USER’S MANUAL

Revision 1.0b

X9SRi

X9SRi-F

X9SRi-3F

X9SRE

X9SRE-F

X9SRE-3F

Manual Revision 1.0b

Release Date: May 25, 2012

Unless you request and receive written permission from Super Micro Computer, Inc., you may not

copy any part of this document. Information in this document is subject to change without notice.

Other products and companies referred to herein are trademarks or registered trademarks of their

respective companies or mark holders.

Printed in the United States of America

The information in this User’s Manual has been carefully reviewed and is believed to be accurate.

The vendor assumes no responsibility for any inaccuracies that may be contained in this document,

makes no commitment to update or to keep current the information in this manual, or to notify any

person or organization of the updates. Please Note: For the most up-to-date version of this

manual, please see our web site at www.supermicro.com.

Super Micro Computer, Inc. ("Supermicro") reserves the right to make changes to the product

described in this manual at any time and without notice. This product, including software and docu-

mentation, is the property of Supermicro and/or its licensors, and is supplied only under a license.

Any use or reproduction of this product is not allowed, except as expressly permitted by the terms

of said license.

IN NO EVENT WILL SUPER MICRO COMPUTER, INC. BE LIABLE FOR DIRECT, INDIRECT,

SPECIAL, INCIDENTAL, SPECULATIVE OR CONSEQUENTIAL DAMAGES ARISING FROM THE

USE OR INABILITY TO USE THIS PRODUCT OR DOCUMENTATION, EVEN IF ADVISED OF

THE POSSIBILITY OF SUCH DAMAGES. IN PARTICULAR, SUPER MICRO COMPUTER, INC.

SHALL NOT HAVE LIABILITY FOR ANY HARDWARE, SOFTWARE, OR DATA STORED OR USED

WITH THE PRODUCT, INCLUDING THE COSTS OF REPAIRING, REPLACING, INTEGRATING,

INSTALLING OR RECOVERING SUCH HARDWARE, SOFTWARE, OR DATA.

Any disputes arising between manufacturer and customer shall be governed by the laws of Santa

Clara County in the State of California, USA. The State of California, County of Santa Clara shall

be the exclusive venue for the resolution of any such disputes. Supermicro's total liability for all

claims will not exceed the price paid for the hardware product.

FCC Statement: This equipment has been tested and found to comply with the limits for a Class B

digital device pursuant to Part 15 of the FCC Rules. These limits are designed to provide reason-

able protection against harmful interference in a residential installation. This equipment generates,

uses, and can radiate radio frequency energy and, if not installed and used in accordance with the

manufacturer’s instruction manual, may cause interference with radio communications. However,

there is no guarantee that interference will not occur in a particular installation. If this equipment

does cause harmful interference to radio or television reception, which can be determined by turn-

ing the equipment off and on, you are encouraged to try to correct the interference by one or more

of the following measures:

•Reorient or relocate the receiving antenna.

•Increase the separation between the equipment and the receiver.

•Connect the equipment into an outlet on a circuit different from that to which the

receiver is connected.

•Consult the dealer or an experienced radio/television technician for help.

California Best Management Practices Regulations for Perchlorate Materials: This Perchlorate warn-

ing applies only to products containing CR (Manganese Dioxide) Lithium coin cells. “Perchlorate

Material-special handling may apply. See www.dtsc.ca.gov/hazardouswaste/perchlorate”.

WARNING: Handling of lead solder materials used in this prod-

uct may expose you to lead, a chemical known to the State of

California to cause birth defects and other reproductive harm.

Produkt Specifikationer

Mærke:	Supermicro
Kategori:	Bundkort
Model:	X9SRi-3F
Bredde:	305 mm
Dybde:	244 mm
Wi-Fi:	Ingen
Ethernet LAN-porte (RJ-45):	2
Antal USB 2.0-porte:	2
Ethernet LAN:	Ja
Kabler inkluderet:	SATA
Bæredygtighedscertifikater:	RoHS
Maksimal intern hukommelse:	256 GB
On-board grafikkort, model:	Matrox G200eW
Medfølgende software:	IPMI v1.5/2.0\r\nSuperDoctor III\r\nWatch Dog\r\nNMI
Processorproducent:	Intel
Antal VGA-porte (D-sub):	1
Ethernet-grænsefladetype:	Gigabit Ethernet
Trusted Platform Module (TPM):	Ja
Komponent til:	Server
Antal serielle porte:	1
Antal PS/2-porte:	2
Processor sokkel:	LGA 2011 (Socket R)
PCI Express slots version:	2.0, 3.0
PCI Ekspres x8 slots:	1
PCI Express x16 slots:	1
Bundkort chipsæt:	Intel® C606
Understøttede hukommelsestyper:	DDR3-SDRAM
Understøttede hukommelsesclock-hastigheder:	1066,1333,1600 MHz
Antal SATA III-stik:	2
LAN Kontroller:	Intel® I350
USB 2.0-stik:	7
Antal SATA II stik:	4
Motherboard form faktor:	ATX
Understøttede lagerdrev brugerflader:	Serial Attached SCSI (SAS)
BIOS-type:	UEFI AMI
BIOS-hukommelsesstørrelse:	16 Mbit
ACPI-version:	4.0
RAID-niveauer:	0, 1,5, 10
Antal understøttede processorer:	1
Hukommelsesspænding:	1.35, 1.5 V
Strømstik til ventilator:	Ja
TPM-stik:	Ja
PCI Ekspres x4 slots:	1
Antal DIMM-slots:	8
Trusted Platform Module (TPM) version:	1.2
Antal PCI Express-slots:	3
IPMI LAN (RJ-45) port:	Ja
Understøttet DIMM modul kapaciteter:	16GB, 1GB, 2GB, 32GB, 4GB, 8GB
Maksimal RDIMM hukommelse:	256 GB
Intel® Xeon serie:	E5-1600, E5-2600
Understøttelse af Intelligent Platform Management Interface (IPMI):	Ja
Maksimal UDIMM hukommelse:	64 GB
On-board grafikkort, hukommelse:	16 MB
Antal understøttede processor cores:	2, 4,8
Processor, termisk ydeevne (maks.):	130 W
Understøttet QPI:	8 GT/s
