FEATURES
Intensifier® Series HD-TVI 1080p 2MP Dome Camera
Wall/Ceiling Mount, UTC, 2BNC out for TVI & CVBS, Dual voltage
HT7250TM – 5~50mm motorized zoom focus lens, dark gray housing
SPECIFICATIONS
Image Sensor.................. 1/3” Progressive Scan CMOS, 2MP
Minimum Illumination....... 0.001 lux (Sens-up X32)
Effective Pixels................ 1984 (H) x 1105 (V)
Total Pixels...................... 2000 (H) x 1121 (V)
Scanning System............ Progressive
S/N Ratio......................... More than 50dB
Output Resolution............ 1920x1080 @ 30fps
Video Output.................... 1.0Vp-p / 75 Ohms
Electronic Shutter............ Auto / Manual (1/30 – 1/30,000 sec.)
Day / Night....................... Auto / Color / BW / External
Test Monitor Output......... CVBS (BNC out in Yellow)
Communication............... UTC (up the coax)
Power............................. 12VDC / 24VAC
Power Consumption........ 600mA max. (DC), 450mA max. (AC)
Operating Temperature.... -4° F – 122° F
Unit Dimensions.............. 3.97” (H) x 5.23” (Dia.)
Unit Weight...................... 3.3 lbs
Certifications.................... FCC, RoHS
Signal Distance............... Up to 1600 feet
(depending on coax quality)*
• Full HD resolution over coax (HD-TVI)
• Supports up to Full HD 1080p @ 30fps
• True WDR operation
• Superior low-light performance
• Amplify existing light with no distance limitation
• Presets: Outdoor, Low Light, Hallway, Lobby, Elevator, Indoor
• Built-in heater and anti-fog glass reduces condensation
• 3-axis for wall and ceiling mounting
• Chameleon Cover™: snaps on and can be painted to
match any décor!*
• Full OSD operation through on-board control and UTC (up the coax)
• Additional 960H analog output
• Signal distance up to 1600 feet*
• Vandal / tamper resistant
• IP67 compliant, weather resistant
• 12VDC & 24VAC dual voltage operation
• 5 year warranty
OSD MENU TREE
PRESET MODE
• OUTDOOR
• INDOOR
• LOW LIGHT
• LOBBY
• HALLWAY
• ELEVATOR
MAIN SETUP
EXPOSURE
• B/W
• EXTERN
• LOW • MIDDLE • HIGH
• SHARPNESS • GAMMA • MIRROR
• FLIP
DAY / NIGHT
COLOR
SPECO DNR
EXIT
• BRIGHTNESS
• SHUTTER
BACKLIGHT
• HLC• BLC
• WDR
• AUTO
• AWB • COLOR GAIN
• ACE • DEFOG
SYSTEM
• OUTPUT
• FREQ.
• IMAGE RANGE
• INTENSIFY
• AGC
• COLOR
• SHADING
IRIS
MOTION
• FRAME RATE
• LANGUAGE• COLOR BAR
• RESET
• CAM TITLE
• D-ZOOM
• PRIVACY
2-MOTOR
• COLOR SPACE
• COM.
OSD Joystick
Video Test (CVBS)
Right (Near)
Up (Zoom-In)
Down (Zoom-Out)
Left (Far)
DIMENSIONS
Bottom View
Side View
Optional Accessories
Unit : inch
INTCM1
(Pole/Corner Mount)
INTWM1
(Wall Mount)
White Cover
(Included)
Black Cover
(Optional)
