Prepare to Ride
GB
F 8ixer for handlebar bags and baskets
User's Guide
Add cable housing over the security
cable to protect the stem from
marring. Trim excess cable housing.
M5 x 20L
Bolt
A. Mount Handlebar Fixer on Handlebar
Tighten the bolts.
(Do not tighten completely.)
20˚
* Not needed if handlebar diameter is 31.8mm.
DETAILED PARTS DESCRIPTION
Handlebar Bag Fixer
1. HB Fixer A
1a. HB Fixer Release Button
2. M5 x 20mm Bolt 2a. Washer x2
3. M5 x 18mm Bolt
4. M5 x 12mm Bolt
5. HB Fixer B
*
6. Computer Clip
6a. Thread hole
6b. Computer Clip Release Tab
7. Rubber Sizing Pad
7a. ø25.4 (for normal size h/bar)
7b. ø28.6 (for oversize h/bar)
8. Security Cable
8a. cable housing
8
6
7a 7b
5
6b
6a
8a
Fits ø25.4, ø28.6 and ø31.8 mm handlebars.
5mm Allen key
1
31a
2
2a
4
Prepare to Ride
F 8ixer for handlebar bags and baskets
User's Guide
M-Fixer8-GB 01/11
Trim excess cable.
Press release tabs on computer clip for removal.
Release
Tab
Pull cable and tighten
anchor bolt rmly.
5˚
Recommended
5˚ from horizontal
Re-tighten the
bolts once correct
angle is reached.
B. Mounting Computer Clip
Install Uninstall
C. Bags Utilization
Install Uninstall
"Click"
Release
Button
Pull
Back
Pull back release button of HB
Fixer A and lift basket to detach.
Handlebar DryBag
Compact Handlebar Bag TourGuide Handlebar Bag DXTourGuide Handlebar Bag BarPack
Handlebar Bag / Jango
Art no. JB-HB01
HB Cabriolet BasketHB Chopper Basket
COMPATIBLE ACCESSORIES
* Features Jango Logo
Copyright © Topeak, Inc. 2011
WARRANTY
2-year
Warranty: All mechanical components against
manufacturer defects only.
Warranty Claim Requirements
To obtain warranty service, you must have your original sales receipt. Items
returned without a sales receipt will assume that the warranty begins on
the date of manufacture. All warranties will be void if the product is
damaged due to user crash, abuse, system alteration, modification, or used
in any way not intended as described in this manual.
* The specications and design are subject to change without notice.
Topeak Panoram
Cycle Computer
Series
OPTIONAL
ACCESSORY TO MOUNT
ON COMPUTER CLIP
Please contact your Topeak dealer with any questions.
For USA customer service call: 1-800-250-3068
Website: www.topeak.com
