USER’S MANUAL

Revision 1.1a

X8DTH-6F

X8DTH-6

X8DTH-i

X8DTH-iF

Unless you request and receive written permission from Super Micro Computer, Inc., you may not

copy any part of this document.

Information in this document is subject to change without notice. Other products and companies

referred to herein are trademarks or registered trademarks of their respective companies or mark

holders.

Printed in the United States of America

Manual Revision 1.1a

Release Date: May 18, 2010

The information in this User’s Manual has been carefully reviewed and is believed to be accurate.

The vendor assumes no responsibility for any inaccuracies that may be contained in this document,

makes no commitment to update or to keep current the information in this manual, or to notify any

person or organization of the updates. Please Note: For the most up-to-date version of this

manual, please see our Website at www.supermicro.com.

Super Micro Computer, Inc. ("Supermicro") reserves the right to make changes to the product

described in this manual at any time and without notice. This product, including software and docu-

mentation, is the property of Supermicro and/or its licensors, and is supplied only under a license.

Any use or reproduction of this product is not allowed, except as expressly permitted by the terms

of said license.

IN NO EVENT WILL SUPER MICRO COMPUTER, INC. BE LIABLE FOR DIRECT, INDIRECT,

SPECIAL, INCIDENTAL, SPECULATIVE OR CONSEQUENTIAL DAMAGES ARISING FROM THE

USE OR INABILITY TO USE THIS PRODUCT OR DOCUMENTATION, EVEN IF ADVISED OF

THE POSSIBILITY OF SUCH DAMAGES. IN PARTICULAR, SUPER MICRO COMPUTER, INC.

SHALL NOT HAVE LIABILITY FOR ANY HARDWARE, SOFTWARE, OR DATA STORED OR USED

WITH THE PRODUCT, INCLUDING THE COSTS OF REPAIRING, REPLACING, INTEGRATING,

INSTALLING OR RECOVERING SUCH HARDWARE, SOFTWARE, OR DATA.

Any disputes arising between the manufacturer and the customer shall be governed by the laws of

Santa Clara County in the State of California, USA. The State of California, County of Santa Clara

shall be the exclusive venue for the resolution of any such disputes. Supermicro's total liability for

all claims will not exceed the price paid for the hardware product.

FCC Statement: This equipment has been tested and found to comply with the limits for a Class

A digital device pursuant to Part 15 of the FCC Rules. These limits are designed to provide

reasonable protection against harmful interference when the equipment is operated in a commercial

environment. This equipment generates, uses, and can radiate radio frequency energy and, if not

installed and used in accordance with the manufacturer’s instruction manual, may cause harmful

interference with radio communications. Operation of this equipment in a residential area is likely

to cause harmful interference, in which case you will be required to correct the interference at your

own expense.

California Best Management Practices Regulations for Perchlorate Materials: This Perchlorate

warning applies only to products containing CR (Manganese Dioxide) Lithium coin cells. “Perchlorate

Material-special handling may apply. See www.dtsc.ca.gov/hazardouswaste/perchlorate”.

WARNING: Handling of lead solder materials used in this

product may expose you to lead, a chemical known to

the State of California to cause birth defects and other

reproductive harm.

Produkt Specifikationer

Mærke:	Supermicro
Kategori:	Bundkort
Model:	X8DTH-IF
Bredde:	3050 mm
Dybde:	330 mm
Wi-Fi:	Ingen
Opbevaringstemperatur (T-T):	-40 - 70 °C
Relativ luftfugtighed ved drift (H-H):	8 - 90 %
Relativ luftfugtighed ved opbevaring (H-H):	5 - 95 %
Ethernet LAN-porte (RJ-45):	3
Antal USB 2.0-porte:	2
Ethernet LAN:	Ja
Driftstemperatur (T-T):	10 - 35 °C
Bæredygtighedscertifikater:	RoHS
Maksimal intern hukommelse:	192 GB
On-board grafikkort, model:	Matrox G200eW
Processorproducent:	Intel
Antal VGA-porte (D-sub):	1
Ethernet-grænsefladetype:	Gigabit Ethernet
Antal serielle porte:	1
Antal PS/2-porte:	2
Processor sokkel:	Socket B (LGA 1366)
Understøtter RAID:	Ja
Bundkort chipsæt:	Intel® 5520
Understøttede hukommelsestyper:	DDR3-SDRAM
Understøttede hukommelsesclock-hastigheder:	800,1066,1333 MHz
LAN Kontroller:	Intel® 82576
USB 2.0-stik:	6
Antal SATA stik:	6
Indbrudsttik til kabinet:	Ja
Motherboard form faktor:	Udvidet ATX
Understøttede lagerdrev brugerflader:	SATA
BIOS-type:	EEPROM
BIOS-hukommelsesstørrelse:	32 Mbit
ACPI-version:	3.0
RAID-niveauer:	0, 1,5, 10
Antal understøttede processorer:	2
Hukommelsesspænding:	1.35, 1.5 V
Antal DIMM-slots:	12
Understøttet DIMM modul kapaciteter:	16GB, 1GB, 2GB, 4GB, 8GB
Maksimal RDIMM hukommelse:	192 GB
Intel® Xeon serie:	E5500, E5600, L5500, L5600, W5500, X5500, X5600
Understøttet UDIMM-clockhastigheder:	800 MHz
Maksimal UDIMM hukommelse:	48 GB
Antal understøttede processor cores:	2, 4,6
PCI Ekspres x8 (Gen 2.x) slots:	7
Understøttet QPI:	6.4 GT/s
