• 1xHDMIVideoSplitter

• 1xPowerAdapter

• 1xInstallationGuide

• HDMIenableddisplaydevices(e.g.monitor,HDTV,etc)

• HDMIenabledvideosource(e.g.computer,PVR/DVR,

etc)

• AvailableACpoweroutlet

ManualRevision:12/02/2010

Forthemostup-to-dateinformation,pleasevisitwww.startech.com

1.Makesurealldisplaysandthevideosourcedeviceare

turnedoffbeforeinstalling.

2.ConnectanHDMIcable(notincluded)fromeachofthe

videodisplaydevices(e.g.monitor,HDTV,etc)tothe

numberedoutputHDMIconnectorsonthevideosplitter.

NOTE:Port1istheprimaryoutputsoEDIDinformation

willbetakenfromthere.Thecapabilitiesofthedisplayon

Port1willbeappliedtoallotherportssobecarefulnotto

exceedthecapabilitiesoftheotherdisplays.

3.IfconnectingaudioseparatelyfromHDMI,connect

speakerstothecorresponding3.5mmaudiooutputs.

4.ConnectanHDMIcable(notincluded)fromthevideo

sourcedevice(e.g.computer,PVR/DVR,etc)tothe

‘SOURCE’inputHDMIconnectoronthevideosplitter.

5.IfconnectingaudioseparatelyfromHDMI,connectthe

audiosourcetotheinput3.5mmaudioconnector.

6.Connecttheincludedpoweradaptertothevideo

splitter.

7.Turnonthedisplaydevices,followedbythevideo

source.Thevideooutputshouldbedisplayedonall

connecteddisplaydevices.

*actualproductmayvaryfromphotos

ST122HDMI2 ST124HDMI2

Number of Ports 24

Video Signal HighSpeedHDMI(HDMI1.3)

Connectors

1xHDMIfemale(input)

2xHDMIfemale(output)

1x3.5mmmini-jackAudio(input)

2x3.5mmmini-jackAudio(output)

1xDCPower

1xHDMIfemale(input)

4xHDMIfemale(output)

1x3.5mmmini-jackAudio(input)

4x3.5mmmini-jackAudio(output)

1xDCPower

LEDs 1xPower/SignalInput

2xSignalOutput

1xPower/SignalInput

4xSignalOutput

Maximum Video Resolution 1920x1200/1080p

Maximum Cable Distance 5m

Audio Support Yes

HDCP Support Yes

DDC Support Yes

Power Adapter 9~12VDC,1500mA,centerpositive

Enclosure Material Metal

Operating Temperature 0°C~40°C(32°F~104°F)

Storage Temperature -20°C~60°C(-4°F~140°F)

Humidity 0%~80%

Dimensions 180.0mmx80.0mmx19.0mm 220.0mmx135.0mmx44.0mm

Weight 500g 1074g
