Side 1/40

FormNo.3448-826RevA

30inTurfMasterHDXWalk-BehindLawnMower

ModelNo.22215—SerialNo.410094837andUp

Operator'sManual

Introduction

Thisrotary-blade,walk-behindlawnmowerisintended

tobeusedbyprofessional,hiredoperators.Itis

designedprimarilyforcuttinggrassonwell-maintained

lawnsonresidentialorcommercialproperties.Using

thisproductforpurposesotherthanitsintendeduse

couldprovedangeroustoyouandbystanders.

Readthisinformationcarefullytolearnhowtooperate

andmaintainyourproductproperlyandtoavoid

injuryandproductdamage.Y ouareresponsiblefor

operatingtheproductproperlyandsafely.

Visitwww.T oro.comformoreinformation,including

safetytips,trainingmaterials,accessoryinformation,

helpndingadealer,ortoregisteryourproduct.

Wheneveryouneedservice,genuineT oroparts,or

additionalinformation,contactanAuthorizedService

DealerorT oroCustomerServiceandhavethemodel

andserialnumbersofyourproductready.Figure1

identiesthelocationofthemodelandserialnumbers

ontheproduct.Writethenumbersinthespace

provided.

Important:Withyourmobiledevice,youcan

scantheQRcodeontheserialnumberdecal(if

equipped)toaccesswarranty,parts,andother

productinformation

g290587

Figure1

1.Modelandserialnumberlocation

ModelNo.

SerialNo.

Thismanualidentiespotentialhazardsandhas

safetymessagesidentiedbythesafety-alertsymbol

(Figure2),whichsignalsahazardthatmaycause

seriousinjuryordeathifyoudonotfollowthe

recommendedprecautions.

g000502

Figure2

Safety-alertsymbol

Thismanualuses2wordstohighlightinformation.

Importantcallsattentiontospecialmechanical

informationandNoteemphasizesgeneralinformation

worthyofspecialattention.

ItisaviolationofCaliforniaPublicResourceCode

Section4442or4443touseoroperatetheengineon

anyforest-covered,brush-covered,orgrass-covered

landunlesstheengineisequippedwithaspark

arrester,asdenedinSection4442,maintainedin

effectiveworkingorderortheengineisconstructed,

equipped,andmaintainedforthepreventionofre.

Theenclosedengineowner'smanualissupplied

forinformationregardingtheUSEnvironmental

ProtectionAgency(EPA)andtheCaliforniaEmission

ControlRegulationofemissionsystems,maintenance,

andwarranty.Replacementsmaybeorderedthrough

theenginemanufacturer.

GrossorNetTorque:Thegrossornettorque

ofthisenginewaslaboratoryratedbytheengine

manufacturerinaccordancewiththeSocietyof

AutomotiveEngineers(SAE)J1940orJ2723.As

conguredtomeetsafety,emission,andoperating

requirements,theactualenginetorqueonthisclass

ofmowerwillbesignicantlylower.Pleasereferto

theenginemanufacturer’sinformationincludedwith

themachine.

WARNING

CALIFORNIA

Proposition65Warning

Theengineexhaustfromthisproduct

containschemicalsknowntotheStateof

Californiatocausecancer,birthdefects,

orotherreproductiveharm.

Useofthisproductmaycauseexposure

tochemicalsknowntotheStateof

Californiatocausecancer,birthdefects,

orotherreproductiveharm.

8111LyndaleAvenueSouth

Bloomington,MN55420Registeratwww.T oro.com.

OriginalInstructions(EN)

PrintedinMexico

AllRightsReserved *3448-826*

Contents

Introduction...............................................................1

Safety.......................................................................2

GeneralSafety...................................................2

SafetyandInstructionalDecals..........................3

Setup........................................................................6

1InstallingtheHandle........................................6

2AddingOiltotheEngine...................................7

3AssemblingtheGrassBag...............................7

ProductOverview.....................................................9

Controls.............................................................9

Specications....................................................9

Attachments/Accessories.................................10

Operation................................................................10

BeforeOperation.................................................10

BeforeOperationSafety...................................10

FillingtheFuelTank..........................................10

CheckingtheEngine-OilLevel...........................11

AdjustingtheHandleHeight..............................11

AdjustingtheCuttingHeight.............................12

CheckingtheBlade-StopSystem

Operation......................................................13

DuringOperation.................................................13

DuringOperationSafety...................................13

StartingtheEngine...........................................14

OperatingtheSelf-PropelDriveand

EngagingtheBlades.....................................15

ShuttingOfftheEngine.....................................16

EngagingtheParkingBrake.............................16

DisengagingtheParkingBrake.........................16

RecyclingtheClippings....................................17

BaggingtheClippings.......................................17

Side-DischargingtheClippings.........................18

OperatingTips.................................................19

AfterOperation....................................................19

AfterOperationSafety......................................19

CleaningundertheMachine.............................19

CleaningtheWheels.........................................20

Maintenance...........................................................21

RecommendedMaintenanceSchedule(s)...........21

MaintenanceSafety..........................................21

ServicingtheAirFilter.......................................22

ChangingtheEngineOil...................................22

ChangingtheOilFilter......................................23

ServicingtheSparkPlug...................................24

CheckingtheConditionoftheBelts...................24

EmptyingtheFuelT ankandCleaningthe

Filter..............................................................24

ChangingtheFuelFilter....................................25

ServicingtheBlade-DriveSystem.....................25

ServicingtheBlades.........................................26

ChangingtheBlade-DriveBelt..........................28

ChangingtheBlade-Brake-Clutch(BBC)

Belt................................................................29

AdjustingtheBlade-BrakeCable......................30

ChangingtheTransmissionBelt.......................31

AdjustingtheParking-BrakeCable...................32

AdjustingtheSelf-PropelDrive.........................33

Storage...................................................................34

StorageSafety..................................................34

GeneralInformation..........................................34

PreparingtheFuelSystem...............................34

PreparingtheEngine........................................34

RemovingtheMachinefromStorage................34

Troubleshooting......................................................35

Safety

Thismachinehasbeendesignedinaccordancewith

ANSIB71.4-2017.

GeneralSafety

Thisproductiscapableofamputatinghandsand

feetandofthrowingobjects.Alwaysfollowallsafety

instructionstoavoidseriouspersonalinjuryordeath.

•Read,understand,andfollowtheinstructions

andwarningsinthisOperator’sManualandon

themachineandattachmentsbeforestartingthe

engine.

•Donotputyourhandsorfeetnearmovingpartsor

underthemachine.Keepclearofanydischarge

opening.

•Donotoperatethemachinewithoutallguards

andothersafetyprotectivedevicesinplaceand

functioningproperlyonthemachine.

•Keepbystandersandchildrenoutoftheoperating

area.Donotallowchildrentooperatethemachine.

Allowonlypeoplewhoareresponsible,trained,

familiarwiththeinstructions,andphysically

capabletooperatethemachine.

•Stopthemachine,shutofftheengine,andwaitfor

allmovingpartstostopbeforeservicing,fueling,

oruncloggingthemachine.

Improperlyusingormaintainingthismachinecan

resultininjury.Toreducethepotentialforinjury,

complywiththesesafetyinstructionsandalways

payattentiontothesafety-alertsymbol ,which

meansCaution,Warning,orDanger—personalsafety

instruction.Failuretocomplywiththeseinstructions

mayresultinpersonalinjuryordeath.
