Computer\ Sensor Installation
Chest Belt
Functions
Battery Installation
Use a coin to rotate open the battery door, put a CR2032 battery into the
battery compartment, note: the positive pole (+) of the battery is upward,
after the battery is loaded, cover the battery door and tighten it. If LCD
show irregular figures, take out the battery and re-install it.
Speedometer Sensor
Mount the speedometer sensor (Transmitter) on the fork of the bike, on
the same side as the magnet and fix it on the fork with the attached zip
ties. Adjust the relative position of the magnet and the transmitter so that
the distance between them is 2mm. The transmitter works the best when
it is at the shortest distance from the handlebar,
Mounting Bracket
Attach the mounting shoe to the
handlebars using the included cable
ties.
Computer
Attach the computer to the mounting shoe by
sliding the unit until it snaps firmly into its postion.
To remove it, press the button on it and push from
the opposite direction.
To check for proper speed function and
sensor alignment, spin the front wheel
with computer in speed mode. Adjust
the position of sensor and magnet when
there is on weak reaction.
Remove the battery cover from the chest belt, install an CR2032 battery
with the positive (+) pole facing the battery cover and replace the cover.
Move to the left to unlock the cover and right to tight it.
Attaching the chest belt
Attach the belt with the battery cover facing the body.
Functional Description And Notes
Wireless transmission heartbeat frequency is 120KHz.
Attach the belt with the logo on the belt can be seen outside and placed
up right. If the logo looks upside down, it is mounted incorrectly.
The belt must be placed near the heart, close to the body. Any cloth or
other materials which will isolate conduction of body and belt are not
allowed.
In dry and cold environment, bad contraction may exist for the first few
minutes when putting on the belt, in this case please just wait for a few
minutes; users can also put a few drops of clean water or conductive gel
to wet the inside of the conductive material, which can help to realize
better and faster heartbeat transmission.
Parameter Settings
Setting (km/h) / (m/h)
Reinstall the battery or press and hold the Right button +
Left button for 3 seconds in any mode to enter the
parameter setting. The screen displays the Kilometer (KM)
setting, press the Right button to select Metric (KM) or
Imperial (MILE). Press the left button to confirm and enter
the wheel circumference setting.
Wheel Size Input
In the wheel circumference setting mode, the default value is 2155
millimeters. To adjust the value, press the right button. To enter the next
parameter setting directly, press the left button. Select the required
circumference based on the tire model of the bike, as indicated in the table
below. Press the right button to adjust the current digit. Press the left
button to confirm and enter the next digit selection. The input range of
wheel circumference is 0 to 9999mm. After setting, press the left button to
confirm and enter the initial total mileage setting.
Setting The Initial Value Of Odometer
In ODO mode, Press the LEFT button for 2 seconds to set the ODO value,
its default value is 0000.0. when one figure is flashing, press the RIGHT
button to adjust it and the LEFT button to confirm it, and start to set the
next figure. Press the LEFT button to enter into MAINTENANCE ALERT
SETTING MODE.
Setting Maintenance Alert
Setting Rider’s Weight
In the Rider’s Weight Setting mode, press the RIGHT
button to reset measuring unit, and press the LEFT button
to enter into the next mode. The default weight is
65kg(143lb), press the RIGHT button to adjust the flashing
weight number according to rider’s weight, press the LEFT
button to confirm and advance. Weight ranges: 0~299kg/0~699lb. Press
the LEFT button to enter into HEART RATE THRESHOLD SETTING MODE.
- SPD CURRENT SPEED
- TOT-ODO TOTAL ODOMETER
- TRPDIST TRIP DISTANCE
- MAXSPD MAXIMUM SPEED
- AVGSPD AVERAGE SPEED
- TRP TIME TRIP TIME
- CLOCK(12H/24H)
- STPWTCH STOPWATCH
- TMP TEMPERATURE
- MIN TMP
- MAX TMP
- SCAN
- COMPARATOR
- CALORIE
- FATBURN
- EXPERT(Fade menu)
- SETTING SPEED SCALE (KM/MILE)
- SETTING TIRE CIRCUMFERENCE
- SETTING THE INITAL VALUE OF ODOMETER/ODO
- MAINTENANCE ALERT
- REMOTE CONTROL
- AUTO BACKLIGHT
- CONSTANT ON BACKLIGHT
- AUTO ON/OFF
- DEEP SLEEP MODE
- P(CURRENT HEART RATE)
- AVE(AVERAGE HEART RATE)
- MAX(MAX HEART RATE)
Sensor
Magnet
Computer
Push the ziptie through the bottom
slot on the remote controller
and fix it on the handle
Cable Tie
In Maintenance Alert mode, the default Maintenance Alert
value is 200(KM/M), Press the RIGHT button, the first digit
will flash. Re-press the RIGHT Button to change the value,
and the LEFT button to advance to the next digit the value
ranges 000~800(KM/M).
Functions specifications when the ODO reaches the setted Maintenance
Alert value, the will appear on the screen to alert the rider, Press the
LEFT button for 5 seconds, it will disappear, and the value for Trip Distance\
Maxmum Speed\ Average Speed and Riding Time will be cleared. Press the
LEFT button to entre into the RIDER’S WEIGHT SETTING MODE.
Remote Control Installation
Push Into
CR2032Battery
Battery Cover
2mm
Close
Open
