LM2901x-Q1 Quadruple Automotive Comparator

1 Features

• Qualified for automotive applications

• AEC-Q100 Qualified with the following results:

– Device temperature grade 1: –40°C to 125°C

ambient operating temperature range

– Device HBM ESD classification levels:

• H1B for "AV" version

• H1C for all other versions

– Device CDM ESD classification level C6

• Single supply or dual supplies

• Low supply-current drain independent of

supply voltage 0.8mA (typical)

• Low input bias current 25 nA (typical)

• Low input offset current 2 nA (typical)

• Low input offset voltage 2mV Typ (typical)

• Common-mode input voltage range includes

ground

• Differential input voltage range equal to maximum-

rated supply voltage ±36 V

• Low output saturation voltage

• Output compatible with TTL, MOS, and CMOS

• For single version in 5-pin SOT-23, see the TL331-

Q1 (SLVS969)

2 Applications

•Automotive

–HEV/EV and power train

–Infotainment and cluster

–Body control module

•Industrial

•Appliances

3 Description

The LM2901x-Q1 family of devices consists of

four independent voltage comparators, designed to

operate from a single power supply over a wide range

of voltages.

Operation from dual supplies is possible, provided the

difference between the two supplies is 2 V to 36 V,

and VCC is at least 1.5 V more positive than the input

common-mode voltage. Current drain is independent

of the supply voltage.

The outputs can be connected to other open-collector

outputs to achieve wired-AND relationships.

LM2901V-Q1 supports higher 32 V supply voltage

and LM2901AV-Q1 supports the higher 32 V supply

voltage and lower offset voltage.

Device Information

PART NUMBER PACKAGE (1) BODY SIZE (NOM)

LM2901-Q1

LM2901A-Q1

LM2901AV-Q1

TSSOP (14) 4.40 mm × 5.00 mm

SOIC (14) 3.91 mm × 8.65 mm

(1) For all available packages, see the orderable addendum at

the end of the data sheet.

IN–

IN+

OUT

Simplified Schematic

LM2901-Q1, LM2901V-Q1, LM2901AV-Q1

SLCS142F – DECEMBER 2003 – REVISED MAY 2021

An IMPORTANT NOTICE at the end of this data sheet addresses availability, warranty, changes, use in safety-critical applications,

intellectual property matters and other important disclaimers. PRODUCTION DATA.

Table of Contents

1 Features............................................................................1

2 Applications..................................................................... 1

3 Description.......................................................................1

4 Revision History.............................................................. 2

5 Pin Configuration and Functions...................................3

6 Specifications.................................................................. 4

6.1 Absolute Maximum Ratings........................................ 4

6.2 ESD Ratings............................................................... 4

6.3 Recommended Operating Conditions.........................4

6.4 Thermal Information....................................................5

6.5 Electrical Characteristics LM2901x-Q1.......................6

6.6 Switching Characteristics LM2901x-Q1...................... 6

6.7 Typical Characteristics LM2901x-Q1.......................... 7

7 Detailed Description........................................................8

7.1 Overview.....................................................................8

7.2 Functional Block Diagram........................................... 8

7.3 Feature Description.....................................................8

7.4 Device Functional Modes............................................8

8 Application and Implementation.................................... 9

8.1 Application Information............................................... 9

8.2 Typical Application...................................................... 9

9 Power Supply Recommendations................................11

10 Layout........................................................................... 11

10.1 Layout Guidelines................................................... 11

10.2 Layout Example...................................................... 11

11 Device and Documentation Support..........................12

11.1 Documentation Support.......................................... 12

11.2 Related Links.......................................................... 12

11.3 Trademarks............................................................. 12

11.4 Electrostatic Discharge Caution.............................. 12

11.5 Glossary.................................................................. 12

12 Mechanical, Packaging, and Orderable

Information.................................................................... 12

4 Revision History

Changes from Revision E (January 2015) to Revision F (May 2021) Page

• Updated Front Page HBM ESD Classifications.................................................................................................. 1

• Updated the numbering format for tables, figures, and cross-references throughout the document..................1

• Added seporate line for 1kV LM2901AV-Q1 HBM in ESD Ratings table............................................................4

• Changed incorrect text in Apps Section Feature Description............................................................................. 8

• Changed incorrect Layout Example pinout....................................................................................................... 11

Changes from Revision D (April 2008) to Revision E (January 2015) Page

• Added AEC-Q100 results to the section .............................................................................................Features 1

• Added table, section, , ESD Ratings Feature Description Device Functional Modes Application and

Implementation Power Supply Recommendations Layout Device and section, section, section,

Documentation Support Mechanical, Packaging, and Orderable Information section, and section. ................. 1

• Added the common-mode voltage note to the V ICR parameter in the table...............Electrical Characteristics 6

LM2901-Q1, LM2901V-Q1, LM2901AV-Q1

SLCS142F – DECEMBER 2003 – REVISED MAY 2021 www.ti.com

Product Folder Links: LM2901-Q1 LM2901V-Q1 LM2901AV-Q1

Produkt Specifikationer

Mærke:	Texas Instruments
Kategori:	Ikke kategoriseret
Model:	LM2901VQPWRQ1
Type:	Komparator
Bredde:	5.1 mm
Dybde:	4.5 mm
Højde:	1.05 mm
Antal pr. pakke:	2000 stk
Pakkedybde:	853 mm
Pakkebredde:	449 mm
Pakkehøjde:	35 mm
Opbevaringstemperatur (T-T):	-65 - 150 °C
Driftstemperatur (T-T):	-40 - 125 °C
Pakketype:	TSSOP
Antal kanaler:	4 kanaler
Antal stifter:	14
Bredde (med stifter):	5.1 mm
Højde (med stifter):	1.2 mm
Dybde (med stifter):	6.6 mm
