5296652

Digital Folding K Type Thermocouple with Replaceable Probe-

Thank you for purchasing a Taylor® Type Thermocouple Please read this Digital Folding K- .

instruction manual carefully before use. Keep these instructions handy for future reference.

Please remember to keep the unit away from children and do not use it for safety related

applications.

THERMOCOUPLE PROBE REPLACEMENT

To replace the K-type thermocouple probe, unfold the probe to open position. Turn screw

cap counterclockwise to loosen and remove. Gently pull probe in an outward direction to

remove. Insert new probe, aligning the "+" and " " polarity symbols. Replace screw cap, -

turn clockwise to tighten.

DIGITAL FOLDING THERMOCOUPLE PROBE FUNCTION

To turn the unit on, unfold the probe to an open position (between a 45° 180° degree angle). -

A motion sensor within the unit will re illuminate the back light, pick up or gently shake the - -

thermometer to activate. The unit will continuously display temperatures for up to 10

minutes. After that, the unit will automatically shut off to preserve battery life. Or, to turn off

manually, fold the probe to a closed position.

1. Placing stress on the probe may cause breakage.

2. After measuring high temperatures, the probe may remain HOT for a while. Allow the

p robe to cool before touching.

3. Use caution while handling the probe to avoid injury. Keep probe out of reach of

children.

The probe may be damaged if used to measure a temperature that exceeds the

specification of the measurement temperature range.

To avoid electric shock and thermometer damage, do not measure a live circuit where

the voltage exceeds 24V AC RMS or 60V CD with the thermocouple probe.

°F C OR ° MODE

To switch between ‘°F’ and ‘°C’, unfold probe to open position, rotate unit left to right three

times in a row. Or, loosen screws on the battery compartment cover, remove the cover and

press ºF/ºC button

BACKLIGHT FEATURE

The backlight will activate for 15 seconds when the unit is in the open position.

LCD ERROR MESSAGES

The thermocouple incorporates visual diagnostic messages as follows:

‘Hi’ ’Lo’ or

is displayed when the temperature being measured is outside of

the measurement range.

‘bAt’

indicates a low battery warning. Replace both batteries at the same

time.

‘

"Er3" is displayed when the entire unit has been exposed to ambient

temperature below 32ºF (0ºC) or above 122ºF (50ºC). Allow

approximately 30 minutes for the unit to stabilize back to working room

temperature.

BATTERY INSTALLATION

The thermocou operates ple on 2 AAA batteries (included).

1. Remove any plastic wrap from the batteries before proceeding.

2. Loosen the screws on the battery compartment cover on the back of the

thermocouple . and remove the cover

3. Install 2 “AAA” batteries into the battery compartment according to the “+” and “-”

polarity symbols in the battery compartment.

4. Replace the battery compartment cover s. and tighten the screw

CAUTION: When batteries of different brand or type are used together, or new and old

batteries are used discharged due to together, some batteries may be over-

difference of voltage or capacity. This can result in venting, leakage, and rupture

and may cause personal injury.

NOTE: Please recycle or dispose of batteries correctly per local regulations.

WARNING: Batteries may pose a choking hazard. Do not let children hand batteries. Keep

batteries away from children. If swallowed, seek medical attention immediately

PRECAUTION: Do not dispose of the unit or batteries in fire, as the batteries inside this unit

may explode or leak. Remove the batteries if the product will not be used for along period of

time. Remove used batteries promptly. Clean the battery contacts and also those of the

device prior to battery installation.

STORAGE & CLEANING

Take care eaning the using only a soft cloth or cotton swab with when cl thermocouple,

water or medical alcohol, allow the o not and thermocouple . Dto fully dry before using it

submerge any part . The of the thermocouple thermocouple should be stored at room

temperature betw een -4 to +140 -°F ( 20 to +60 ). °C

SPECIFICATIONS

Item

Digital Folding K- Type Thermocouple

Probe Measurement Range

-40°F to 500°F (- 40°C to 260°C)

Operating Range

32 to122°F (0 to 50°C)

Resolution

0.1°F (0.1°C)

Probe Accuracy

±1% of reading or 1°F (1°C)

Battery Life

Typically 40 hours, minimum 30 hours continuous use

Batteries

2 AAA batteries

Display

LCD 1.57x0.75 inch (40x19mm)

Dimensions

6.42x1.93x1.06 inch (163x49x26.9mm)

Probe length

3.3” (8.382cm)

IPX7 Waterproof Rating

IPX7 when the battery door is properly closed and the

probe is properly attached

EMC/RFI

Readings may be affected if the unit is operated within a radio frequency electromagnetic

field strength of approximately 3 volts per meter, but the performance of the instrument will

not be permanently affected.

DO NOT keep the unit too close to objects that continuously generate high heat (such as

a hot plate) for long periods of time. This may cause the unit to overheat.

CARE AND PRECAUTIONS

1. Always read instructions thoroughly to ensure that you have the full benefit of all

the unit's eatures.f

2. Keep thermometer and probe out of reach of all children.

3. DO NOT immerse unit in water, as doing so will cause damage to internal components

and void the warranty. If you spill liquid on it, dry it immediately with a soft, lint -free

cloth. The unit is not dishwasher safe. Damage will void warranty.

4. DO NOT clean the unit with an abrasive or corrosive material. This may scratch the

plastic parts and corrode the electronic circuits.

5. DO NOT subject the units to excessive force, shock, dust, temperature or humidity.

This may result in malfunction, shorter electronic life span, damaged battery and

distorted parts.

6. DO NOT operate or store the unit in high temperature or humidity conditions. The

heat or moisture may interfere with the unit’s internal components. Store the unit at

temperatures between °C).-4 0 – 0and +14 °F ( 20 and +6

7. DO NOT tamper with the unit's internal components. Doing so will invalidate the

warranty on the unit and may cause damage. The unit contains no user-serviceable

parts.

8. This unit operates on 2 AAA batteries. Always purchase the correct size and grade of

battery most suitable for the intended use. Always replace both batteries at the

same time; do not combine old and new batteries. Do not mix Alkaline, carbon-zinc

(standard) or N - ickel Cadmium (rechargeable) batteries.

Two Year Limited Warranty

Taylor warrants this product to be free from defects in materials or workmanship for two (2 s ) year

(excluding batteries) for the original pur from date of original purchase. It does not cover chaser

damages or wear resulting from accident, misuse, abuse, commercial use, or unauthorized adjustment

and/or repair. If service is required, do not return to distributor. For service, call between 7:30 AM and

4:30 PM, Mountain Standard Time, Monday through Friday. To assist us in servic you, please have the ing

model number and date of purchase available. Should this product require service (or replacement at

our option), please pack the item carefully and return it prepaid, along with receipt showing date of

purchase and a note explaining reason for return to:

Taylor, a division of Lifetime Brands, Inc.

2220 Entrada del Sol, Suite A

Las Cruces, New Mexico 88001

Customer Service Phone: 1- - - 800 225 4834

Cust -575-526- omer Service Fax: 1 4347

www.taylorusa.com

There are no expressed warranties except as listed above. This warranty gives you specific legal rights,

and you may have other rights which vary from state to state.

For additional product information, or warranty information outside the USA, please contact us through

www.taylorusa.com.

Made to our exact specifications in China.

5296652 8.22 WC
