Side 1/6
General Information Introduction
WARNING
Before installing the optic on a firearm, ensure the
firearm is UNLOADED.
WARNING
This Trijicon
® product is shipped with a new lithium battery.
Lithium batteries or lithium button cells pose the risk of fire.
The battery can explode or leak and cause injury if installed
backwards, disassembled, charged, crushed or exposed to fire
or high temperature. Keep out of reach of children. Check local
municipality for proper disposal. California Only:
Perchlorate Material – special handling may apply.
CAUTION
DO NOT allow harsh organic chemicals such as acetone,
trichloroethane, or other cleaning solvents to come in contact
with this Trijicon
® product. They will affect the appearance, but
not the performance.
CAUTION
When mounting this Trijicon
® product onto the rail of a firearm,
do not tighten the mount screws beyond the recommended
torque setting provided by the mount manufacturer. Damage
may occur to the optic and/or zero retention may be negatively
affected.
The Trijicon Tenmile
® / Tenmile® HX is a versatile, variable powered
riflescope with an electronically illuminated reticle. Featuring a high
quality lens system with full multi-layer coatings, the Tenmile / Tenmile
HX provides an incredibly clear sight picture. The reticle illumination
is powered by a single CR2032 lithium battery and has an easy-to-
operate brightness adjustment dial with ten brightness settings and an
“off” feature between each setting. The Tenmile / Tenmile HX features
a hard anodized aluminum body that protects against corrosion and
is waterproof to a depth of ten feet (3m). With a generous adjustment
range for windage and elevation, precise adjustment increments, and a
resettable zero, the Tenmile / Tenmile HX riflescope delivers the features
required for pinpoint accuracy.
Each model features:
• Fully multi-coated broadband anti-reflective lenses with enhanced
scratch resistance
• CR2032 battery illumination
• 10 brightness settings with “off” between each setting
• Precise, crisp adjusters
• Highly durable, aircraft-grade aluminum housing
• Waterproof to 10 ft.
• Dry-nitrogen filled to prevent internal fogging
Quick Reference Guide
Trijicon Tenmile® HX
Trijicon Tenmile®
Characteristics
5-25x50
TM2550 Series
TMHX2550 Series
5-50x56
TM5056 Series
TMHX5056 Series
Magnification Range 5 - 25x 5 - 50x
Objective Lens Size 50mm 56mm
Eye Relief 2.9 - 3.9 in.
73 - 99mm
3.5 - 3.9 in.
89 - 100mm
Exit Pupil .39 - .08 in.
10 - 2mm
.28 - .04 in.
7.2 - 1.1mm
Field of View
(Degrees) 3.83 - 0.77° 4° - 0.41°
Field of View
(@ 100 yd.)
(@ 100m)
20.1 - 4 ft.
6.7 - 1.3m
21.2 - 2.1 ft.
7.1 - .7m
Adjustments
1/4 MOA per click
0.1 MRAD per click
1/8 MOA per click
.05 MRAD per click
Total Adjustment
Range Windage
40 MOA
11.6 MRAD
50 MOA
14.5 MRAD
Total Adjustment
Range Elevation
50 MOA
14.5 MRAD
100 MOA
29.1 MRAD
Return to Zero
Yes Yes
Focal Plane
Second
Second
Dimensions
(L x W x H) 13.5 x 3.3 x 2.8 in.
16 x 3.6 x 2.9 in.
Weight 25.6 oz.
38.4 oz.
Tube Diameter 30mm 34mm
4-24x50
TM42450 Series
4.5-30x56
TM3056 Series
TMHX3056 Series
Magnification Range 4 - 24x 4.5 - 30x
Objective Lens Size 50mm 56mm
Eye Relief 3.1 - 3.8 in.
78 - 96mm
3.2 - 3.8 in.
82 - 97mm
Exit Pupil .33 - .08 in.
8.5 - 2.1mm
.35 - .07 in.
8.8 - 1.9mm
Field of View
(Degrees) 5.43° - 0.91° 4.7° - 0.7°
Field of View
(@ 100 yd.)
(@ 100m)
28.5 - 4.7 ft.
9.5 - 1.6m
24.7 - 3.7 ft.
8.2 - 1.2m
Adjustments
0.1 MRAD per click 1/4 MOA per click
0.1 MRAD per click
Total Adjustment
Range Windage 20 MRAD 50 MOA
14.5 MRAD
Total Adjustment
Range Elevation 29 MRAD 100 MOA
29.1 MRAD
Return to Zero
Yes Yes
Focal Plane
Second
First / Second
Dimensions
(L x W x H) 14.45 x 3.26 x 2.37 in. 14.23 - 14.33 x 3.63
x 2.9 in.
Weight 25.7 oz. 36 oz.
Tube Diameter 30mm 34mm
3-18x44
TM1844 Series
TMHX1844 Series
3-18x50
TMHX1850 Series
Magnification Range 3 - 18x 3 - 18x
Objective Lens Size 44mm 50mm
Eye Relief 3.4 - 3.9 in.
87 - 100mm
3.4 - 4.0 in.
87 - 101mm
Exit Pupil .45 - .09 in.
11.4 - 2.4mm
.45 - .11 in.
11.4 - 2.8mm
Field of View
(Degrees) 6.73° - 1.12° 6.62° - 1.11°
Field of View
(@ 100 yd.)
(@ 100m)
35.3 - 5.9 ft.
11.8 - 2.0m
34.7 - 5.8 ft.
11.6 - 1.9m
Adjustments
1/4 MOA per click
0.1 MRAD per click 0.1 MRAD per click
Total Adjustment
Range Windage
60 MOA
17.4 MRAD 17 MRAD
Total Adjustment
Range Elevation
60 MOA
17.4 MRAD 17 MRAD
Return to Zero
Yes Yes
Focal Plane
First Second
Dimensions
(L x W x H) 15.02 x 3.26 x 2.4 in. 14.87 x 3.26 x 2.59 in.
Weight 24.4 oz. 25.7 oz.
Tube Diameter 30mm 30mm
