Supermicro MBD-X8DTL-I-O Manual

Supermicro Bundkort MBD-X8DTL-I-O

Læs gratis den danske manual til Supermicro MBD-X8DTL-I-O (97 sider) i kategorien Bundkort. Denne vejledning er vurderet som hjælpsom af 4 personer og har en gennemsnitlig bedømmelse på 4.6 stjerner ud af 2.5 anmeldelser. Har du et spørgsmål om Supermicro MBD-X8DTL-I-O, eller vil du spørge andre brugere om produktet?

Download PDF

Side 1/97

X8DTL-3

X8DTL-i

USER’S MANUAL

Revision 1.1b

X8DTL-3F

X8DTL-iF

The information in this User’s Manual has been carefully reviewed and is believed to be accurate.

The vendor assumes no responsibility for any inaccuracies that may be contained in this document,

makes no commitment to update or to keep current the information in this manual, or to notify any

person or organization of the updates. Please Note: For the most up-to-date version of this

manual, please see our web site at www.supermicro.com.

Super Micro Computer, Inc. ("Supermicro") reserves the right to make changes to the product

described in this manual at any time and without notice. This product, including software and docu-

mentation, is the property of Supermicro and/or its licensors, and is supplied only under a license.

Any use or reproduction of this product is not allowed, except as expressly permitted by the terms

of said license.

IN NO EVENT WILL SUPERMICRO BE LIABLE FOR DIRECT, INDIRECT, SPECIAL, INCIDENTAL,

SPECULATIVE OR CONSEQUENTIAL DAMAGES ARISING FROM THE USE OR INABILITY TO

USE THIS PRODUCT OR DOCUMENTATION, EVEN IF ADVISED OF THE POSSIBILITY OF

SUCH DAMAGES. IN PARTICULAR, SUPERMICRO SHALL NOT HAVE LIABILITY FOR ANY

HARDWARE, SOFTWARE, OR DATA STORED OR USED WITH THE PRODUCT, INCLUDING THE

COSTS OF REPAIRING, REPLACING, INTEGRATING, INSTALLING OR RECOVERING SUCH

HARDWARE, SOFTWARE, OR DATA.

Any disputes arising between manufacturer and customer shall be governed by the laws of Santa

Clara County in the State of California, USA. The State of California, County of Santa Clara shall

be the exclusive venue for the resolution of any such disputes. Super Micro's total liability for all

claims will not exceed the price paid for the hardware product.

FCC Statement: This equipment has been tested and found to comply with the limits for a Class

A digital device pursuant to Part 15 of the FCC Rules. These limits are designed to provide

reasonable protection against harmful interference when the equipment is operated in a commercial

environment. This equipment generates, uses, and can radiate radio frequency energy and, if not

installed and used in accordance with the manufacturer’s instruction manual, may cause harmful

interference with radio communications. Operation of this equipment in a residential area is likely

to cause harmful interference, in which case you will be required to correct the interference at your

own expense.

California Best Management Practices Regulations for Perchlorate Materials: This Perchlorate

warning applies only to products containing CR (Manganese Dioxide) Lithium coin cells. “Perchlorate

Material-special handling may apply. See www.dtsc.ca.gov/hazardouswaste/perchlorate”

WARNING: Handling of lead solder materials used in this

product may expose you to lead, a chemical known to

the State of California to cause birth defects and other

reproductive harm.

Manual Revision 1.1b

Release Date: April 13, 2010

Unless you request and receive written permission from Super Micro Computer, Inc., you may not

copy any part of this document.

Information in this document is subject to change without notice. Other products and companies

referred to herein are trademarks or registered trademarks of their respective companies or mark

holders.

Printed in the United States of America

Produkt Specifikationer

Mærke:	Supermicro
Kategori:	Bundkort
Model:	MBD-X8DTL-I-O
Bredde:	305 mm
Dybde:	254 mm
Wi-Fi:	Ingen
Opbevaringstemperatur (T-T):	-40 - 70 °C
Relativ luftfugtighed ved drift (H-H):	8 - 90 %
Relativ luftfugtighed ved opbevaring (H-H):	5 - 95 %
Ethernet LAN-porte (RJ-45):	2
Antal USB 2.0-porte:	2
Ethernet LAN:	Ja
Driftstemperatur (T-T):	10 - 35 °C
Bæredygtighedscertifikater:	RoHS
Maksimal intern hukommelse:	48 GB
On-board grafikkort, model:	Matrox G200eW
On-board grafikkort:	Ja
Processorproducent:	Intel
Antal VGA-porte (D-sub):	1
Ethernet-grænsefladetype:	Gigabit Ethernet
Komponent til:	Server
Antal serielle porte:	1
Antal PS/2-porte:	2
Processor sokkel:	Socket B (LGA 1366)
Understøtter RAID:	Ja
Understøttelse af parallel behandlingsteknologi:	Ikke understøttet
Bundkort chipsæt:	Intel® 5500
Understøttede hukommelsestyper:	DDR3-SDRAM
Understøttede hukommelsesclock-hastigheder:	800,1066,1333 MHz
LAN Kontroller:	Intel® 82574L
USB 2.0-stik:	3
Antal SATA II stik:	6
Motherboard form faktor:	ATX
Understøttede lagerdrev brugerflader:	SATA III
BIOS-type:	AMI
BIOS-hukommelsesstørrelse:	64 Mbit
ACPI-version:	3.0
Wake-on-LAN klar:	Ja
RAID-niveauer:	1, 5,10
Antal understøttede processorer:	2
Hukommelsesspænding:	1.35, 1.5 V
PCI-slots:	2
PCI Ekspres x4 slots:	1
Antal DIMM-slots:	6
Understøttet RDIMM-clockhastigheder:	800,1066,1333 MHz
Understøttet DIMM modul kapaciteter:	16GB, 1GB, 2GB, 4GB, 8GB
Maksimal RDIMM hukommelse:	96 GB
Intel® Xeon serie:	E5500, E5600, L5500, L5600, W5500, X5500, X5600
Understøttelse af Intelligent Platform Management Interface (IPMI):	Ja
Understøttet UDIMM-clockhastigheder:	800,1066,1333 MHz
Maksimal UDIMM hukommelse:	24 GB
On-board grafikkort, hukommelse:	16 MB
Antal understøttede processor cores:	4, 6
PCI Ekspres x4 (Gen 2.x) slots:	1
PCI Ekspres x8 (Gen 2.x) slots:	2
Understøttet RDIMM modul kapacitet:	16GB, 1GB, 2GB, 4GB, 8GB
Understøttet QPI:	6.4 GT/s
