OPERATING INSTRUCTIONS

WIRELESS TRANSMITTER WM-5325

Thank you for purchasing TOA's Wireless Transmitter.

Please carefully follow the instructions in this manual to ensure long, trouble-free use of your equipment.

TABLE OF CONTENTS

1. SAFETY PRECAUTIONS ............................................................................... 2

2. GENERAL DESCRIPTION ............................................................................. 3

3. FEATURES .......................................................................................................... 3

4. HANDLING PRECAUTIONS .......................................................................... 3

5. NOMENCLATURE ............................................................................................. 4

6. BATTERY INSERTION .................................................................................... 6

7. WHEN OPERATING ON RECHARGEABLE BATTERY ....................... 7

8. CHANNEL NUMBER SETTING .................................................................... 8

9. OPERATION ........................................................................................................ 8

10. OPERATIONAL HINTS .................................................................................... 9

11. DISTANCE BETWEEN THE MICROPHONE AND THE MOUTH ...... 9

12. AUDIO LEVEL ADJUSTMENT (SENSITIVITY CONTROL) ................ 9

13. SPECIFICATIONS ........................................................................................... 10

página 36

página 48

! ၁

Español:

Português:

ᇖ໚  ࡬฿ሺ 

English:

Deutsch:

Français:

page

seite

page

When the Unit is in Use

• To prevent the electromagnetic wave from badly

influencing medical equipment, make sure to

switch off the unit's power when placing it in close

proximity to the medical equipment.

• Use TOA's BC-5000 Battery Charger when

recharging.

• The wireless transmitter can be powered by WB-

2000 Battery. But, if use of any other than the

counter specified battery into the BC-5000 Battery

Charger, it may cause fire, personal injury, or

environmental contamination due to battery rupture

or leakage.

• The use of any other than the specified charger

could result in fire, personal injury, or

environmental contamination due to battery rupture

or leakage.

• Stop charging, if the batteries are not fully charged

within 3 hours. Failure to do so may cause the

batteries to fire, explode, leak, or heat.

• Never short-circuit the charging terminals on the

bottom of the transmitter with metal objects. Doing

so could result in electric shocks or burns.

When the Unit is in Use

• When the unit is not in use for 10 days or more, be

sure to take the battery out of the unit because

battery leakage may cause personal injury or

contamination of environment.

• Make sure to observe the following handling

precautions so that a fire or personal injury does

not result from leakage or explosion of the battery.

· Do not short, disassemble, heat nor put the

battery into a fire.

· Never charge batteries of the type which are not

rechargeable.

· Do not solder a battery directly.

· Be sure to use the specified type of battery.

· Note correct polarity (positive and negative

orientation) when inserting a battery in the unit.

· Avoid locations exposed to the direct sunlight,

high temperature and high humidity when storing

batteries.

Do not place the dry cell battery into charger.

Placing non-rechargeable batteries in the charger

may cause the battery to crack resulting in a fire

and/or harm to the body.

When recharging, please only use the BC-5000

Battery Charger and WB-2000 Battery.

Do not use other battery types.

When the battery becomes inflated or leaks,

discontinue use and replace with new one

immediately.

If there’s any burning and/or peculiar smell while

charging the battery, please switch off the power

immediately.

The frequencies between 865 MHz and 867 MHz do

not comply with "CE."

CAUTION TO USER: Changes or modifications not

expressly approved by the party responsible for

compliance could void the user's authority to operate

the equipment.

IMPORTANT NOTE: To comply with the FCC RF

exposure compliance requirements, no change to

the antenna or the device is permitted. Any change

to the antenna or the device could result in the

device exceeding the RF exposure requirements and

void user’s authority to operate the device.

1. SAFETY PRECAUTIONS

• Be sure to read the instructions in this section carefully before use.

• Make sure to observe the instructions in this manual as the conventions of safety symbols and messages

regarded as very important precautions are included.

• We also recommend you keep this instruction manual handy for future reference.

Safety Symbol and Message Conventions

Safety symbols and messages described below are used in this manual to prevent bodily injury and property

damage which could result from mishandling. Before operating your product, read this manual first and

understand the safety symbols and messages so you are thoroughly aware of the potential safety hazards.

WARNING

CAUTION

Indicates a potentially hazardous situation which, if mishandled, could

result in death or serious personal injury.

Indicates a potentially hazardous situation which, if mishandled, could

result in moderate or minor personal injury, and/or property damage.

WARNING

CAUTION

Produkt Specifikationer

Mærke:	TOA
Kategori:	Mikrofon
Model:	WM-5325
Bredde:	62 mm
Dybde:	23 mm
Højde:	102.5 mm
Vægt:	90 g
Produktfarve:	Sort
Indbygget skærm:	Ingen
Formfaktor:	Bordpladesender
Driftstemperatur (T-T):	-10 - 50 °C
LED-indikatorer:	Ja
Batterilevetid (maks.):	13 t
Batteritype:	AA
Antenne type:	Indbygget
Antal kanaler:	64 kanaler
RF-effekt:	50 mW
Mikrofon frekvenssvar:	100 - 15000 Hz
Radiofrekvens (RF) interval:	576 - 937.5 MHz
3,5 mm ind:	Ja
Topafvigelse:	40 kHz
Driftsfrekvenstype:	Ultrahøj frekvens (UHF)
