Instruction Manual

DE: Bedienungsanleitung - de.startech.com

FR: Guide de l'utilisateur - fr.startech.com

ES: Guía del usuario - es.startech.com

IT: Guida per l'uso - it.startech.com

NL: Gebruiksaanwijzing - nl.startech.com

PT: Guia do usuário - pt.startech.com

Manual Revision: 10/27/2011

For the most up-to-date information, please visit: www.startech.com

Packaging Contents

• 1xDisplayPortMultiMonitorAdapter

• 1xPowerAdapter

• 1xInstructionManual

System Requirements

• DisplayPortenabledcomputersystem/videocard

• DisplayPortenabledmonitor/displaydevice

• AvailableACelectricaloutlet

• DisplayPortcables(male/male)

SP123DP

Triple Head DisplayPort Multi Monitor Adapter

*actual product may vary from photos

Installation

1. Makesurethecomputersystemandmonitors/displaydevicesarepoweredo.

2. UsingastandardDisplayPortcable,connecttheMulti-MonitorAdaptertotheDisplayPortconnectorontheHostcomputersystem.

3. ConnecttheDisplayPortmonitor/displaydevice(s)intothenumberedconnectorsontheMulti-MonitorAdapter.Makesuretoconnect

themonitor/displaydevice(s)inorderfrom1to3(donotskipports).

4. ConnecttheincludedpoweradaptertotheMulti-MonitorAdapter.

5. Poweronthemonitor/displaydevice(s).

6. TurnontheHostcomputersystem.

7. TheoperatingsystemwillautomaticallydetecttheMulti-MonitorAdapterandeitherclone/mirror spanasingleimageonalldisplays,or 

animageacrossalldisplays.

8. Tochangethedisplaysetting/mode,changethedisplayresolutionviatheoperatingsystem’sdisplayproperties.Touse ,setClone Mode

thedisplayresolutiontoequalorlessthanthemaximumresolutionofthesmallestconnecteddisplay.Setthedisplayresolutionhigher,

touse .Span Mode

TheSP123DPTripleHead(DisplayPort)GraphicsExpansionModule

isanexternalmulti-monitorspanner/splitterthatletsyouaddup

to3displaystoadesktoporlaptopPC,fromasingleDisplayPort

output.

Outputasingle-modeDisplayPortsignaltospanacross3monitors

asasinglepanoramicdisplayatresolutionsupto3840x1200or

clone(mirror)yourprimarydisplay,usingthisdeviceasa3-port

DisplayPortvideosplitter.

Front View

Rear View

DisplayPort

connector (input)

DC Power connector DisplayPort connector (output)

FCC Compliance Statement

ThisequipmenthasbeentestedandfoundtocomplywiththelimitsforaClassBdigitaldevice,pursuanttopart15oftheFCCRules.Theselimitsaredesignedtoprovidereasonableprotectionagainst

harmfulinterferenceinaresidentialinstallation.Thisequipmentgenerates,usesandcanradiateradiofrequencyenergyand,ifnotinstalledandusedinaccordancewiththeinstructions,maycause

harmfulinterferencetoradiocommunications.However,thereisnoguaranteethatinterferencewillnotoccurinaparticularinstallation.Ifthisequipmentdoescauseharmfulinterferencetoradioor

televisionreception,whichcanbedeterminedbyturningtheequipmentoandon,theuserisencouragedtotrytocorrecttheinterferencebyoneormoreofthefollowingmeasures:

• Reorientorrelocatethereceivingantenna.

• Increasetheseparationbetweentheequipmentandreceiver.

• Connecttheequipmentintoanoutletonacircuitdierentfromthattowhichthereceiverisconnected.

• Consultthedealeroranexperiencedradio/TVtechnicianforhelp.

Use of Trademarks, Registered Trademarks, and other Protected Names and Symbols

This manual may make reference to trademarks, registered trademarks, and other protected names and/or symbols of third-party companies not related in any way to

StarTech.com.WheretheyoccurthesereferencesareforillustrativepurposesonlyanddonotrepresentanendorsementofaproductorservicebyStarTech.com,oranendorsementoftheproduct(s)

towhichthismanualappliesbythethird-partycompanyinquestion.Regardlessofanydirectacknowledgementelsewhereinthebodyofthisdocument,StarTech.comherebyacknowledgesthatall

trademarks,registeredtrademarks,servicemarks,andotherprotectednamesand/orsymbolscontainedinthismanualandrelateddocumentsarethepropertyoftheirrespectiveholders.

Technical Support

StarTech.com’slifetimetechnicalsupportisanintegralpartofourcommitmenttoprovideindustry-leadingsolutions.Ifyoueverneedhelpwithyourproduct,visitwww.startech.com/supportandaccess

ourcomprehensiveselectionofonlinetools,documentation,anddownloads.

Forthelatestdrivers/software,pleasevisitwww.startech.com/downloads

Warranty Information

Thisproductisbackedbyatwoyearwarranty.

Inaddition,StarTech.comwarrantsitsproductsagainstdefectsinmaterialsandworkmanshipfortheperiodsnoted,followingtheinitialdateofpurchase.Duringthisperiod,theproductsmaybereturned

forrepair,orreplacementwithequivalentproductsatourdiscretion.Thewarrantycoverspartsandlaborcostsonly.StarTech.comdoesnotwarrantitsproductsfromdefectsordamagesarisingfrom

misuse,abuse,alteration,ornormalwearandtear.

Limitation of Liability

InnoeventshalltheliabilityofStarTech.comLtd.andStarTech.comUSALLP(ortheirocers,directors,employeesoragents)foranydamages(whetherdirectorindirect,special,punitive,incidental,

consequential,orotherwise),lossofprots,lossofbusiness,oranypecuniaryloss,arisingoutoforrelatedtotheuseoftheproductexceedtheactualpricepaidfortheproduct.Somestatesdonotallow

theexclusionorlimitationofincidentalorconsequentialdamages.Ifsuchlawsapply,thelimitationsorexclusionscontainedinthisstatementmaynotapplytoyou.

Specications

Video Signal DisplayPort1.1a

Number of Ports 3

External Connectors 4xDisplayPortfemale

1xDCPower

LEDs 1xPower

Maximum Display

Resolution

OneDisplay:1920x1200

TwoDisplays:3840x1200

ThreeDisplays:3840x1024

HDCP Compliant Yes
