Side 1/5

page 1 / 5 sonel.com

• LED test results indication

• quick access to the measurement procedures

• compact design and ergonomic soft case

• automatic measurement range selection

• measurement of protective conductor resistance with

the currents:

» PAT-2 •PAT-2E PAT-10 | •200 mA,

»PAT-10 | 200 mA, 10 A

• insulation resistance measurement:

» PAT-2 •PAT-2E PAT-10 | •250 V

»PAT-2E PAT-10 | •250 V, 500 V

• PRCD trip time testing

• measurement of equivalent, touch and differential

leakage current

• measurement of mains voltage

• IEC lead test

• saving results to the memory

• printing labels with measurement results (option)

• works with software: and Sonel Reader Sonel

PATAnalysis

• works with Sonel PAT Analysis Mobile application

LED test results

indication

(PASS / FAIL)

Quick access to the

measurement procedures

Portable Appliance Testers

PAT-10 / 2E / 2

index: WMGBPAT10 / WMGBPAT2E / WMGBPAT2

Security at hand

Features

PAT-10

START

Full autotest procedure

after pressing

START

Visual test

Measurements

Saving to

memory/printing

page 2 / 5 sonel.com

Standards

The tester can be used to test the equipment performance in accordance with

standards:

• EN 50699:2021 Recurrent tests of electrical equipment

• EN 60745-1 Hand-held motor-operated electric tools. Safety. General requirements

• EN 61029 Safety of transportable motor-operated electric tools - Generalre-

quirements

• EN 60335-1 Household and similar electrical appliances -Safety - Part 1: Gen-

eral requirements

• EN 60950 Safety of information technology equipment (IT Equipment)

• AS/NZS 3760:2010 In-service safety inspection and testing of electri-

calequipment

• VDE 0404-1 Prüf- und Messeinrichtungen zum Prüfen der elektrischen Sicher-

heit von elektrischen Geräten. Teil 1: Allgemeine Anforderungen

• VDE 0404-2 Prüf- und Messeinrichtungen zum Prüfen der elektrischen Sich-

erheit von elektrischen Geräten. Teil 2: Prüfeinrichtungen für Prüfungen nach

Instandsetzung, Änderung oder für Wiederholungsprüfungen

• VDE 0701-0702 Prüfung nach Instandsetzung, Änderung elektrischer Geräte.

Wiederholungsprüfung elektrischer Geräte. Allgemeine Anforderungen für die

elektrische Sicherheit

Capabilities

The PAT-10, PAT-2E and PAT-2 meters are an innovative combination of small

dimensions (allowing full mobility) with advanced measuring systems, provid-

ing -fully automatic measurements of electrical devices, IEC cables and exten

sion cords - also those with PRCD.

A set of tests is made with just one press of the START button. Conguration

options allow to modify meter’s work mode, and thus - to better tailor it to us-

er’s needs.

PAT instruments are equipped with a manual measurement mode. It is useful

in situations where individual test is sufcient instead of a complex measure-

ment sequence.

All instruments enable basic tests without external power supply: simplied

test sets are available in battery mode.

Small dimensions, light weight and a specially designed bag for the meter and

accessories provide both convenience and high mobility. Wireless communi-

cation with the printer allows free measurement place arrangement without

tangled wires. Meter’s memory and integration with PC software additionally

extends the functionality of the instruments.
