Side 1/2

• 1xICUSB1284INTadapter

• 1xLowProleBracket

• 1xDriverCD

• 1xInstallationGuide

• Computersystemwithavailable9-pin

internalUSBheader

• Computerchassiswithavailable

desktopexpansioncardslot

• Microsoft®Windows®2000/XP/Server

2003/Vista/Server2008R2/7(32/64-

bit),orApple®MacOS®X(10.6.x)

WARNING!Computerpartscanbeseverelydamagedbystaticelectricity.Besure

thatyouareproperlygroundedbeforeopeningyourcomputercase.StarTech.

comrecommendsthatyouwearananti-staticstrapwheninstallinganycomputer

component.Ifananti-staticstrapisunavailable,dischargeyourselfofanystatic

electricitybuild-upbytouchingalargegroundedmetalsurface(suchasthe

computercase)forseveralseconds.

1. Turnyourcomputeroffandanyperipheralsconnectedtothecomputer(i.e.

Printers,externalharddrives,etc.).Unplugthepowercablefromtherearofthe

powersupplyonthebackofthecomputeranddisconnectallperipheraldevices.

2. Removethecoverfromthecomputercase.Refertodocumentationforyour

computersystemfordetails.

3. Locateanopenexpansioncardslotontherearofthecomputercaseandremove

themetalcoverplate.

4. Placetheadapter’sexpansioncardbracketintotheopeningandfastenthe

brackettotherearofthecase.

NOTE: Ifinstallingintoasmallformfactorchassis,changethecard’sbracketfor

theincludedLowProlebracket.

5. Locatea9-pinUSBheaderconnectoronthemotherboardandplugintheIDC

connectoronthecable.TheIDCconnectoriskeyedtohelppreventincorrect

installation.Seesystemormotherboarddocumentationfordetails.

6. Placethecoverbackontothecomputercase.

7. Insertthepowercableintothesocketonthepowersupplyandreconnectallother

connectorsremovedinStep1.

Windows 2000/XP/Server 2003/Vista/Server 2008 R2/7

Nodriverinstallationisrequiredforthesupportedoperatingsystems,astheywill

automaticallyinstallaUSBPrintingport.Fromthemaindesktop,right-clickon

“MyComputer”(“Computer”inVista/7),thenselectManage.InthenewComputer

Managementwindow,selectDeviceManagerfromtheleftwindowpanel.

Underthe“UniversalSerialBusControllers”categoryshouldbeadevicecalled

“USBPrintingSupport”.

Warranty Information

Thisproductisbackedbyaoneyearwarranty.

Inaddition,StarTech.comwarrantsitsproductsagainstdefectsinmaterials

andworkmanshipfortheperiodsnoted,followingtheinitialdateofpurchase.Duringthisperiod,theproductsmaybereturnedforrepair,orreplacementwith

equivalentproductsatourdiscretion.Thewarrantycoverspartsandlaborcostsonly.StarTech.comdoesnotwarrantitsproductsfromdefectsordamagesarising

frommisuse,abuse,alteration,ornormalwearandtear.

Limitation of Liability

InnoeventshalltheliabilityofStarTech.comLtd.andStarTech.comUSALLP(ortheirofcers,directors,employeesoragents)foranydamages(whetherdirector

indirect,special,punitive,incidental,consequential,orotherwise),lossofprots,lossofbusiness,oranypecuniaryloss,arisingoutoforrelatedtotheuseofthe

productexceedtheactualpricepaidfortheproduct.Somestatesdonotallowtheexclusionorlimitationofincidentalorconsequentialdamages.Ifsuchlawsapply,

thelimitationsorexclusionscontainedinthisstatementmaynotapplytoyou.

ManualRevision:09/01/2010

Forthemostup-to-dateinformation,pleasevisitwww.startech.com

Bus Interface USB1.1

Form Factor Full/LowProle

Chipset ID ProlicPL-2305

Connectors 1xDB25female

1x9-pinIDCfemale

Supported Standard IEEE1284-1994

Operating Temperature 0°C~115°C(32°F~239°F)

Storage Temperature -55°C~150°C(-67°F~302°F)

Integrated Cable
