USER’S MANUAL

Revision 1.0a

X11SAA

A2SAV/-2C-L/-L

A2SAV-V/-2C-LV/-LV

The information in this user’s manual has been carefully reviewed and is believed to be accurate. The vendor assumes

no responsibility for any inaccuracies that may be contained in this document, and makes no commitment to update

or to keep current the information in this manual, or to notify any person or organization of the updates. Please Note:

For the most up-to-date version of this manual, please see our website at www.supermicro.com.

Super Micro Computer, Inc. ("Supermicro") reserves the right to make changes to the product described in this manual

at any time and without notice. This product, including software and documentation, is the property of Supermicro and/

or its licensors, and is supplied only under a license. Any use or reproduction of this product is not allowed, except

as expressly permitted by the terms of said license.

IN NO EVENT WILL Super Micro Computer, Inc. BE LIABLE FOR DIRECT, INDIRECT, SPECIAL, INCIDENTAL,

SPECULATIVE OR CONSEQUENTIAL DAMAGES ARISING FROM THE USE OR INABILITY TO USE THIS PRODUCT

OR DOCUMENTATION, EVEN IF ADVISED OF THE POSSIBILITY OF SUCH DAMAGES. IN PARTICULAR, SUPER

MICRO COMPUTER, INC. SHALL NOT HAVE LIABILITY FOR ANY HARDWARE, SOFTWARE, OR DATA STORED

OR USED WITH THE PRODUCT, INCLUDING THE COSTS OF REPAIRING, REPLACING, INTEGRATING,

INSTALLING OR RECOVERING SUCH HARDWARE, SOFTWARE, OR DATA.

Any disputes arising between manufacturer and customer shall be governed by the laws of Santa Clara County in the

State of California, USA. The State of California, County of Santa Clara shall be the exclusive venue for the resolution

of any such disputes. Supermicro's total liability for all claims will not exceed the price paid for the hardware product.

FCC Statement: This equipment has been tested and found to comply with the limits for a Class A digital device

pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful

interference when the equipment is operated in a commercial environment. This equipment generates, uses, and can

radiate radio frequency energy and, if not installed and used in accordance with the manufacturer’s instruction manual,

may cause harmful interference with radio communications. Operation of this equipment in a residential area is likely

to cause harmful interference, in which case you will be required to correct the interference at your own expense.

California Best Management Practices Regulations for Perchlorate Materials: This Perchlorate warning applies only

to products containing CR (Manganese Dioxide) Lithium coin cells. “Perchlorate Material-special handling may apply.

See www.dtsc.ca.gov/hazardouswaste/perchlorate”.

WARNING: Handling of lead solder materials used in this product may expose you to lead, a

chemical known to the State of California to cause birth defects and other reproductive harm.

The products sold by Supermicro are not intended for and will not be used in life support systems, medical equipment,

nuclear facilities or systems, aircraft, aircraft devices, aircraft/emergency communication devices or other critical

systems whose failure to perform be reasonably expected to result in signicant injury or loss of life or catastrophic

property damage. Accordingly, Supermicro disclaims any and all liability, and should buyer use or sell such products

for use in such ultra-hazardous applications, it does so entirely at its own risk. Furthermore, buyer agrees to fully

indemnify, defend and hold Supermicro harmless for and against any and all claims, demands, actions, litigation, and

proceedings of any kind arising out of or related to such ultra-hazardous use or sale.

Manual Revision 1.0a

Release Date: October 16, 2019

Unless you request and receive written permission from Super Micro Computer, Inc., you may not copy any part of this

document. Information in this document is subject to change without notice. Other products and companies referred

to herein are trademarks or registered trademarks of their respective companies or mark holders.

Printed in the United States of America

Produkt Specifikationer

Mærke:	Supermicro
Kategori:	Bundkort
Model:	A2SAV
Bredde:	171.45 mm
Dybde:	171.45 mm
Antal HDMI-porte:	1
Ethernet LAN-porte (RJ-45):	2
Antal USB 2.0-porte:	3
Antal USB 3.2 Gen 1 (3.1 Gen 1) type-A-porte:	2
Ethernet LAN:	Ja
Processorkerner:	4
Driftstemperatur (T-T):	0 - 60 °C
Lyd-output kanaler:	- kanaler
Strømkilde type:	ATX
Processorfrekvens:	1.6 GHz
Maksimal intern hukommelse:	8 GB
On-board grafikkort:	Ja
Medfølgende software:	SuperDoctor 5, Watch Dog
Processorproducent:	Intel
Processormodel:	E3940
Antal DisplayPorts:	1
Antal VGA-porte (D-sub):	1
Ethernet-grænsefladetype:	Gigabit Ethernet
Komponent til:	PC
Grafikadapter:	HD Graphics
Perifere (Molex) strømstik (4-pin):	1
Processor sokkel:	BGA 1296
Kompatibel processor serie:	Intel Atom®
Bundkort chipset familie:	Intel
Understøttede hukommelsestyper:	DDR3-SDRAM
Antal hukommelsesstik:	1
Hukommelses slots type:	SO-DIMM
Understøttede hukommelsesclock-hastigheder:	1333,1600,1866 MHz
Ikke-bufferet hukommelse:	Ja
Antal M.2 (M) slots:	1
Antal SATA III-stik:	6
LAN Kontroller:	Intel® I210-AT
USB 2.0-stik:	4
Antal COM-stik:	2
ATX strømstrik (24 stikben):	Ja
Indbrudsttik til kabinet:	Ja
Antal kabinetventilatorstik:	2
Motherboard form faktor:	mini ITX
Understøttede lagerdrev brugerflader:	SATA III
BIOS-type:	UEFI
BIOS-hukommelsesstørrelse:	64 Mbit
ACPI-version:	5.0
Hukommelsesspænding:	1.35, 1.5 V
Maksimalt antal SMP-processorer:	1
Antal COM-porte:	1
PC sundhedsovervågning:	CPU, FAN, LED, Temperature, Voltage
Mini PCI ekspres slots:	1
Understøttede hukommelsesmodulkapaciteter:	2GB, 4GB, 8GB
Processor, termisk ydeevne (maks.):	9.5 W
PCI Ekspres x8 (Gen 2.x) slots:	1
Antal integrerede Displayporte (eDP):	1
