Side 1/1

SurgeX

Installation Instructions

SA82

120 Volt Connections

The SurgeX SA82 is designed to operate from a 120V AC service. Power up the unit by

connecting the power cord supplied with the unit and then plug into a 120V ac receptacle.

The SA82 is rated for a maximum load of 8 amps. Plug up to two equipment power cords into

the yellow receptacles as needed to provide safe, filtered power to the equipment.

Under no circumstances should the product be used with a “ground lifter” or any other device

which disconnects ground from the SurgeX. Doing so will create a safety hazard and could

constitute danger to life.

Indicator Lights

The green Self-Test light indicates that power is applied to the unit and the internal surge

protection circuitry is fully functional. If this light is not on when the unit is plugged into the AC

check that AC is present at the receptacle where the unit is plugged in.

If at any point the Self-Test light should go out, first make sure that AC is present at the

receptacle where the unit is plugged in. If the light is still off once this has been checked then it

will be necessary to return the unit to SurgeX for repair.

The red Power light indicates that AC power is available at the two yellow receptacles. This light

will go out if the AC voltage rises above 145 Volts and power will be interrupted in order to

protect connected equipment. When the AC voltage returns below 135 Volts power will be

automatically restored to the yellow receptacles and the red Power light will once again be lit.

Produkt Specifikationer

Mærke:	SurgeX
Kategori:	Ikke kategoriseret
Model:	SA-82
Bredde:	135 mm
Dybde:	230 mm
Højde:	44.5 mm
Vægt:	1542 g
Produktfarve:	Sort
Relativ luftfugtighed ved drift (H-H):	5 - 95 %
Driftstemperatur (T-T):	5 - 35 °C
Materiale:	Metal
Stativ-montering:	Ja
Strømstik:	NEMA 5–15P
Nominel indgangsspænding:	120 V
AC udgange, antal:	2 AC stikkontakt(er)
AC stikkontakt typer:	NEMA 5–15R
Overspænding energivurdering:	- J
EMI/RFI støjfiltrering:	Ja
Nominel udgangsstrøm:	10 A
Spidsstrøm, almindelig modus:	3000 A
Maksimal spikespænding:	6000 V
