G-70x Operating Manual
Rev. B
p/n LIT-805720
Operating Manual
The Steadicam
®
G-70x Arm is the third release of
Tiffen’s G-Series arms. The revolutionary, patented Geo spring geometry optimizes
performance throughout its lifting range. It tames high/low arm travel with adjustable-
length crankshafts that dynamically rock the spring termination as the arm is boomed
up or down. Powered by coaxial titanium spring sets, the G-70x arm smoothly carries
any load from 13 to 70 pounds (5.8 to 32 kg).
The design criteria for the G-70x arm: light weight (10.8 lbs / 4.9 kg), user-
maintainable, and a 29 inch (73 cm) boom range. It has soft bumpers at each end of
travel so the arm can be boomed right to its limits without shot-disturbing clunks. The
G-70x also has a Ride control that adjusts the iso-elastic response of the arm.
Note: Iso-elasticity can be dened as the vertical bandwidth throughout which
lifting power closely approximates load.
Two more G-70x innovations: The arm posts are locked in place by a single lever,
so switching arm posts is quick and easy. This quick-change mechanism also has an
adjustable drag for the post’s rotation, from completely free to totally locked.
At the socket block end of the arm is a new, “kick back” link, which gets the arm
further out of the way as the sled crosses the operator’s body, and keeps the arm from
banging against the stops in normal operation.
The net result: the smoothest, best performing arm ever built, and all
parameters are user adjustable.
Tiffen Steadicam
2815 Winona Avenue
Burbank, CA 91504
818 843-4600 or 800 593-3331
818 843-8321 fax
Tiffen International Ltd.
Pinewood Studios
Pinewood Road
Iver Heath SL0 0NH
United Kingdom
44 870 1001220
44 1869 321766
Overview
Steadicam‚ G-70x™
Iso-Elastic Stabilizer Arm
tiffen.com/steadicam
steadicam.com
Email: techsupport@tiffen.com
The Tiffen Company
90 Oser Avenue
Hauppauge, New York 11788
631 273-2500 or 800 645-2522
631 273-2557 fax
