Height………….… ….... 14 in.
FX Series Manual Flush Steam Generator
Input Voltage………… ……. ......208-240VAC Single Phase
Kilowatt Rating……………………………………… ….... 11 .0
Maximum Amperage………………………… ….. ....55 AMPS
Breaker Size…………………………………….. …... 60 AMPS
Water Inlet…………………………….…...3/8” Compression
Steam Outlet…………………………………….…….1/2” NPT
Safety Valve………………………………………..….3/4” NPT
Electrical Connection………………………….. ... Hardwired
Maximum Room Size (Cubic Feet)………..………..…...395
For any further assistance please contact ThermaSol at
800.776.0711 or sales@thermasol.com
• Can be plumbed up to 50 . from the steam room
without upsizing the generator
• Stainless steel construcon throughout
• Temp Sensor is built into controller
Generator must be installed by a licensed electrician.
Install this generator according to the installaon guide supplied. Follow all local plumbing and electrical codes. Unit must be accessible for
service and maintenance. Generator is factory sized: L x W x H = Steam Room Cubic Feet Cu. Ft. max. Choose the appropriate generator. = 395
For every addional foot of ceiling height over 8 , use the next larger generator. Always round up when calculang the total cubic feet.
Product Specicaon Basics:
The steam generator unit dimensions are approximately 17-3/4”L x
6-1/8”W x 12-3/4”H in dimension. The generator shall be made from
FX Series Manual Flush Series Standard Equipment:
• Manually Operated PowerFlush Pressurized inner tank cleaning system –
• Includes Fast Start Steam in s– econds… not minutes
• Constant Steam at a constant rate
• Unit has -240 volt power connecons to be installed by your licensed 208
• Superior heang element low wa density –
