StarTech.com ECREAD Manual

StarTech.com Hukommelseskortlæser ECREAD

Læs gratis den danske manual til StarTech.com ECREAD (2 sider) i kategorien Hukommelseskortlæser. Denne vejledning er vurderet som hjælpsom af 57 personer og har en gennemsnitlig bedømmelse på 5.0 stjerner ud af 29 anmeldelser. Har du et spørgsmål om StarTech.com ECREAD, eller vil du spørge andre brugere om produktet?

Download PDF

Side 1/2

ECREAD

ExpressCard Memory Card Reader

Introduction

Thank you for purchasing a StarTech.com ExpressCard Memory Card Reader. Providing convenient access to popular media/

memory cards from a notebook computer, this 12-in-1 media/memory card reader is an ideal selection for accessing data such as

digital photos, multimedia and more, while ensuring cost-effective operation.

Features

Installs into ExpressCard 34mm or 54mm slots•

Supports high speed and high capacity memory cards•

Hot swappable, plug and play operation•

USB 2.0 transfer rate up to 480 Mbps•

Package Contents

1 x 12-in-1 Card Reader•

1 x Instruction Manual•

Installation

Please note: It is advisable to remove all possible static discharge potential from any objects that the

ExpressCard may come in contact with before installation. This can be accomplished by touching a grounded

metal object, prior to insertion

Locate an unused ExpressCard slot on the host computer.1.

Insert ECREAD into the available ExpressCard slot. Since this card is hot-pluggable, this can be performed while the 2.

computer is on or off. Once the card has been inserted, ensure the computer is powered, to proceed with installation

Windows will detect that the card has been inserted, and will prompt for driver installation. Because Windows natively supports 3.

this device, there is no need for additional driver installation. Please follow the on-screen instructions to complete installation.

Once the driver has been installed, the operating system will notify you that your new hardware is ready for use.

Operation

In Microsoft® Windows

When the card reader is connected to the computer but contains no memory card, a removable disk icon with an assigned drive

letter will appear in My Computer. Once a card is inserted, the name of the removable disk will change accordingly based on the

media type.

To access the inserted media, simply click on the icon representing the drive location.

Please see reverse for further instruction and product speciﬁcations

Produkt Specifikationer

Mærke:	StarTech.com
Kategori:	Hukommelseskortlæser
Model:	ECREAD
Vægt:	16 g
Produktfarve:	Sort
Pakkevægt:	40 (tbc) g
Pakkedybde:	108 mm
Pakkebredde:	14 mm
Pakkehøjde:	160 mm
Kompatible hukommelseskort:	Memory Stick (MS), MS PRO, MMC, SD, xD
Dimensioner (BxDxH):	33 x 78 x 5 mm
Kompatible operativsystemer:	Windows 2000/ME/XP/Vista/Mac OSX
Intern:	Ja
Pakkelængde:	108.00 mm
