1. Unpack speaker & set
aside grille assembly.
2. Use included tile bridge
to mark cutout in tile.
3. Use Rotozip or other tool
to cut hole.
9. Select the tap position by
adjusting rotary switch
to desired high impedance
value or voice coil direct
mode.
11. Done!10. Press grille into place.
6. Insert speaker into
mounting hole with
installation aid in place.
Screw down both bolts on
the bafe face to actuate
the mounting wings. Firmly
secure both bolts – do not
over-tighten.
7. If required, a sheet-metal
tab located on the rear
panel of the speaker serves
as a secondary point of
attachment (cable not
included).
8. Once all painting and
nish work is completed,
remove the paint mask.
Hole Diameters
CM42-EZs-II
165.1 mm (6.50 in)
All other CMEZ, FS and BGM models
266.7 mm (10.50 in)
2. Use included tile bridge
to mark cutout in sheetrock.
3. Use Rotozip or other tool
to cut hole.
3. Use Rotozip or other tool
to cut hole.
11. Done!
Do not spec or install speaker near support beam, ventilation duct or
other structure that may interfere with speaker function or dispersion.
SoundTube speakers must be installed by a professional audio installer/contractor. For safety and for
optimum audio performance, installer must follow all directions issued by SoundTube Entertainment.
1. Unpack speaker & set
aside grille assembly.
5. Tighten screw on terminal
plate, and push conduit
connector into knockout.
4. Run signal wires through
conduit connector, then through
cover plate. Connect to ceramic
terminal strip. Two + and two -
connectors are provided for
daisy chaining.
5. Tighten screw on terminal
plate, and push conduit
connector into knockout.
4. Run signal wires through
conduit connector, then through
cover plate. Connect to ceramic
terminal strip. Two + and two -
connectors are provided for
daisy chaining.
4. Run signal wires through
conduit connector, then through
cover plate. Connect to ceramic
terminal strip. Two + and two -
connectors are provided for
daisy chaining.
9. Select the tap position by
adjusting rotary switch
to desired high impedance
value or voice coil direct
mode.
10. Press grille into place.
8. Once all painting andnish
work is completed, remove
the paint mask.
10. Press grille into place.
7. Insert speaker into
mounting hole with
installation aid in place.
Screw down both bolts on
the bafe face to actuate
the mounting wings. Firmly
secure both bolts – do not
over-tighten.
5. Tighten screw on terminal
plate, and push conduit
connector into knockout.
6. If required, a sheet-metal
tab located on the rear
panel of the speaker serves
as a secondary point of
attachment (cable not
included).
6. If required, a sheet-metal
tab located on the rear
panel of the speaker serves
as a secondary point of
attachment (cable not
included).
Hole Diameters
CM42-EZs-II
165.1 mm (6.50 in)
All other CMEZ, FS and BGM models
266.7 mm (10.50 in)
Hole Diameters
CM42-EZs-II
165.1 mm (6.50 in)
All other CMEZ, FS and BGM models
266.7 mm (10.50 in)
9. Attach grille safety clip by
placing the large end of the
clip over snap-t post (1),
then sliding clip until small
end snaps into place around
post (2).
9. Attach grille safety clip by
placing the large end of the
clip over snap-t post (1),
then sliding clip until small
end snaps into place around
post (2).
9. Attach grille safety clip by
placing the large end of the
clip over snap-t post (1),
then sliding clip until small
end snaps into place around
post (2).
1. Nail or screw bracket to
joists. Secure conduit/signal
wire away from hole in
bracket.
2. Complete Finish work.
7. Insert speaker into
mounting hole with
installation aid in place.
Screw down both bolts on
the bafe face to actuate
the mounting wings. Firmly
secure both bolts – do not
over-tighten.
8. Once all painting and
nish work is completed,
remove the paint mask.
9. Select the tap position
by adjusting rotary switch
to desired high impedance
value or voice coil direct
mode.
11. Done!
(CM82-EZ-FS and CM82-EZs-FS are UL1480 UUMW
listed, all other CMEZ and BGM speakers are UL1480 UEAY listed.)
EQ settings required for the EN54-24 specic installations
Model
EQ-1
BANDWIDTH
EQ-2
BANDWIDTH
CM62-BGM
-3dB @ 125Hz
.5 Octave
-3dB @ 175Hz
1.0 Octave
CM62- EZ-II
-6dB @ 200Hz
1.0 Octave
+2dB @ 4800Hz
0.7 Octave
CM62-EZs-II
-6dB @ 200Hz
1.0 Octave
+3dB @ 4800Hz
0.7 Octave
CM42- EZs-II
-4dB @ 200Hz
1.0 Octave
EN54-24
0359
SoundTube Entertainment Inc
6430 North Business Park Loop Rd.
Park City, UT 84098
0359-CPR-00442
EN54-24:2008
CM62-BGM-WH, CM62-BGM-BK, CM62-EZs-II-WH, CM62-EZs-II-BK,
CM62-EZ-II-WH, CM62-EZ-II-BK, CM42-EZs-II-WH, CM42-EZs-II-BK
E ential c r acteristics ss ha
Performan ce
S ttering (frequency range / sensitivity) ca
Passed
Nominal impedance Passed
Hor ontal and vertical dispersion angle p iz
Passed
Maximum sound pressur level e
Passed
dessaP )ytilibarud( ecnamrofrep esion lanimoN
Dry heat (operating)
Passed
Dry h t (endurance) ea
N/A
Cold (in operation) Passed
Damp heat cyc (operating) , lic
Passed
Damp heat steady stat (end ance) , e ur
Passed
Damp heat cyc (fatigue test) , lic
N/A
Sulfur dioxide (SO2) cor si (endurance) ro on
Passed
Shock (operating)
Passed
Impact (operati ) ng
Passed
Si soidal vibration (operating) nu
Passed
Vibration, sinusoidal (enduran ) ce
Passed
Enclosure testing
Passed
Document Issue Date: 12-4-14
Document Reference Number: CMEZ0039
Document Revision: 02-04-2015 Rev 2
15
