SuperServer E403-9D-4C/8CN/12C/14C/14CN/16C-FN13TP Quick Reference Guide

http://www.supermicro.com MNL-2208-QRG

Rev. 1.0

Pl ndlast Haic es

Installing

Hard Drives

The hard drive cage must be removed

from the chassis before installing the

hard drives.

Caution

Mounting the Chassis on the Wall

The CSE-E403iF supports up to three PCI-E slots. These slots are installed on a riser car and must be installed into the system to provide expansion capability.

Components of the Expansion Card Module

Accessing the Main System

For more information go to: http://www.supermicro.com/support

Always be sure all power supplies for this system have the same

power output. If mixed power supplies are installed, the system

will not operate.

IMPORTANT: See installation instructions and safety warning

before connecting system to power supply.

http://www.supermicro.com/about/policies/safety_information.cfm



! SAFETY INFORMATION

To reduce risk of electric shock/damage to equipment, disconnect

power from server by disconnecting all power cords from electrical

outlets.

If any CPU socket empty, install protective plastic CPU cap.



! WARNING:



! WARNING:

Please clean the dust filters regularly

Attach the three wall mount

brackets to the chassis using

the ten M4xL4 screws.

The mounting bracket along

the I/O panel is pre-

attached.

After disconnecting power, flip open the fan cover, remove the screw that has been exposed. Slightly slide the system cover towards the fans.

Lift both segments of the top cover off the chassis.

1. Power down the system and remove the AC power cord and the chassis cover.

2. Remove the screw as shown above and set aside.

3. Pull the locking lever up to release the expansion card module.

4. Pull the expansion card module upward with the aid of the plastic handle.

Please refer to user manual for

more information.

Expansion Card

Module

Remove this

screw

Locking Lever

Plastic Handle

Expansion Card

Module

Expansion Card

(optional)

Press the latch

Accessing the System

Installing or Replacing the Riser Cards and Fans

Front View and Features

Control Panel

Chassis

CSE-E403iF

Processors

Socket Type

Intel

Xeon

D-2123IT, Intel

Xeon

D-2146NT, Intel

Xeon

D-2163IT, Intel

Xeon

D-2173IT,

Intel

Xeon

D-2177NT, and Intel

Xeon

D-2183IT

FCBGA2518

Memory

Chipset

Supports up to 256GB of ECC/non ECC RDIMM or 512GB of ECC LRDIMM DDR4 memory with

speeds of up to 2667MHz (D-2177NT) in four DIMM slots

System on Chip

Expansion Slots

Storage Drives

Two PCI-E 3.0 p1-x16 or two PCI-E 3.0 p1-x8 + one PCI-E 3.0 p1-x16 (FH3/4L) slots

One M.2 M-Key 2280/22110, One M.2 B-Key 3042, One M.2 E-Key 2230

Four internal SATA3 2.5" drive bays

Input/Output

Power

600W AC multi-output PFC Gold Certified power supply

Cooling

Three 80x80mm PWM redundant fans

Dimensions

Compact Box 2.5U (WxHxD) 10.5 x 4.3 x 16 in. (267 x 109 x 406 mm)

Network

Four SATA3 (6Gbps) ports supporting RAID 0, 1, 5, 10

USB: two USB 3.0 ports (front), two USB 2.0 ports (front)

Serial Port: one COM via RJ45

Video: one VGA port

Two RJ45 GbE LAN ports, nine RJ45 10GbE LAN ports, two 10G SFP+ LAN ports, and one RJ45

dedicated IPMI LAN port

System FeaturesBoard Layout

Item Description

1 Power Input

2 USB ports

3 PCI Slots

4 Ground

5 I/O Front Panel

UID

7 VGA Port

8 Control Panel

Features

Power button

Reset Button

Power LED

HDD LED

NIC LED

Information LED

Item

7 Overheat LED

Description

The main power switch applies or removes

primary power from the power supply to the

server but maintains standby power.

System reset button

Indicates power is being supplied to the

system power supply units.

Indicates hard disk drive activity when flashing.

Indicates network activity on the LAN when

flashing.

Alerts operator to several states, as noted in

the table on the next page.

If this indicator is continuously on and red, an

overheat condition has occurred.

Status Description

Information LED

Blinking red (1Hz)

Blinking red (0.25Hz)

Fan failure. Check for an inoperative fan.

Power failure. Check for a non-operational power

RESET

1 2 3

CMOS Clear

Trusted Platform Module (TPM)/Port 80

TPM Enable/Disable

4-pin HDD Power

SATA3.0 Ports

CPU

Power LED

Unit Identifier Switch

UID LED

10G SFP+ / 10G LAN / 1G LAN Ports (from I350)

Software-Defined Pins (For I350 LAN2)

1G LAN Ports(from I350)

1G LAN Ports(from I210) / Dedicated IPMI LAN Port

COM1/USB3.1

LAN JBMActivity LED

Disable Dedicated IPMI/Shared LAN

M.2 Slot E-Key 2230 (USB2.0 / PCI-E x1)

SATA3.0

M.2 Slot M-Key 2280/22110 (SATA3.0 / PCI-E x4)

RAID Key

SATA DOM Power

12V 8-pin DC Power

24-pin ATX Power

Standby Power

Disable IPMI Shared LAN

M.2 SMBus Enable/Disable

Description

Overheat/Power Fail/Fan Fail LED

Serial Link General Purpose I/O

DIMMA1~DIMMB1

Onboard Battery

No.

DIMMD1~DIMME1

BMC

System Management Bus (for IPMI only)

WIO

M.2 Slot B-Key 2242/3042, PCI-E 3.0 X2 / S-SATA4

VGA

Non-volatile Memory (NVMe) I2C

WIO

WIO, PCI-E X16+X16

FAN4

FAN3

FAN1

FAN2

JD1

JF1

FANA

JSD1

JIPMB1

JNVI2C1

JTGLED2

JTGLED1

JBT1

JTPM1

JPI2C1

JPWR1

JBM1

JBM2

JLANLED1

JLANLED3

S-SGPIO1

JLANLED2

JSTBY1

LEDM1

LEDT4 LEDT2

JPG1

JVRM1 JPL2 JPL3

JPT1

JSMB1 JI2C1 JI2C2 JWD1 JPME2

JPUSB1

JPL1

MH1

MH3

MH7

MH2

MH4

MH6

MH5

BT1

JMD2_SRW1

JMD1_SRW1

LED3

LED1

JMD3_SRW1

LED2

LEDT3

S S A3AT

JSIM1

JGP1

JPV1

S-S A1AT

JVGA1

COM2

JRK1

S-S A0AT

JMD1: M.2-H

JSDP3

JSDP2

JSDP1

S-S A2AT

JPW1

LEDT1

PRESS FIT

C A

CA CA

DESIGNED IN USA

BAR CODE

X11SDW-4C-TP13F

REV:1.01

LAN 1

COM1

USB 4/5

USB 2/3

USB 0/1

2-3:DISABLE

JPT1:TPM

1-2:ENABLE

: PCI-E X16+X16

JSXB1C

JSXB1B

JSXB1A

CPU

JPL3:

LAN 6/7/8/9

1-2:ENABLE

2-3:DISABLE

JPL2:

2-3:DISABLE

LAN 2/3/4/5

1-2:ENABLE

PCI-E 3.0 X1

JMD3:M.2-P

JMD2:M.2-H

PCI-E 3.0 X2 / S-S A4AT

UID

LAN 2/3/4/5/6/7/8/9

PCI-E 3.0 X4 / I-S A4AT

LAN 12/13

LAN 10/11

IPMI_LAN

LED

HDD

NIC1

PWR

RST

NIC2

LED

PWR

JF1:

JD1:

4-7:SPEAKER

3:PWR LED

DIMMA1

DIMMB1

DIMME1

DIMMD1

JL1

JPH1

6 8

262728 21

222425

8 9 10 121 2 3 4 5 6 7 11

Produkt Specifikationer

Mærke:	Supermicro
Kategori:	Ikke kategoriseret
Model:	SuperServer E403-9D-16C-FN13TP
Bredde:	267 mm
Dybde:	406 mm
Højde:	109 mm
Vægt:	7700 g
Produktfarve:	Sort
Opbevaringstemperatur (T-T):	-40 - 70 °C
Relativ luftfugtighed ved drift (H-H):	8 - 90 %
Relativ luftfugtighed ved opbevaring (H-H):	5 - 95 %
Antal USB 2.0-porte:	2
Antal USB 3.2 Gen 1 (3.1 Gen 1) type-A-porte:	2
Ethernet LAN:	Ja
Processorkerner:	16
Driftstemperatur (T-T):	10 - 40 °C
Intern hukommelse:	- GB
Operativsystem installeret:	Ingen
Processorfrekvens:	2.2 GHz
Processorserie:	Intel® Xeon®
Processor boost frekvens:	3 GHz
Processor-cache:	22 MB
Intern hukommelsestype:	DDR4-SDRAM
Maksimal intern hukommelse:	512 GB
Samlet lagringskapacitet:	- GB
Hukommelsesstik:	4
Processormodel:	D-2183IT
Antal VGA-porte (D-sub):	1
Ethernet-grænsefladetype:	10 Gigabit Ethernet
Optisk drevtype:	Ingen
Antal installerede processorer:	1
HDD-størrelse:	- "
Strømforsyning:	600 W
Thermal Design Power (TDP):	100 W
Maksimal lagerkapacitet:	- TB
Fejlkorrigerende kode:	Ja
Antal SATA III-stik:	4
BIOS-type:	AMI
PCI Ekspres x16 (Gen 3.x) slots:	2
Antal af hovedstrømforsyninger:	1
PCI Ekspres x8 (Gen 3.x) slots:	3
Understøttelse af Intelligent Platform Management Interface (IPMI):	Ja
