ITEM №: HLPR1TW
Adjustable function
1. Resistor A: If you want to change the working time of IR Led, please
open the cover at the bottom of the camera(As showed in the following
picture), you can adjust the IR LED working time. Anticlockwise refers to the
IR LED will start working under the darker situation. clockwise refers to the
IR LED will start working under the brighter situation.
2. Resistor B: If you want to change the intensity of the IR light, please
open the cover at the bottom of the camera(As showed in the following
picture), you can adjust the IR light intensity.
When you feel EXPOSURE on the plate, please lower down IR intensity;
when you feel DARK on the plate, please increase IR intensity, IR intensity
please refer to picture shown 。
Packing
* Camera Hexagonal Wrench X1 *X1
* User Manual Mounting drawing paper X1 *X1
* Screw X3 Junction Box *X1
* Plastic-Conical-Anchor X3 Power Cable Connector X1 *
* Junction box(including accessories) X1
Specification
ITEM
HLPR1TW
IP Rating
IP66
Type
Color/Monochrome
Signal System
NTSC/PAL
Pick Up Device
1/2.9" 2.2 Mega Pixels CMOS
Picture Elements
1920(H)X1080(V)
Min Illumination
0Lux（42 Pieces IR LED ON）
S/N Ratio
≥52dB
Lens
9-22mm Motorized Varifocal Auto iris IR Lens
M ph
28 miles/h
3D/2D
ON
SENS-UP
OFF
IR SMART
ON
White Balance
ATW
Back Light Compensation
OFF
DWDR
OFF
Video Out- put
HD-TVI/HD-AHD/HD-CVI/CVBS
Power Supply
DC12V ± %/AC24V10 ±10%
Current Consumption
DC:580mA/AC 0mA (Max) 25
IR Effect Distance
2~15m（ ）6.56~49.18ft (Outdoor)
Dimension
231×84X110mm (9.1”×3.3”×4.3” )
Weight
1260g/2.78pounds (Including Junction Box)
Storage Temperature
- +6030～℃ (- +14022～℉)
Operating Temperature
- +4030～℃ (- +10422～℉)
Remark: Non-regulative adaptor may cause camera damaged.
License Plate Capture Camera
Resistor A
Resistor B
Use the OSD joystick to switch the camera to:
video signal output switches
TVI DVR Coaxial Signal Control and Auto Focus Lens
1) Menu
As shown in Picture:
A.shows the up, down, left and right direction of the menu;
B. shows the enter/conrm button of the menu
2) Lens Auto Focus
shows lens focus (Near/Far) of the Auto focus lens, and (4) shows
Zoom(wide/tele) of the AUTO focus lens. When Keep pressing “Focus or ”
“Zoom” buttons, the lens will keep moving, only after “Focus or ” “Zoom”
button without pressing, the lens will focus automatically.
