CL 9

user manual

1. General information

Thank you for purchasing this high-quality pro-

duct. Please read these operating instructions

carefully before using the appliance for the rst

time and keep them for future reference.

If you have any technical questions, you can

service@telestar.de.

2. Safety instructions

Read the safety instructions carefully before

using the appliance. Pay attention to all war-

nings and instructions both on the appliance

itself and in these operating instructions.

• Avoid any violent impact on the product, e.g.

with sharp or pointed objects.

• Always keep the lighter out of the reach of

children.

• Never open the appliance yourself. Mainte-

nance or repair work may only be carried out

by authorised specialist personnel.

• The lighter and especially the ignition wires

must not come into contact with water or

other liquids.

• To remove wax residue from the ignition

poles (the wires of the ARC ame), use a nail

le, for example.

• Only use the USB socket of a laptop or a

mobile device charger with a maximum out-

put power of 5 V DC / 3000 mA for charging.

Improper charging can lead to a risk of

explosion!

• Do not use the lighter as a light source.

• Always keep the device away from your face,

skin, other people and unsuitable or easily

ammable materials. Make sure that the arc

is completely switched off after each use to

avoid accidents.

• Do not expose the product to direct sunlight,

open re or temperatures above 50 °C, as

this can lead to overheating, malfunctions or

re hazards and shorten the service life of

the product.

• Disconnect the charger from the device

immediately after fully charging.

TELESTAR GmbH

Brückenstraße 2

D-97618 Niederlauer

www.telestar.de

info@telestar.de

3. Operation

The TELESTAR CL 9 is equipped with a

rechargeable Li-Ion battery (3.7 V, 220 mAh).

The integrated booster technology converts the

low battery voltage into a semi-sine wave high

voltage (7 kV at 15 kHz) and generates an arc

with an extremely high temperature between

the electrodes.

Thanks to this technology, the lighter is ideal

for lighting cigarettes, candles, replaces and

other highly ammable materials. Thanks to

its rechargeability, it is an environmentally

friendly alternative to conventional gas or petrol

lighters.

Charging the battery:

Charge the device fully before using it for the

rst time. To do this, use the USB port of a lap-

top or a suitable mobile device charger (max. 5

V DC, 3000 mA).

1. Connect the micro USB socket of the lighter

to the USB port or charger - use the cable

supplied.

2. The charging process takes about 2-3 hours.

3. The charge level indicator goes out as soon

as the charging process is complete.

4. Disconnect the charger when fully charged -

the lighter is now ready for use.

Ignition:

1. Open the safety ap by turning the handle

and pressing the silver locking button.

2. Then press the ignition button to create an

arc.

3. Hold the object to be ignited against the arc.

4. Specications

• USB ARC lighter (arc lighter)

• Torch function with two operating modes

(normal light and SOS ashing light)

• Integrated compass

• Protection class: IP56 (waterproof)

• Material: Zinc alloy / ABS

• Robust paint nish (Baking Paint)

• Battery capacity: 220 mAh

• Operating time:

Torch approx. 2.5 hours

Arc: approx. 50 ignitions

• Nominal voltage: 3.7 volts

• Charging connection: Micro-USB (DC 5 Volt)

• Charging time: approx. 2 hours

• Dimensions: 31 x 108 x 22 mm (W/H/D)

• Weight: 43 g

Conformity information

Telestar GmbH hereby declares that the follo-

wing device is in compliance with the essential

requirements and other relevant provisions of

the RoHS Directive 2011/65/EU including Dele-

gated Directive (EU) 2015/863 and the REACH

Version 1.0

(07/2025)

Old appliances must not be disposed

of with household waste, but must be

returned free of charge to municipal

collection centres or retailers. Remo-

vable used batteries and rechargeable

batteries must be removed and

disposed of separately before handing

them in.

Batteries and rechargeable batteries

must be collected separately and

can be returned free of charge to

collection centres or retailers. Lithium

batteries must be discharged and

the terminals taped to prevent short

circuits before handing them in.

The ignition process ends when you release

the button or automatically after approx. 6-8

seconds thanks to the integrated overload

protection.

After an automatic switch-off, the appliance

must cool down briey before it can be used

again.

Torch:

The LED torch can also be activated by pressing

the ignition button. The safety ap must be

closed when doing so.

Regulation (EC) No. 1907/2006:

TELESTAR CL 9 (item no. 5100002)

The declaration of conformity for these pro-

ducts is available from the company

TELESTAR GmbH, Brückenstraße 2,

D-97618 Niederlauer

You can download the declaration of conformi-

ty from our homepage:

https://www.telestar.de/support/dl/

Note on the disposal of rechargeable batteries

and batteries

ARC ameMicro-USB

connection

Light

Carrying strap

Press the switch to

create an electric arc

Switch on with the

switch and change

modes by pressing

several times.

Safety bar

Cover
