Side 1/4

Humidity level

bar graph

Indoor temperature

in ºC

Indoor comfort

indicator icon

Indoor relative

humidity in %

Low battery icon

TEMPERATURE STATION

INTRODUCTION:

Congratulations on purchasing this Temperature Station with indoor temperature, humidity and comfort

indicator. To enjoy the full benefits of this innovative product, please read this operating manual.

TEMPERATURE STATION:

FEATURES:

• Indoor temperature display in degree Celsius (°C)

• Indoor humidity display in RH%

• Indoor temperature and humidity display with MIN/MAX recordings

• Relative humidity level bar

• Indoor comfort indicator icon

• Low battery indicator

• Wall mounting or table standing

SETTING UP:

Please follow these steps to ensure that your new Temperature Station works correctly:

1. Insert the batteries into the Temperature Station. See “How to install and replace batteries in

the Temperature Station” below.

2. Once the batteries are in place, all segments of the LCD will light up briefly. Then the indoor

temperature, humidity and level bar will be displayed. If the indoor temperature is not displayed

after a few seconds, remove the batteries and wait for at least 30 seconds before reinserting them.

HOW TO INSTALL AND REPLACE BATTERIES IN THE TEMPERATURE STATION:

The Temperature station uses 2 x AAA, IEC LR3, 1.5V batteries. To install and replace the batteries,

please follow the steps below:

1. Insert finger or other solid object in the space at the right

center of the battery compartment and lift up to remove

the cover.

2. Insert batteries observing the correct polarity (see

marking).

3. Replace compartment cover.

Hanging hole

TO RESET THE TEMPERATURE STATION:

1. Remove the batteries from the Temperature Station

2. Wait at least 30 seconds and repeat the procedures in Setting up above

BATTERY CHANGE:

It is recommended to replace the batteries in all units on an annual basis to ensure optimum accuracy of

this unit.

Please participate in the preservation of the environment. Return used batteries to an

authorized depot.

FUNCTION KEYS:

The weather station has 1 key function easy to use:

MIN/MAX key:

• Toggle between MIN/MAX indoor temperature

• Toggle between MIN/MAX indoor humidity data

• Reset MIN/MAX records by pressing and holding the key for 2 seconds

LCD SCREEN

The Temperature Station’s LCD is divided into 3 sections, displaying humidity level in a bar graph format,

indoor humidity and indoor temperature.

LCD

display

Foldable stand

MIN/MAX key

Battery

compartment

USING THE TEMPERATURE STATION

THE HUMIDITY LEVEL BAR:

Located above the temperature/humidity display, it shows the indoor relative humidity level. The range is

from 16% to 98%, and each bar corresponds to 2% of relative humidity. It automatically changes

accordingly to the indoor humidity display.

INDOOR RELATIVE HUMIDITY:

The indoor relative humidity is displayed on the second line of the LCD under the humidity level bar. The

Temperature Station’ built in sensor automatically measures the surrounding indoor humidity level once

the batteries are inserted.

THE COMFORT LEVEL INDICATORS:

Comfortable: A happy face icon “☺” indicating a temperature level between 20.0°C and 25.9°C and

humidity between 45% and 65%.

Uncomfortable: A sad face icon “” indicating any value outside the comfortable range.

INDOOR TEMPERATURE:

The indoor temperature is displayed on the last line of the LCD under indoor comfort icon and MIN/MAX

icons. The indoor temperature is automatically displayed once the batteries are inserted.

MINIMUM AND MAXIMUM INDOOR TEMPERATURE AND HUMIDITY RECORDINGS:

By pressing the “MIN/MAX” key the current indoor temperature and humidity will alternate between the

maximum and minimum records. Once a new indoor temperature and humidity high or low is reached, it

will automatically set into the Temperature Station’s memory.

TO TOGGLE BETWEEN THE MIN/MAX INDOOR TEMPERATURE AND HUMIDITY:

1. Press the “MIN/MAX” key. The MAX indoor temperature will be displayed

2. Press the “MIN/MAX” key a second time. The MIN indoor temperature will be displayed.

4. Press the “MIN/MAX” key a third time. The MAX indoor humidity with humidity level bar will be

displayed.

5. Press the “MIN/MAX” key a fourth time. The MIN indoor humidity with humidity level bar will be

displayed.

6. Press again the “MIN/MAX” key to return to normal display mode.

Note: If no key is pressed for about 16 seconds, the display will automatically return to normal mode

display

RESETTING THE MIN/MAX TEMPERATURE AND HUMIDITY RECORDINGS:

During the MIN/MAX temperature and humidity record display, pressing the “MIN/MAX” key for 2 seconds

will reset the displayed records to the current data.

POSITIONING THE TEMPERATURE STATION:

The Temperature Station comes complete with a foldable stand that gives the option of table standing or

wall mounting.

To wall mount:

1. Fix a screw into the desired wall, leaving the head extended out by about

5mm.

2. Using the Temperature Station’s hanging hole, carefully hang it onto the

screw.

Note: Always ensures that the unit locks onto the screw head before releasing.

To table stand:

Unfold the Temperature Station’s stand located at the back of the unit

CARE AND MAINTENANCE:

• Avoid placing the unit in areas prone to vibration and shock as these may cause damage.

MAX icon

MIN icon

Indoor temperature

display in ºC

Relative humidity

level bar

MAX icon

Indoor humidity

display in RH%

MIN icon

Produkt Specifikationer

Mærke:	Techno Line
Kategori:	Vejrstation
Model:	WS 9410
Bredde:	153 mm
Dybde:	17 mm
Højde:	141 mm
Produktfarve:	Grey, Silver
Indbygget skærm:	Ja
Kan monteres på væggen:	Ja
Batteritype:	AAA Micro LR03
Temperatur, måleenheder:	°C
Målefunktioner:	Indoor hygrometer, Indoor thermometer
Trend visning af målefunktioner:	Hygrometer, Thermometer
Vejrstation, extremum data:	Hygrometer, Thermometer
Min. /maks. Temperatur-hukommelse:	Ja
Antal batterier (sensor):	2
