Wall Mounting Guide

Wall Mountable Switches

1.1 Wall Mounting Preparation

Before mounting the switch, you need to prepare the tools below:

ǴA screw driver.

ǴTwo screws which complies to the corresponding standard. For details, see Wall

Mounting Specification.

1.2 Wall Mounting Procedure

On the bottom of the panel, there are two mounting holes. You need to drive two screws

into the wall, then mount the switch on the wall. Note that the switch should be mounted

on the wall upright rather than sideways. For TL-SF1008P/TL-SF1008LP/TL-SF1009P/

TL-SG1008P, the switch should be mounted with the ports facing downward and the

LEDs facing upward.

1) Determine the location on the wall where you want to mount the switch.

2) Mark the wall where the two mounting holes are. The distance between the two marks

must be the same as that between the two mounting holes of the switch. For the wall-

mounting-holes distance, see .Wall Mounting Specification

3) Drive the screws into the wall at the marks using the screw driver. For the Screw-

Head-to-Wall Minimum Distance, see .Wall Mounting Specification

4) Mount the switch on the wall.

1.3 Wall Mounting Specification

Model

Screw Standard of

ANSI B1.1

Minimum Length

of Screw

Screw-Head-to-Wall

Minimum Distance

Wall-Mounting-Holes

Distance

DS105G

4#, (5#), 6#, 8# .57 mm

1.5mm mm39

DS105GE

4#, (5#), 6#

7.5mm

1.5mm mm52

DS105G-M2 4#, (5#), 6#

7.5mm

1.5mm mm52

DS105GP

4#, (5#), 6#, 8# 8.5mm

1.5mm mm39

DS105X 4#, (5#), 6# .5mm 1.5mm7

150mm

DS106GPP 4#, (5#), 6#, 8# 8.5mm 1.5mm mm94

DS106P 4#, (5#), 6#, 8# 8.5mm 1.5mm 94mm

DS108G 4#, (5#), 6#, 8# .5mm 1.5mm7 94mm

DS108GE 4#, (5#), 6# .5mm 1.5mm 1 mm7 10

DS108G-M2 4#, (5#), 6# .5mm 1.5mm 1 mm7 10

DS108GP

4#, (5#), 6#, 8#

8.5mm 1.5mm mm94

DS110GMP 4#, (5#), 6# 8.5mm 1.5mm

150mm
