SuperServer 6029P-E1CR24H/E1CR24L Quick Reference Guide
CPU Installation
Removing the 6029P-E1CR24H/E1CR24L Drive Trays
S A Drive Installation Fans InstallationAT
CPU2 SLOT1 PCI-E 3.0 x8
CPU2 SLOT2/SLOT3 PCI-E 3.0 x16
CPU2 slot
P2-DIMM slots A1~C1 & A2~C2
Descrip iot nNo. t nNo. Descrip io
1
2
3
4
5P2-DIMM slots D1~F1 & D2~F2
6
CPU1 SIOM PCI-E 3.0 x16
CPU1 slot
7
P1-DIMM slots D1~F1 & D2~F2
P1-NVMe0-3
P1-DIMM slots A1~C1 & A2~C2
8
9
11 CPU1 JMEZZ1/JMEZZ2 PCI-E
12 CMOS Clear Button
13 I-SATA2/I-SATA3
10
Memory SupportBoard Layout Front View
Rear View
SIOM Installation
D riptionesc
No.
1
2
3
4
5
Power Supply Module
3.5" Drive Bays
I/O Ports
PCI Slots
Rack Ear Brackets
Power Button
Reset Button
Power LED
HDD LED
NIC2 LED
NIC1 LED
Power Fail LED
Universal Information LED
D ripesc tion
No. No.
1
2
3
4
D ripesc tion
5
6
7
8
Caution
SAFETY INFORMATION
IMPORTANT: See installation instructions and safety warning before
connecting system to power supply.
http://www.supermicro.com/about/policies/safety_information.cfm
WARNING:
To reduce risk of electric shock/damage to equipment, disconnect power
from server by disconnecting all power cords from electrical outlets.
If any CPU socket empty, install protective plastic CPU cap
WARNING:
Always be sure all power supplies for this system have the same power
output. If mixed power supplies are installed, the system will not operate.
For more information go to : http://www.supermicro.com/support
!
!
!
After removing the screws, lift the Processor
Heatsink Module off the CPU socket.
Removing the Processor
Heatsink Module (PHM) from the
Motherboard
Remove the dust cover from the CPU socket, exposing
the socket and socket pins as shown on the illustration
below.
Note: Do not touch the socket pins to avoid damaging
them, causing the CPU to malfunction.
12
3
4
Removing the screws in
the sequence of 4, 3, 2, 1
Printed Triangle on Motherboard
CPU Socket
Processor Carrier Assembly (with CPU mounted
on the Processor Clip)
CPU (Upside Down)
w/CPU LGA Lands up
On Locations of (C, D), the notches
snap onto the heat sink’s
mounting holes
On Locations (A, B), the notches
snap onto the heatsink’s sides
Heatsink
(Upside Down)
CPU and Processor Clip
Attaching the Processor Carrier Assembly to the Heatsink to Form the Processor Heatsink
Module (PHM)
Removing the Dust Cover from
the CPU Socket
Installing the Processor Heatsink Module (PHM)
Dust Cover
CPU Socket
Remove the dust cover from the CPU socket, exposing the
socket and socket pins as shown on the illustration below.
No : te
Do not touch the socket pins to avoid damaging
them, causing the CPU to malfunction.
Note: Do not use excessive force when tightening the screws to avoid
damaging the LGA lands and the processor.
Mounting the Processor Heatsink Module into
the CPU socket (on the motherboard)
Align Notch C of the
CPU and Notch C of
the Processor Clip
CPU/Heatsink Package
(Upside Down)
Align Notch B of the
CPU and Notch B of
the Processor Clip A
B
C
Allow carrier to
latch onto CPU
Allow carrier to
latch onto CPU
Processor Carrier Assembly
B
C
B
C
Pin 1
A
A
Align CPU Pin 1
Socket Pins
Remove the plastic protective
cover from the CPU socket.
Do not touch or bend
the socket pins.
Triangle on the CPU
Triangle on the
Processor Carrier
a
b
A
B
d
c
D
C
Make sure Mounting
Notches snap into place
A
B
D
C
Small Guiding Post
Oval C (Large Guiding Post)
Printed Triangle
12
3
4
T30 Torx Driver
Use a torque of 12lbf-in
Oval D
Tighten the screws in the
sequence of 1, 2, 3, 4 (top 3 quarter view)
Remove the small section of the chassis rear to allow access to the
motherboard SIOM slot.
Release Tab
Re ease ttl Bu on
Installing/Removing Fans
Press the fan release tab to lift the failed fan
from the chassis and pull it completely out
of the chassis
CPU1: P1-DIMMB1/P1-DIMMB2/P1-DIMMA1/P1-DIMMA2/P1-DIMMD2/P1-DIMMD1/
P1-DIMME2/P1-DIMME1
CPU2: P2-DIMMB1/P2-DIMMB2/P2-DIMMA1/P2-DIMMA2/P2-DIMMD2/P2-DIMMD1/
P2-DIMME2/P2-DIMME1
Memory Population Table
When 2 CPUs are used
Memory Population Sequence
CPU1: P1-DIMMA1/P1-DIMMD1
CPU2: P2-DIMMA1/P2-DIMMD1
CPU1: P1-DIMMC1/P1-DIMMB1/P1-DIMMA1
CPU2: P2-DIMMC1/P2-DIMMB1/P2-DIMMA1
CPU1: P1-DIMMB1/P1-DIMMA1/P1-DIMMD1/P1-DIMME1
CPU2: P2-DIMMB1/P2-DIMMA1/P2-DIMMD1/P2-DIMME1
CPU1: P1-DIMMC1/P1-DIMMB1/P1-DIMMA1/P1-DIMMD1/P1-DIMME1/P1-DIMMF1
CPU2: P2-DIMMB1/P2-DIMMA1/P2-DIMMD1/P2-DIMME1
CPU1: P1-DIMMC1/P1-DIMMB1/P1-DIMMA1/P1-DIMMD1/P1-DIMME1/P1-DIMMF1
CPU2: P2-DIMMC1/P2-DIMMB1/P2-DIMMA1/P2-DIMMD1/P2-DIMME1/P2-DIMMF1
CPU1: P1-DIMMB1/P1-DIMMB2/P1-DIMMA1/P1-DIMMA2/P1-DIMMD2/P1-DIMMD1/
P1-DIMME2/P1-DIMME1
CPU2: P2-DIMMC1/P2-DIMMB1/P2-DIMMA1/P2-DIMMD1/P2-DIMME1/P2-DIMMF1
CPU1: P1-DIMMC1/P1-DIMMC2/P1-DIMMB1/P1-DIMMB2/P1-DIMMA1/P1-DIMMA2/
P1-DIMMD2/P1-DIMMD1/P1-DIMME2/P1-DIMME1/P1-DIMMF2/P1-DIMMF1
CPU2: P2-DIMMB1/P2-DIMMB2/P2-DIMMA1/P2-DIMMA2/P2-DIMMD2/P2-DIMMD1/
P2-DIMME2/P2-DIMME1
CPU1: P1-DIMMC1/P1-DIMMC2/P1-DIMMB1/P1-DIMMB2/P1-DIMMA1/P1-DIMMA2/
P1-DIMMD2/P1-DIMMD1/P1-DIMME2/P1-DIMME1/P1-DIMMF2/P1-DIMMF1
CPU2: P2-DIMMC1/P2-DIMMB1/P2-DIMMA1/P2-DIMMD1/P2-DIMME1/P2-DIMMF1
CPU1: P1-DIMMC1/P1-DIMMC2/P1-DIMMB1/P1-DIMMB2/P1-DIMMA1/P1-DIMMA2/
P1-DIMMD2/P1-DIMMD1/P1-DIMME2/P1-DIMME1/P1-DIMMF1
CPU2: P2-DIMMC1/P2-DIMMC2/P2-DIMMB1/P2-DIMMB2/P2-DIMMA1/P2-DIMMA2/
P2-DIMMD2/P2-DIMMD1/P2-DIMME2/P2-DIMME1/P2-DIMMF1
CPU1: P1-DIMMC1/P1-DIMMC2/P1-DIMMB1/P1-DIMMB2/P1-DIMMA1/P1-DIMMA2/
P1-DIMMD2/P1-DIMMD1/P1-DIMME2/P1-DIMME1/P1-DIMMF2/P1-DIMMF1
CPU2: P2-DIMMC1/P2-DIMMC2/P2-DIMMB1/P2-DIMMB2/P2-DIMMA1/P2-DIMMA2/
P2-DIMMD2/P2-DIMMD1/P2-DIMME2/P2-DIMME1/P2-DIMMF2/P2-DIMMF1
CPU1: P1-DIMMA1
CPU2: P2-DIMMA1
2 CPUs & 2 DIMMs
2 CPUs & 4 DIMMs
2 CPUs & 6 DIMMs
2 CPUs & 8 DIMMs
2 CPUs &10 DIMMs
2 CPUs & 12 DIMMs
2 CPUs & 14 DIMMs
2 CPUs & 16 DIMMs
2 CPUs & 18 DIMMs
2 CPUs & 20 DIMMs
2 CPUs & 24 DIMMs
2 CPUs & 22 DIMMs
(Unbalanced: not
recommended)
+
1
1
X11DSC+
REV:1.00
DESIGNED IN USA
BIOS
LICENSE
LAN
CTRL
JSDCARD1
JUIDB1
(UID)
UID-LED
JPI2C1
JPWR2
JPWR1
P1_NVMe3
P1_NVMe2
P1_NVMe0
P1_NVMe1
JNVME0
JNVME1
JNVME2
JNVME3
P2_LE D_C1
P2_LE D_E2
P2_LE D_D2P2_LE D_D1
P2_LE D_B2P2_ LED_A 1
P2_LE D_A2
P2_LE D_C2
P2_LE D_B1
P1_LE D_B1P1_ LED_C2
P1_LE D_C1
P2_LE D_F2P2 _LED_ F1
P2_LE D_E1
P1_LE D_D2
P1_LE D_A2P1_ LED_A 1
P1_LE D_B2
P1_LE D_F1P1 _LED_ F2
P1_LE D_E2P1_ LED_E 1
P1_LE D_D1
FAN3
FAN1
FAN2
HDD_LED1
SP1
JVRM _SE L1
JWD1
JPME2
JF1
JNVI2C2
JIPMB1
JSD2
JSD1
I-SATA2
I-SATA3
JI2C_FP1
LEDBMC
I-SATA1
I-SATA0
USB2 (3.0)
FAN5 FAN4
JI2C EXP2
JI2C_EXP 1
I-SGPIO1
JSEN1
JRK1
JTPM1
JL1
JSTBY1
JPWR3
BMC
JNVI2C1
CPU2_MEMORY_LED CPU1_MEMORY_LED
LEDPWR
P2-DIMMC2
P2-DIMMC1
P2-DIMMB2
P2-DIMMB1
P2-DIMMA2
P2-DIMMA1
P2-DIMMD2
P2-DIMMD1
P2-DIMME2
P2-DIMME1
P2-DIMMF2
P2-DIMMF1
P1-DIMMC2
P1-DIMMC1
P1-DIMMB2
P1-DIMMB1
P1-DIMMA1
P1-DIMMA2
P1-DIMMD1
P1-DIMMD2
P1-DIMME1
P1-DIMME2
P1-DIMMF1
P1-DIMMF2
BAR CODE
IPMI CODE
CPU2
CPU1
COM1VGA
IPMI_LAN
USB 0/1 (3.0)
CPU1 SIOM PCI-E 3.0 x16
JBAT1
JBT1
CPU1 JMEZZ1 PCIE-E 3.0 x8
CPU1 JMEZZ2 PCIE-E 3.0 x8
PCH
CPU2 SLOT3 PCI-E 3.0 x16
CPU2 SLOT2 PCI-E 3.0 x16
CPU2 SLOT1 PCI-E 3.0 x8
12
RESET
P1-DIMMD1
P1-DIMMD1
P1-DIMME2
P1-DIMME1
P1-DIMMF2
P1-DIMMF1
P1-DIMMC1
P1-DIMMC2
P1-DIMMB1
P1-DIMMB2
P1-DIMMA1
P1-DIMMA2
P2-DIMMD2
P2-DIMMD1
P2-DIMME2
P2-DIMME1
P2-DIMMF2
P2-DIMMF1
P2-DIMMC1
P2-DIMMC2
P2-DIMMB1
P2-DIMMB2
P2-DIMMA1
P2-DIMMA2
1012 891113
1 3 4 752 6
3
5
7
2
Insert the SIOM
card into this slot
SIOM card with the
bracket installed
SATA3.0 / SAS3.0 Drive, Front Bays
12
RESET
SATA3.0 / SAS3.0 Drive, Raiser Bays
HDD2
HDD1
HDD0
HDD5
HDD4
HDD3
HDD8
HDD7
HDD6
HDD11
HDD10
HDD9
HDD14
HDD13
HDD12
HDD17
HDD16
HDD15
HDD20
HDD19
HDD18
HDD23
HDD22
HDD21
4
6
8
1
21
3 55 4
