Introduction

Thank you for purchasing a StarTech.com DVI Signal

Extender. This product allows you to boost and

extend the length of DVI signals over a copper based

DVI cable by 12 meters at 1080p / UXGA (24 meters

in total extension).

Features

• Corrects signal error and extends DVI transmission

by 12 meters without degradation

• HDCP 1.1 compliant

• Plug and Play, easy to install

• DDC pass through ensures proper recognition of

the connected display

• Cascadable in multiple stages to achieve maximum

transmission distance

Before You Begin

System Requirements

• A DVI video Source

• Input and Output DVI cables

• A display with at least 1 DVI input

Basic Setup

Connecting the video source to the extender:

Connect the DVI cable running from your video

source to the DVI INPUT socket.

Connecting the extender to the display:

Insert a standard DVI cable into the DVI OUTPUT

port. Insert the opposite end of the cable into the DVI

input on your video display (PC Monitor, projector,

LCD or PDP display unit).

Powering the extender:

Connect the tip on the power adapter (provided) to

the port marked on the video extender.DC/5V 2A

Connect the opposite end to a wall outlet or other

suitable power source.

The red light located above the power input will illumi-

nate, indicating that your extender is functioning.

Accessories

DVIAEXT10

33 foot (10 meter) Active DVI Extension Cable

ZENDVI1

Cable ZEN 3.3 ft (1m) DVI Digital Video Cable

ZENDVI2

Cable ZEN 6.6 ft (2m) DVI Digital Video Cable

ZENDVI4

Cable ZEN 13.1 ft (4m) DVI Digital Video Cable

Specifications

HDCP Compliant HDTV DVI Extender

DVIHDCPEXT

Revised: 22 December 2005 (A)

Support, Warranty Information, and Regulatory Compliance Statement

If you ever need help with your product, visit and access our com-www.startech.com/support

prehensive selection of online tools, documentation, and downloads. This product is backed by a

one-year warranty. In addition, StarTech.com warrants its products against defects in materials

and workmanship for the periods noted, following the initial date of purchase. During this period,

the products may be returned for repair, or replacement with equivalent products at our discre-

tion. The warranty covers parts and labor costs only. StarTech.com does not warrant its products

from defects or damages arising from misuse, abuse, alteration, or normal wear and tear.

Limitation of Liability: In no event shall the liability of StarTech.com Ltd. and StarTech.com USA

LLP (or their officers, directors, employees or agents) for any damages (whether direct or indirect,

special, punitive, incidental, consequential, or otherwise), loss of profits, loss of business, or any

pecuniary loss, arising out of or related to the use of the product exceed the actual price paid for

the product. Some states do not allow the exclusion or limitation of incidental or consequential

damages. If such laws apply, the limitations or exclusions contained in this statement may not

apply to you.

FCC Compliance Statement: This equipment has been tested and found to comply with the lim-

its for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed

to provide reasonable protection against harmful interference in a residential installation. This

equipment generates, uses and can radiate radio frequency energy and, if not installed and used

in accordance with the instructions, may cause harmful interference to radio communications.

However, there is no guarantee that interference will not occur in a particular installation. If this

equipment does cause harmful interference to radio or television reception, which can be deter-

mined by turning the equipment off and on, the user is encouraged to try to correct the interfer-

ence by one or more of the following measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

• Connect the equipment into an outlet on a circuit different from that to which the receiver is con-

nected.

• Consult the dealer or an experienced radio/TV technician for help.

Video Input 1 x HDMI

Video Output 1 x HDMI

Dimensions (LxWxH) 105 x 76 x 30mm

Weight 1.35 lbs

Power DC 5V, 2A

Certification (Regulatory) FCC, CE

Produkt Specifikationer

Mærke:	StarTech.com
Kategori:	Splitter
Model:	DVIHDCPEXT
Maksimal opløsning:	1600 x 1200 pixel
Dimensioner (BxDxH):	76 x 105 x 30 mm
Stik:	DVI-D Dual Link F
DC indgang:	5V DC
Video porttype:	DVI
Antal videoporte:	1
