made load to the engine
since this may cause engine damage.
9. Some parts of the snow thrower may freeze under
extreme temperature conditions. Do not attempt to
operate the snow thrower with frozen parts. If the parts
freeze while the snow thrower is in use, stop the snow
thrower, unplug the extension cord, and inspect for frozen
parts. Free all parts before restarting or operating the
snow thrower. Never force controls that have frozen.
10. When working on pebbles, gravel, or unpaved surfaces,
avoid throwing loose surface material along with the snow
by pushing down on the handle to raise the scraper bar at
the base of the unit above the pebbles or gravel.
11. For larger areas, a denite pattern of operation is required
to thoroughly clean an area of snow. These patterns
will avoid throwing snow in unwanted places, a well as
eliminate the need for a second removal of snow (Fig. 16).
Fig. 14
Fig. 15
On/Oswitch
Safety lock
button

11
Pattern A: Throw the snow to the right or left side where
it is possible. For areas such as a long driveway, it is
advantageous to start in the middle. Plow from one end to
the other, throwing snow to both sides.
Pattern B: If the snow can only be thrown to one side of
the area to be cleared, start on the opposite side.
Changing Throw Direction + Throw
Height
mWARNING! Never direct the discharge chute at the
operator, at bystanders, at vehicles, or at nearby windows.
The discharged snow and foreign objects accidentally picked
up by the snow thrower can cause serious damage and
personal injury.
Always orient the discharge chute in the opposite direction
from where you, bystanders, surrounding vehicles, or windows
are located.
NOTE: The chute crank shaft rotation is sti in the rst initial
use. It will loosen with use.
1. The discharge chute can be adjusted 180 degrees by
rotating the chute crank. Rotate the chute control crank
clockwise to move the discharge chute to the left (Fig. 17)
and counterclockwise to move the chute to the right
(Fig. 18).
2. The chute deector on the top of the discharge chute
controls the height of the snow stream. Loosen the knob
to raise or lower the deector to the desired height of
snow you wish to throw. Tighten the knob to secure the
deector (Fig. 19).
Fig. 16
pattern A
pattern B
Fig. 17
Chute
crank
Discharge
chute
Fig. 18

12
mWARNING! Make sure that the chute deector snaps
and locks completely onto the discharge chute. An opening
between the discharge chute and the chute deector may
allow foreign objects to be picked up by the snow thrower
and thrown in the direction of the operator causing serious
boldly injury.
• Do not advance the chute deector too far forward
causing an opening to appear between the deector and
discharge chute.
• Do not overtighten the knobs on the chute deector.
Maintenance
mWARNING! Make sure to turn o the switch and
disconnect the extension cord before performing any
maintenance task on your snow thrower.
Lifetime Lubrication (Motor + Auger)
Lubrication is not necessary and may damage the unit.
The snow thrower is lubricated for lifetime use at the factory
before shipment.
General Maintenance Tips
1. Do not attempt to repair the machine unless you have the
proper tools and instructions for disassembly and repair of
the machine.
2. Check bolts and screws at frequent intervals for proper
tightness to ensure that the equipment is in safe
working condition.
3. After each snow removal session, run the snow thrower
for a few minutes to prevent the collector/impeller from
freezing. Shut o the motor, wait for all revolving parts to
stop completely, and wipe residual ice and snow o the
unit. Rotate the chute crank several times to remove any
excess snow.
4. Only use a cloth soaked with hot water and a soft brush
to clean the snow thrower; never wet or spray water on
the machine!
5. Do not use detergent or solvents as these could cause
irreparable damage to the snow thrower. Chemicals can
destroy the plastic parts.
6. To protect the snow thrower from corrosion when storing
for long periods, lightly oil the metal parts.
7. Store the appliance in a dry area out of reach of children.
8. For the user's safety, worn or damaged parts must be
replaced. Replace with original replacement parts only.
Parts from another snow thrower may not t properly,
causing an unsafe situation.
Replacing the Rubber Plates
NOTE: When replacing worn rubber plates, pay close attention
to carefully distinguish between the coarse and smooth side
of the plates. Place the coarse side inside and the smooth
side outside.
1. Detach the worn rubber plate assembly by removing the
two sets of nut, bolt and washer located on the ends
(Figs. 20 – 21).
2. Loosen the middle two sets of nut, washer and bolt to
detach the worn rubber plate from the metal frame
(Fig. 22).
Deector
knob
Fig. 19
Fig. 20
Remove the nuts,
washers and bolts Auger assembly
Worn rubber plate assembly
Fig. 21
Nut
Washer
Bolt
Worn rubber plate
assembly

13
3. Attach the new rubber plate onto the metal frame by
replacing and tightening the middle two sets of nut,
washer and bolt (Fig. 22).
4. Reassemble the rubber plate assembly to the auger
assembly by replacing and tightening the two sets of nut,
washer and bolt used to secure it (Figs. 20 – 21).
5. Repeat above steps for all worn plates.
Replacing the Scraper Bar
1. The scraper bar is located at the base of the snow thrower
beneath the rotor housing. Turn the snow thrower to sit on
its side when replacing the scraper bar (Fig. 23).
2. Detach the worn scraper bar from the snow thrower by
removing the 3 screws that hold it in place (Fig. 24).
3. Install the new scraper bar and fasten it securely to the
snow thrower with the 3 screws (Fig. 24).
Replacing the Belt + Pulley
NOTE: Determine the left and right hand side of the snow
thrower by standing behind the unit in the normal operating
position.
1. Remove the screws from the left panel of the snow
thrower and remove the left panel (Fig. 25).
2. Lift the belt tension pulley and roll the worn belt up and o
the big pulley from the top of the big pulley (Fig. 26).
3. To replace the big pulley, remove the screw and washer
from the middle of the pulley. While securing the auger so
it does not spin, use a 7/8-inch socket to turn the outer
nut of the pulley clockwise (the pulley is left-handed,
so loosening and tightening occur in reverse orientation;
clockwise to loosen and counterclockwise to tighten).
Once the old pulley is removed, replace the big pulley and
tighten the outer nut counterclockwise with the 7/8-inch
socket. Replace and tighten the screw and washer
(Fig. 27).
Metal frameRubber plate
Fig. 22
Fig. 23
Scraper bar
Fig. 24
Screws
Scraper bar
Fig. 25
Left panel
Screws
Fig. 26
Big pulley
Belt tension
pulley
Belt

15
Optional Accessories
mWARNING! ALWAYS use only authorized Snow Joe® + Sun Joe® replacement parts and accessories. NEVER use
replacement parts or accessories that are not intended for use with this electric snow thrower. Contact Snow Joe® + Sun Joe®
if you are unsure whether it is safe to use a particular replacement part or accessory with your electric snow thrower. The use of
any other attachment or accessory can be dangerous and could cause injury or mechanical damage.
Snow Joe® + Sun Joe® SJTW-A 14-gauge
50-foot extension cord with lighted end
PJEXT50-B
ModelAccessories Item
1
2
Universal snow thrower chute clean-out tool SJCOT
NOTE: Accessories are subject to change without any obligation on the part of Snow Joe® + Sun Joe® to provide notice of such
changes. Accessories can be ordered online at snowjoe.com or via phone by contacting the Snow Joe® + Sun Joe® customer
service center at 1-866-SNOWJOE (1-866-766-9563).

R4_01282020
SNOW JOE® + SUN JOE® CUSTOMER PROMISE
OUR WARRANTY:
Snow Joe warrants new, genuine, powered and non-powered Products to be free from defects in material or workmanship when used
for ordinary household use for a period of two years from the date of purchase by the original, end-user purchaser when purchased
from Snow Joe or from one of Snow Joe’s authorized sellers with proof of purchase. Because Snow Joe is unable to control the quality
of its Products sold by unauthorized sellers, unless otherwise prohibited by law, this Warranty does not cover Products purchased from
unauthorized sellers. If your Product does not work or there’s an issue with a specic part that is covered by the terms of this Warranty,
Snow Joe will elect to either (1) send you a free replacement part, (2) replace the Product with a new or comparable product at no
charge, or (3) repair the Product. How cool is that!
This Warranty gives you specific legal rights, and you may also have other rights which vary from State to State.
PRODUCT REGISTRATION:
Snow Joe strongly encourages you to register your Product. You can register online at snowjoe.com/register, or by printing and
mailing in a registration card available online from our website, or calling our Customer Service Department at 1-866-SNOWJOE
(1-866-766-9563) help@snowjoe.com, or by e-mailing us at . Failure to register your Product will not diminish your warranty
rights. However, registering your Product will allow Snow Joe to better serve you with any of your customer service needs.
WHO CAN SEEK LIMITED WARRANTY COVERAGE:
This Warranty is extended by Snow Joe to the original purchaser and original owner of the Product.
WHAT IS NOT COVERED?
This Warranty does not apply if the Product has been used commercially or for non-household or rental applications. This Warranty also
does not apply if the Product was purchased from an unauthorized seller. This Warranty also does not cover cosmetic changes that do
not aect performance. Wearing parts like belts, augers, chains and tines are not covered under this Warranty, and can be purchased
at or by calling . snowjoe.com 1-866-SNOWJOE (1-866-766-9563)
ABOVE ALL ELSE, Snow Joe, LLC (“Snow Joe”) is dedicated to you, our customer. We strive to make your experience as pleasant as
possible. Unfortunately, there are times when a Snow Joe®, Sun Joe®
, or Aqua Joe® product (“Product”) does not work or breaks under
normal operating conditions. We think it’s important that you know what you can expect from us. That’s why we have a Limited Warranty
(“Warranty”) for our Products.
16
EN

17

SP
© 2020 Snow Joe®, LLC
Derechos reservados. Instrucciones originales. GUARDE ESTAS INSTRUCCIONES
19
Una división de Snow Joe
® , LLC Modelo SJ626E Forma No. SJ-SJ626E-880S-MR2
MANUAL DEL OPERADOR
QUITANIEVE ELÉCTRICO
55.9 CM | 14.5 A
R
¡IMPORTANTE!
Instrucciones de seguridad
Todos los operadores deberán leer
estas instrucciones antes del uso
Cualquier artefacto eléctrico puede ser peligroso si se usa
incorrectamente. Algunas de las precauciones de seguridad
que aparecen en este manual se aplican a muchos artefactos
eléctricos. Otras advertencias son especícas al uso de este
quitanieve. Conserve este manual para futuras referencias.
¡ADVERTENCIAS generales de
seguridad!
Usted y cualquier otro operador de este quitanieve deberán
leer, entender y seguir estas instrucciones en su totalidad,
y deberán volver a leerlas al inicio de cada temporada de
nieve. No seguir todas las instrucciones puede causar un
CHOQUE ELÉCTRICO, INCENDIO y/o LESIONES
PERSONALES severas.
Preste atención al símbolo m de alerta de seguridad
personal usado en este manual para enfocar su
atención a una ADVERTENCIA dada junto a una
instruccióndeoperaciónparticular.Estosignica
que la operación requiere ATENCIÓN, PRECAUCIÓN Y
CAUTELA especiales.
1. Mantenga el área de trabajo limpia y bien iluminada.
Las áreas de trabajo abarrotadas y las áreas oscuras
provocan accidentes.
2. No opere el quitanieve en una atmósfera explosiva,
como en presencia de líquidos inamables, gases o polvo.
Las herramientas eléctricas crean chispas que pueden
encender los polvos o gases.
3. Mantenga a las mascotas, niños y espectadores
alejados del área de trabajo. Tenga en cuenta que
el ruido normal de la máquina al estar funcionando
puede hacer difícil para usted oír a la gente acercarse.
Los visitantes deben usar gafas de seguridad y ser
mantenidos a una distancia segura, lejos del área de
trabajo. No permita que los espectadores toquen el
quitanieve o el cable de extensión.
4. Los enchufes deben encajar en los tomacorrientes.
Nunca modique el enchufe de ninguna manera. No use
ningún enchufe adaptador con artefactos que tengan
conexión a tierra. El uso de enchufes no modicados
y tomacorrientes equivalentes reducirá el riesgo de un
choque eléctrico.
5. Eviteelcontactodelcuerpoconsupercies
conectadas a tierra (es decir, tuberías de agua en cielo
raso o subterráneas, radiadores, cocinas, refrigeradores,
hornos microondas y estructuras externas de equipos
calefactores). Tome las precauciones necesarias para
evitar un choque eléctrico. Hay un mayor riesgo de
choque eléctrico si su cuerpo está conectado a tierra.
6. No maltrate el cable. Mantenga el cable alejado del
calor, aceite, bordes alados o partes en movimiento.
Nunca jale el quitanieve por su cable, o tire del cable para
desconectarlo del tomacorriente. Los cables dañados o
enredados aumentan el riesgo de un choque eléctrico.
7. Reemplace o repare apropiadamente los cables
dañados. Si el cable se daña de cualquier manera
mientras está enchufado en el tomacorriente de pared,
tire inmediatamente del enchufe del cable de extensión y
retírelo del tomacorriente.
8. El contacto con el agua durante la operación del
quitanieve puede resultar en un choque eléctrico y
graves lesiones personales. No use el quitanieve en
lugares húmedos o mojados, ni bajo la lluvia. No toque el
enchufe o el artefacto con las manos húmedas ni mientras
esté parado sobre agua.
9. m ¡ADVERTENCIA! Use cables de extensión de los
siguientes tipos SW-A, SOW-A, STW-A, STOW-A, :
SJW-A, SJTW-A o SJTOW-A. Estos cables están
especicadosparausoenexterioresyreducenel
riesgo de un choque eléctrico.
10. Apague el interruptor de alimentación y desconecte el
cable de alimentación antes de llevar a cabo cualquier
ajuste, inspección, mantenimiento, reparación, cambio
de accesorios o limpieza del quitanieve. Siga el mismo
procedimiento si otras condiciones peligrosas están
presentes durante la operación. Cualquier ajuste a
la unidad debe ser llevado a cabo después de que las
partes giratorias dentro del quitanieve se hayan detenido
por completo. Estas medidas preventivas de seguridad
reducen el riesgo de un encendido accidental
del quitanieve.
11. Si usted ve que el cable de alimentación principal o
el cable de extensión están dañados, desconecte la
alimentación y desconecte el enchufe del receptáculo
inmediatamente. Repare el cable o reemplácelo de
ser necesario.

23
Símbolos de seguridad
La siguiente tabla describe los símbolos de seguridad que pueden aparecer en este producto. Lea, comprenda y siga todas las
instrucciones relacionadas a esta máquina antes de intentar ensamblarla y operarla.
Es obligatorio usar en todo momento
gafas protectoras o una visera para
proteger los ojos y el rostro.
Desconecte el enchufe antes de
llevar a cabo cualquier reparación
o cuando el cable esté dañado
o enredado.
Tenga cuidado con piedras y otros
objetos que puedan ser lanzados
desde el artefacto. Mantenga a
todos los transeúntes, niños y
animales domésticos a una distancia
segura, lejos del área de trabajo.
Mantenga los pies alejados de las
partes giratorias del quitanieve. Las
partes giratorias pueden causar
lesiones corporales severas.
Mantenga las manos y pies
alejados de las partes giratorias.
Mantenga las manos alejadas
de las partes giratorias del
quitanieve. Las partes giratorias
pueden causar lesiones
corporales severas.
La parte giratoria seguirá girando
continuamente durante varios
segundos después de que haya
apagado la máquina.
Doble aislamiento.
Mantenga el cable de alimentación
exible alejado de las cuchillas
de corte.
Mantenga siempre el cable de
alimentación alejado de fuentes de
calor, aceites o bordes alados. Retire
inmediatamente el enchufe
del tomacorriente si el cable se daña
o se enreda.
Símbolo Descripción Símbolo Descripción
LEA EL(LOS) MANUAL(ES) DEL
OPERADOR: lea, comprenda y
siga todas las instrucciones en
el(los) manual(es) antes de intentar
ensamblar y operar esta unidad.
ALERTA DE SEGURIDAD:
indica una precaución,
advertencia o peligro.
¡ADVERTENCIA! No exponga la
unidad a la lluvia o a condiciones
húmedas. Manténgala seca.
Utilice guantes protectores y
calzado no deslizante al
operar esta máquina y al
manipular desechos.
¡PRECAUCIÓN! Tenga cuidado
con piedras y otros objetos
extraños que puedan ser
lanzados desde el artefacto.
¡PELIGRO! Peligro de corte/
mutilación: mantenga las manos
lejos del rotor giratorio. No use las
manos para desatascar la carcasa
del rotor. Detenga el motor antes de
retirar residuos.
Produkt Specifikationer
Mærke: | Snow Joe |
Kategori: | Sneslynge |
Model: | SJ626E |
Har du brug for hjælp?
Hvis du har brug for hjælp til Snow Joe SJ626E stil et spørgsmål nedenfor, og andre brugere vil svare dig
Sneslynge Snow Joe Manualer
14 November 2024
22 September 2024
19 September 2024
30 August 2024
15 August 2024
14 August 2024
10 August 2024
9 August 2024
6 August 2024
5 August 2024
Sneslynge Manualer
- RYOBI
- Texas
- DeWalt
- American DJ
- Biltema
- Yard Force
- Frontier
- Meec Tools
- Honda
- Stiga
- Alpina
- Craftsman
- Karma
- Troy-Bilt
- Cotech
Nyeste Sneslynge Manualer
16 Juli 2025
16 Juni 2025
15 Juni 2025
25 Januar 2025
12 Januar 2025
3 Januar 2025
30 December 2025
29 December 2024
9 December 2024
24 November 2024
