Side 1/1
BCYCLE COMPUTER
（
（
（
（（ ）
）
）
））SD-531 (14Functions)
FUNCTIONS
- SPD CURRENT SPEED
- ODO ODOMETER （0.00 99999km/m)1～
- DST TRIP DISTANCE
- MXS MAXIMUM SPEED
- AVS AVERAGE SPEED
- TM ELAPSED TIME
- CLK CLOCK 12H/24H （ ）
- SCAN
- ” ” COMPARATOR “+ “－
- SETTING SPEED SCALE km/h,m/h （ ）
- SETTING TYRE CIRCUMFERENCE : (0mm ～
9999mm)
- SETTING THE LAST VALUE OF ODOMETER/ODO
- FREEZE FRAME MEMORY
- AUTO ON/OFF
Battery Installation
Remove the battery cover from the bottom of the computer by
using a flat blade screwdriver, install an AG13 battery with the
positive (+) pole facing the battery cover and replace the cover.
Should the LCD show irregular figures, take out the battery
and re-install it.
Speedometer Sensor
Attach the speedometer sensor
bracket to the left fork blade,
using the shims to adjust the
diameter, and using the cable
ties to tie it with the fork.
Position the sensor and magnet
as shows; make sure that the arc of the magnet intersects the
alignment mark on the sensor with 1mm clearance.
Mounting Shoe
Attach the mounting shoe with the
cable ties to the handlebar; adjust
the mounting shoe on the handlebar
with the shims to hold its position.
Sensor Wiring
Route the sensor wire up the fork
blade, using cable ties to secure it
at the bottom and crown to avoid it
hinder the movement of the front
wheel.
Computer
Attach the computer to the mounting shoe by sliding the unit
until it snaps firmly into its position. To remove it, press the
button on it in the opposite direction.To check for proper speed
function and sensor alignment, spin the front wheel with
computer in speed mode. Adjust the position of sensor and
magnet when there is no or weak reaction.
Wheel Size Input
‘2060’ appears on the screen when the battery has been
installed, with one figure flashing,choose the correct wheel
circumference from the table below. Press RIGHT button to
advance digits as needed and LEFT button to confirm and
advance. (The circumference ranges 0mm 9999mm),press ～
LEFT button to enter KM/M mode.
TIRE SIZE
CIRC
TIRE
SIZE
CIRC
700c x 38mm
2180 26” x 2.25” 2115
700c x 35mm
2168 26” x 2.1” 2095
700c x 32mm
2155 26” x 2.0” 2074
700c x 30mm
2145 26” x 1.9”/1.95” 2055
700c x 28mm
2136 26” x 1.75” 2035
700c x 25mm
2124 26” x 1.5” 1985
700c x 23mm
2105 26” x 1.25” 1953
700c x 20mm
2074 26” x 1.0” 1913
700c Tubulari
2130 24” x 1.9”/1.95” 1916
650c x 23mm
1990 20” x 1-1/4” 1618
650c x 20mm
1945 16” x 2.0” 1253
27” x 1-1/4”
2161 16” x 1.95” 1257
27” x 1-1/8”
2155 16” x 1.5” 1206
26” x 2.3” 2135
Setting km/h / m/h
（
（
（
（（ ）
）
）
）） （
（
（
（（ ）
）
）
））
Press the RIGHT button to choose km/h or
m/h. Press the LEFT button to enter the
CLOCK mode.
CLK Mode(12H/24H)
In CLOCK Mode, press the LEFT button
for 3 seconds to enter 12/24H selection.
Re-press the LEFT button for 12/24
exchanging. Press the RIGHT button to
enter Hour setting mode, when the figure
indicating HOUR start to flash, press the LEFT button to adjust
it.
Continue to press the RIGHT button to enter Minute setting
mode, when the figure indicating MINUTE start to flash, press
the LEFT button to adjust it and RIGHT button to confirm,
press the RIGHT button again to enter Mileage(ODO) mode.
Setting the Last value of Odometer
In ODO mode, press the LEFT button for 2 seconds to
set the ODO value, its initial value is 0000.0. when
one figure flashing, press RIGHT button to adjust it
and LEFT button to confirm it, and start to set the next
figure.(after re-install the battery, latest value can be
inputted according to the value exists before the
battery is re-installed).
Reset of Mileage Parameter
Press and hold both RIGHT and LEFT button simultaneously
for 3 seconds to clear the circumference and (km/m) setting.
The user need to reset the tyre circumference and (km/m), the
original ODO value and CLOCK will remain unaffected.
Speedometer
Speed is shown all the time on the
screen, its maximum reading is
99.9km/h (m/h), and it’s accurate to +/-
0.1km/h (m/h).
Speed Comparator
During riding , ‘ ’+ and ‘－’ indicates the current speed is
higher or lower than average speed(AVS) .
Odometer
In ODO mode , the total distance is
indicated on the screen, its mileage range
is 0.001～99999km(m). The display will
be back to 0 when value exceeds its
maximum limit, press the RIGHT button
to enter DST mode.
Trip Distance (DST)
In DST mode, the distance for one trip is
indicated on the bottom line. DST
ranges 0 9999km(m), when the value ～
exceed the range limit, it restarts from 0
automatically. Both the time and the
distance will be cleared when the time of one trip exceed the
range limits.
press the LEFT button for 5 seconds to clear the records of
DST,MXS,AVS,TM.
Press the RIGHT button to enter MXS mode.
Maximum Speed (MXS)
In MXS mode, maximum speed is
indicated on the bottom line. Press the
LEFT button for 5 seconds to clear the
records of MXS (DST,AVS,TM).
Press the RIGHT button to enter AVS
mode.
Average Speed
In AVS mode, average speed is indicated
on the bottom line. Press the LEFT
button for 5 seconds to clear the records
of AVS,DST,MXS,TM.
Press RIGHT button again to enter TM
mode.
Trip Time
In TM mode, trip time is indicated on the
bottom line.TM ranges 0 :00 :00 ～
99:59 :59. It will be back to 0 when value
exceed the limits.
Press the LEFT button for 5 seconds to
clear the records of TM, DST, MXS and AVS.
Press the RIGHT button to enter SCAN mode.
SCAN
In Scan mode , DST, MXS, AVS and TM
mode are indicated in turn every 4
seconds.
Press the RIGHT button to enter CLOCK
Mode.
Sleep Mode
If no signal has been inputted for 300 seconds, computer will
enter into Sleep Mode, CLK value remains. It will turn back to
the former mode with all the data collected then when any
signal is inputted or any button is pressed.
FREEZE FRAME MEMORY
Press the LEFT button in any time will enter into freeze frame
memory mode. Flashing TM data will appear on the screen.
Press the RIGHT button to view the records of DST,MXS,AVS
and TM.
Press the LEFT button to end it.
Buttons Instruction
Press the RIGHT button to choose any mode below : ODO,
DST, MXS, AVS, TM, SCAN（ 、DST MXS、AVS、TM） and
CLOCK. It’s unnecessary to press the LEFT button except
choosing the Freeze frame Memory mode.
In Freeze Frame Momery mode, press the RIGHT button,
several data will display, re-press LEFT button to turn back to
other modes.
Malfunctions and Problems
Malfunction
s
roblem
s
No speedometer Improper magnet/sensor alignment
Inaccurate value is
indicated Improper input, such as wheel
circumference.
Slow display
response
Temperature exceeds operating
limits(0 55 ). ℃～ ℃
Black display Temperature too high, or put in direct
sunlight for too long time, need to
take back to shadow for a period.
Weak display Poor battery contact or dead battery
Display shows
irregular figures Take out battery and reinstall it after
10 seconds.
Accessories
UnRegistered
UnRegistered
UnRegistered
UnRegistered
