Specications CVC675 CVC75
ImageSensor.......................... 1/3”SonySuperHADII™colorCCD 1/3”BWCCD
Resolution................................ 700TVlines 420TVlines
MinimumIllumination............... 0.001lux(sense-upon) 0.02lux
EffectivePixels........................ 976(H)x494(V) 512(H)x492(V)
ScanningSystem..................... 2:1interlace 2:1interlace
AngleofView........................... Horizontal:72°/Vertical:53° Horizontal:72°/Vertical:53°
Outputs/Connection............... Video-RCA,Power-DCjack Video-BNC,Power-DCjack
ScanningFrequency................ 15.75kHz(H)/60Hz(V) 15.75kHz(H)/60Hz(V)
ElectronicShutterSpeed......... Auto:1/60sec.‒1/50,000sec. Auto:1/60sec.‒1/50,000sec.
Synchronization....................... Internal Internal
VideoOutputLevel.................. 1.0Vp-p/75ohms 1.0Vp-p/75ohms
VideoS/NRatio....................... Greaterthan52dB Morethan48dB
Housing................................... Stainlesssteel Stainlesssteel
Humidity................................... 14°F‒122°F/within90%RH 14°F‒122°F/within90%RH
PowerConsumption................ 110mA 130mA
PowerSupply.......................... 12VDCregulated 12VDCregulated
(UL&CSAlistedpowersupplyincluded) (UL&CSAlistedpowersupplyincluded)
Dimensions.............................. 2.75”(W)x4.25”(H)x2.75”(L) 2.75”(W)x4.25”(H)x2.75”(L)
Weight..................................... 3.45oz. 3.45oz.
•Fitsintoasinglegangelectricalbox(included)
•Brushedstainlesssteelfaceplate
•700TVlinesofresolution
960H Color or Standard BW
CVC675 3.6mmlens,color
SpecoTechnologiesisconstantlydevelopingandimprovingproducts.Wereservetherighttomodifyproductdesignandspecications
withoutnoticeandwithoutincurringanyobligation.SpecRev.1/13/14
800-645-5516 • Fax: 631-957-9142 or 631-957-3880 • specotech.com
CVC6752.2.....2.2mmlens
CVC6752.5.....2.5mmlens
CVC6752.9.....2.9mmlens
