Side 1/35

OE1

OE2

To Seven Other Channels

A1 Y1

2 18

Product

Folder

Sample &

Buy

Technical

Documents

Tools &

Software

Support &

Community

An IMPORTANT NOTICE at the end of this data sheet addresses availability, warranty, changes, use in safety-critical applications,

intellectual property matters and other important disclaimers. PRODUCTION DATA.

On products compliant to MIL-PRF-38535, all parameters are

tested unless otherwise noted. On all other products, production

processing does not necessarily include testing of all parameters.

SN54HC541

SN74HC541

SCLS305D –JANUARY 1996– REVISED SEPTEMBER 2016

SNx4HC541 Octal Buers and Line Drivers With 3-State Outputs

1 Features

• Wide Operating Voltage Range of 2 V to 6 V

• High-Current 3-State Outputs Drive Bus Lines

Directly or Up to 15 LSTTL Loads

• Low Power Consumption, 80-µA Maximum ICC

• Typical tpd = 10 ns

• ±6-mA Output Drive at 5 V

• Low Input Current of 1 µA Maximum

• Data Flow-Through Pinout (All Inputs on Opposite

Side From Outputs)

2 Applications

• LEDs

• Servers

• PCs and Notebooks

• Wearable Health and Wellness Devices

• Electronic Points of Sale

3 Description

These octal buers and line drivers feature the

performance of the SNx4HC541 devices and a pinout

with inputs and outputs on opposite sides of the

package. This arrangement greatly facilitates printed

circuit board layout.

The 3-state outputs are controlled by a two-input

NOR gate. If either output-enable (OE1 or OE2) input

is high, all eight outputs are in the high-impedance

state. The SNx4HC541 devices provide true data at

the outputs.

Device Information(1)

PART NUMBER PACKAGE BODY SIZE (NOM)

SN74HC541DW SOIC (20) 12.80 mm × 7.50 mm

SN74HC541DB SSOP (20) 7.20 mm × 5.30 mm

SN74HC541N PDIP (20) 24.33 mm × 6.35 mm

SN74HC541NS SO (20) 12.60 mm × 5.30 mm

SN74HC541PW TSSOP (20) 6.50 mm × 4.40 mm

SN54HC541J CDIP (20) 24.20 mm × 6.92 mm

SN54HC541FK LCCC (20) 8.89 mm × 8.89 mm

(1) For all available packages, see the orderable addendum at

the end of the data sheet.

Logic Diagram (Positive Logic)

SN54HC541

SN74HC541

SCLS305D – JANUARY 1996 – REVISED SEPTEMBER 2016

www.ti.com

Product Folder Links: SN54HC541 SN74HC541

Table of Contents

1 Features .................................................................. 1

2 Applications ........................................................... 1

3 Description ............................................................. 1

4 Revision History..................................................... 2

5 Pin Conguration and Functions ......................... 3

6 Specications......................................................... 4

6.1 Absolute Maximum Ratings ...................................... 4

6.2 ESD Ratings.............................................................. 4

6.3 Recommended Operating Conditions ....................... 4

6.4 Thermal Information.................................................. 5

6.5 Electrical Characteristics, T

A= 25°C ........................ 5

6.6 Electrical Characteristics, SN54HC541 .................... 5

6.7 Electrical Characteristics, SN74HC541 .................... 6

6.8 Switching Characteristics, CL= 50 pF, TA= 25°C.... 6

6.9 Switching Characteristics, CL= 50 pF, SN54HC541 6

6.10 Switching Characteristics, C

L= 50 pF,

SN74HC541............................................................... 7

6.11 Switching Characteristics, C

L= 150 pF, TA= 25°C 7

6.12 Switching Characteristics, C

L= 150 pF,

SN54HC541............................................................... 7

6.13 Switching Characteristics, C

L= 150 pF,

SN74HC541............................................................... 8

6.14 Operating Characteristics........................................ 8

6.15 Typical Characteristics ............................................ 8

7 Parameter Measurement Information .................. 9

8 Detailed Description ............................................ 10

8.1 Overview ................................................................. 10

8.2 Functional Block Diagram ....................................... 10

8.3 Feature Description................................................. 10

8.4 Device Functional Modes........................................ 10

9 Application and Implementation ........................ 11

9.1 Application Information............................................ 11

9.2 Typical Application .................................................. 11

10 Power Supply Recommendations ..................... 13

11 Layout................................................................... 13

11.1 Layout Guidelines ................................................. 13

11.2 Layout Example .................................................... 13

12 Device and Documentation Support ................. 14

12.1 Related Links ........................................................ 14

12.2 Receiving Notication of Documentation Updates 14

12.3 Community Resources.......................................... 14

12.4 Trademarks ........................................................... 14

12.5 Electrostatic Discharge Caution............................ 14

12.6 Glossary ................................................................ 14

13 Mechanical, Packaging, and Orderable

Information ........................................................... 14

4 Revision History

NOTE: Page numbers for previous revisions may dier from page numbers in the current version.

Changes from Revision C (August 2003) to Revision D Page

• Added section, table, table, section,Applications Thermal Information ESD Ratings Feature Description Device

Functional Modes Application and Implementation Power Supply Recommendations Layout, section, section,

section, section, and section. .....Device and Documentation Support Mechanical, Packaging, and Orderable Information 1

• Deleted table, see at the end of the datasheet..Ordering Information Mechanical, Packaging, and Orderable Information 1

• Changed RθJA for DB package from 70°C/W: to 90.2°C/W .................................................................................................... 5

• Changed RθJA for DW package from 58°C/W: to 77.5°C/W ................................................................................................... 5

• Changed RθJA for N package from 69°C/W: to 45.2°C/W....................................................................................................... 5

• Changed RθJA for NS package from 60°C/W: to 72.8°C/W .................................................................................................... 5

• Changed RθJA for PW package from 83°C/W: to 98.3°C/W ................................................................................................... 5

Produkt Specifikationer

Mærke:	Texas Instruments
Kategori:	Ikke kategoriseret
Model:	SN74HC541N
Type:	Logisk kredsløb
Bredde:	26.92 mm
Dybde:	6.6 mm
Højde:	4.57 mm
Antal pr. pakke:	20 stk
Pakkedybde:	506 mm
Pakkebredde:	13.97 mm
Pakkehøjde:	11.23 mm
Opbevaringstemperatur (T-T):	-65 - 150 °C
Driftstemperatur (T-T):	-40 - 85 °C
Pakketype:	PDIP
Antal stifter:	20
Bredde (med stifter):	26.92 mm
Højde (med stifter):	8.26 mm
Dybde (med stifter):	10.92 mm
