Quick Start Guide

Manual Revision: 09/06/2023

Product Design

Actual product may vary from photos

Front View

Rear View

Package Contents

• HDMI Splitter x 1

• Universal Power Adapter x 1

• Quick-Start Guide x 1

Requirements

Operating system requirements are subject to change. For the

latest requirements, please visit .www.startech.com/ST122HD202

Displays:

Displays are sold separately.

• HDMI Video Source Device x 1

• HDMI Displays x 2

Cables:

Cables are sold separately.

• HDMI Cables x 3

SKU #: ST122HD202

2-Port HDMI® Video Splitter - 4K 60Hz

Installation

Note: Before you begin the installation, ensure your HDMI source

device and each of the HDMI video displays are powered o.

1. Connect an , to the on the HDMI Cable HDMI Input Port HDMI

Splitter. Connect the other end of the in the HDMI Cable HDMI

Output Port on the . Video Source Device

2. Connect an , to the on the HDMI Cable HDMI Out 1 Port HDMI

Splitter. Connect the other end of the in the HDMI Cable HDMI

Input Port on the .Display

3. Repeat Steps 1 - 2 to connected a second display.

4. Connect the to the Universal Power Adapter DC 5V Power

Adapter Port on the . Connect the other end of Video Splitter

the to an .Universal Power Adapter AC Electrical Outlet

5. Turn on the .Video Source Device

6. Turn on the Displays

7. Verify that the video source is on the connected .Displays

EDID Switch

The features an HDMI Splitter Extended Display Identication

Data (EDID) Switch that allows you to use the EDID settings

from the display connected to the , or emulate HDMI Out 1 Port

standard EDID settings.

By default the EDID Switch is set to default (standard).

EDID Default Settings:

• 1920 x 1080 60HzResolution:

• 2 channel stereoAudio:

Using HDMI Out 1 Port EDID Settings

1. On the , change the from default to HDMI Splitter EDID Switch

display.

Note: To switch back to the Default EDID setting, switch from

display to default and follow Steps 2 - 3.

2. Disconnect the from the Universal Power Adapter AC Electrical

Outlet HDMI Splitter and then disconnect it from the .

3. Reconnect the Universal Power Adapter to the DC 5V Power

Adapter Port on the . Connect the other end of Video Splitter

the to an .Universal Power Adapter AC Electrical Outlet

For the latest information, specications, and support visit www.startech.com/ST122HD202.

Power

LED

Input

LED

Output

LEDs

EDID

Switch

HDMI Out

Port 2

HDMI Out

Port 1

HDMI In

Port

DC 5V

Port

Safety Measures

• Wiring terminations should not be made with the product and/or electric lines under power.

• Product installation and/or mounting should be completed by a certied professional as per

the local safety and building code guidelines.

• Cables (including power and charging cables) should be placed and routed to avoid creating

electric, tripping or safety hazards.

Mesures de sécurité

• Les terminaisons de câblâge ne doivent pas être eectuées lorsque le produit et/ou les câbles

électriques sont sous tension.

• Les câbles (y compris les câbles d’alimentation et de chargement) doivent être placés et

acheminés de façon à éviter tout risque électrique, de chute ou de sécurité

安全対策

• 電源が入っている状態の製品または電線の終端処理を行わないでください。

• ケーブル（電源ケーブルと充電ケーブルを含む）は、適切な配置と引き回しを行い、電気障害やつま

づきの危険性など、安全上のリスクを回避するようにしてください。

Misure di sicurezza

• I terminiali dei li elettrici non devono essere realizzate con il prodotto e/o le linee elettriche

sotto tensione.

• I cavi (inclusi i cavi di alimentazione e di ricarica) devono essere posizionati e stesi in modo da

evitare pericoli di inciampo, rischi di scosse elettriche o pericoli per la sicurezza.

Säkerhetsåtgärder

• Montering av kabelavslutningar får inte göras när produkten och/eller elledningarna är

strömförda.

• Kablar (inklusive elkablar och laddningskablar) ska dras och placeras på så sätt att risk för

snubblingsolyckor och andra olyckor kan undvikas.

FCC Compliance Statement

This equipment has been tested and found to comply with the limits for a Class B digital device,

pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection

against harmful interference in a residential installation. This equipment generates, uses and can

radiate radio frequency energy and, if not installed and used in accordance with the instructions,

may cause harmful interference to radio communications. However, there is no guarantee that

interference will not occur in a particular installation. If this equipment does cause harmful

interference to radio or television reception, which can be determined by turning the equipment

o and

on, the user is encouraged to try to correct the interference by one or more of the following

measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

• Connect the equipment into an outlet on a circuit dierent from that to which the receiver is

connected.

• Consult the dealer or an experienced radio/TV technician for help

This device complies with part 15 of the FCC Rules. Operation is subject to the following two

conditions:

(1) This device may not cause harmful interference, and (2) this device must accept any

interference received, including interference that may cause undesired operation. Changes or

modications not expressly approved by StarTech.com could void the user’s authority to operate

the equipment.

Industry Canada Statement

This Class B digital apparatus complies with Canadian ICES-003.

Cet appareil numérique de la classe [B] est conforme à la norme NMB-003 du Canada.

CAN ICES-3 (B)/NMB-3(B)

This device complies with Industry Canada licence-exempt RSS standard(s). Operation is subject to

the following two conditions:

(1) This device may not cause interference, and (2) This device must accept any interference,

including interference that may cause undesired operation of the device.

Use of Trademarks, Registered Trademarks, and other Protected Names and Symbols

This manual may make reference to trademarks, registered trademarks, and other protected

names and/or symbols of third-party companies not related in any way to StarTech.com.

Where they occur these references are for illustrative purposes only and do not represent an

endorsement of a product or service by StarTech.com, or an endorsement of the product(s)

to which this manual applies by the third-party company in question. StarTech.com hereby

acknowledges that all trademarks, registered trademarks, service marks, and other protected

names and/or symbols contained in this manual and related documents are the property of their

respective holders.

Technical Support

StarTech.com’s lifetime technical support is an integral part of our commitment to provide

industry-leading solutions. If you ever need help with your product, visit www.startech.com/

support and access our comprehensive selection of online tools, documentation, and downloads.

For the latest drivers/software, please visit www.startech.com/downloads

Warranty Information

This product is backed by a two-year warranty. StarTech.com warrants its products against defects

in materials and workmanship for the periods noted, following the initial date of purchase. During

this period, the products may be returned for repair, or replacement with equivalent products at

our discretion. The warranty covers parts and labor costs only. StarTech.com does not warrant its

products from defects or damages arising from misuse, abuse, alteration, or normal wear and tear.

Limitation of Liability

In no event shall the liability of StarTech.com Ltd. and StarTech.com USA LLP (or their ocers,

directors, employees or agents) for any damages (whether direct or indirect, special, punitive,

incidental, consequential, or otherwise), loss of prots, loss of business, or any pecuniary loss,

arising out of or related to the use of the product exceed the actual price paid for the product.

Some states do not allow the exclusion or limitation of incidental or consequential damages. If

such laws apply, the limitations or exclusions contained in this statement may not apply to you.

To view manuals, FAQs, videos, drivers, downloads, technical drawing, and more, visit www.startech.com/support.

Quick Start Guide

FR: fr.startech.com

DE: de.startech.com

ES: es.startech.com

NL: nl.startech.com

PT: pt.startech.com

IT: it.startech.com

JP: jp.startech.com

SKU #: ST122HD202

LED Indicators

LED Status

Power LED Lights when the HDMI Splitter is

connected to a power source.

Input LED Lights when an active video

source is connected to the

HDMI In Port

Output LEDs Lights when an active video

display is connected to the

HDMI Out Port

Produkt Specifikationer

Mærke:	StarTech.com
Kategori:	Splitter
Model:	ST122HD202
Vekselstrømsindgangsspænding:	100 - 240 V
Vægt:	159 g
Brugervejledning:	Ja
Produktfarve:	Sort
Pakkevægt:	402 g
Pakkedybde:	100 mm
Pakkebredde:	55 mm
Pakkehøjde:	16 mm
Understøttede videotilstande:	720p, 1080p
Opbevaringstemperatur (T-T):	-20 - 60 °C
Relativ luftfugtighed ved drift (H-H):	20 - 90 %
HDCP:	Ja
Strømforbrug (typisk):	5 W
Driftstemperatur (T-T):	0 - 40 °C
Maksimal opløsning:	3840 x 2160 pixel
Dimensioner (BxDxH):	56 x 100 x 17 mm
Understøttede grafikopløsninger:	1280 x 720 (HD 720), 1920 x 1080 (HD 1080), 1920 x 1200 (WUXGA), 2560 x 1600 (WQXGA), 3840 x 2160
Certificering:	CE, FCC
LED-indikatorer:	Ja
Udgangsspænding:	5 V
Udgangsstrøm:	1 A
AC-adapter inkluderet:	Ja
Harmoniseret systemkode (HS):	85176990
Bæredygtighedscertifikater:	RoHS
Strøm-LED:	Ja
Plug and play:	Ja
Indgangsstrøm:	0.2 A
HDMI-version:	2.0
Videoudgang:	2x HDMI
Video porttype:	HDMI
Antal videoporte:	2
Understøttede lydkanaler:	7.1
