Side 1/2

T – Power over Ethernet (PoE) Repeater

Speco Technologies’ IPPOERPT is a PoE repeater that extends power and data an

additional 328’. A second unit can be used for a possible max distance of 980’,

eliminating the need for additional switches, hubs and expensive fiber installations.

The IPPOERPT is compliant with standard POE IEEE802.3af.

Features:

 Extends both power and data over 300’.

 Can use a second unit (not included) for a total transmission distance of 980’.

 No external power is required.

 Meets IEEE 802.3af POE standard.

 Auto-sensing to detect PoE or non-PoE devices.

 Supports 10/100/1000 BASE-T transmission rate.

 Built in LED status indicator.

 Plug and play for easy installation.

Installation View:

A single IPPOERPT itself provides 328’ of data and power, but the power capability

will drop with an additional receiver:

Panel View:

Max Device Power

Range with PoE switch

IPPOERPT Max. 2

IPPOERPT Max.

8.58W at 656’ 4.21W at 980’

328’

Recommended Cable:

Use CAT5e UTP/STP or CAT6 UTP cable

LED Indicators:

LED (Green) ON PSE send power

OFF PSE non-power

RJ45 (Yellow)

ON 1000 Mbps link

OFF

1000 Mbps unlink

FLASH Activity

RJ45 (Green)

ON 10/100 Mbps link

OFF 10/100 Mbps unlink

FLASH Activity

Specifications:

ITEM NO.

IPPOERPT

Power & Data Input/Output

RJ45

Data Link

Pin 1/2 3/6 4/5 7/8

Power Link

Pin 1/2 (+) 3/6 (-) End-Span

Transmission Range

2 pieces repeater up to 360 Meters

LED Indication

Power: Green, Data link: Yellow/Green

POE

IEEE 802.3af Standard, 48V 12.95W

Power Consumption

Non-load 1.1W (23mA) 1.44W (30mA) @ 10Mbps

1.92W (40mA) @

100/1000Mbps

Temperature

Operation: 32°F to 131°F, Storage:

-4°F to 185°F, Humidity: up to 95%

Dimensions L x W x H

2.6” x 4.3” x 1”

Weight

0.4 Lbs.

Speco Technologies is constantly developing and improving products.

We reserve the right to modify product design and specifications without notice and without incurring any obligation.

Speco Technologies 200 New Highway Amityville NY 11701 ● ● ● ● ● www.specotech.com

Rev. 03/31/20
