Side 1/7
General Information Introduction
WARNING
Before installing the optic on a firearm, ensure the
firearm is UNLOADED.
WARNING
This Trijicon
® product is shipped with a new lithium battery.
Lithium batteries or lithium button cells pose the risk of fire.
The battery can explode or leak and cause injury if installed
backwards, disassembled, charged, crushed or exposed to fire
or high temperature. Keep out of reach of children. Check local
municipality for proper disposal. California Only:
Perchlorate Material – special handling may apply.
CAUTION
DO NOT allow harsh organic chemicals such as acetone,
trichloroethane, or other cleaning solvents to come in contact
with this Trijicon
® product. They will affect the appearance, but
not the performance.
CAUTION
When mounting this Trijicon
® product onto the rail of a
firearm, do not tighten the mount screws beyond the
recommended torque setting provided by the mount
manufacturer. Damage may occur to the optic and/or zero
retention may be negatively affected.
The Trijicon Credo® / Credo® HX is a versatile, variable powered
riflescope with an electronically illuminated reticle. Featuring a high
quality lens system with full multi-layer coatings, the Credo
/ Credo
HX provides an incredibly clear sight picture. The reticle illumination
is powered by a single CR2032 lithium battery and has an easy-to-
operate brightness adjustment dial with ten brightness settings and
an “off” feature between each setting. The Credo / Credo HX features
a hard anodized aluminum body that protects against corrosion and
is waterproof to a depth of ten feet (3m). With a generous adjustment
range for windage and elevation, precise adjustment increments, and
a resettable zero, the Credo / Credo HX riflescope delivers the features
required for pinpoint accuracy.
Each model features:
• Fully multi-coated broadband anti-reflective lenses with enhanced
scratch resistance
• CR2032 battery illumination
• 10 brightness settings with “off” between each setting
• Precise, crisp adjusters
• Highly durable, lightweight aircraft-grade aluminum housing
• Waterproof to 10 ft.
• Dry-nitrogen filled to prevent internal fogging
Quick Reference Guide
Trijicon Credo® HX
Trijicon Credo®
Characteristics
2.5-10x56
CR1056 Series
CRHX1056 Series
2.5-15x42
CR1542 Series
CRHX1542 Series
Magnification Range 2.5 - 10x 2.5 - 15x
Objective Lens Size 56mm 42mm
Eye Relief 2.8 - 4.0 in.
72 - 102mm
3.4 - 3.9 in.
85 - 100mm
Exit Pupil .64 - .21 in.
16.2 - 5.4mm
.42 - .11 in.
10.7 - 2.8mm
Field of View
(Degrees) 7.3° - 1.94° 7.86° - 1.31°
Field of View
(@ 100 yd.)
(@ 100m)
38.3 - 10.2 ft.
12.8 - 3.4m
41.2 - 6.9 ft.
13.7 - 2.3m
Adjustments
1/4 MOA per click
0.1 MRAD per click
1/4 MOA per click
0.1 MRAD per click
Total Adjustment
Range Windage
50 MOA
14.5 MRAD
80 MOA
23.3 MRAD
Total Adjustment
Range Elevation
50 MOA
14.5 MRAD
100 MOA
29.1 MRAD
Return to Zero
No
Yes
Focal Plane
Second
Second
Dimensions
(L x W x H)
13.8 x 2.7 - 2.9 x 2.6
- 2.8 in. 13.9 x 3.3 x 2.6 in.
Weight 25.3 - 25.4 oz. 22.9 oz.
Tube Diameter 30mm 30mm
1-8x28
CR828 Series
CRHX828 Series
2-10x36
CR1036 Series
Magnification Range 1 - 8x 2 - 10x
Objective Lens Size 28mm 36mm
Eye Relief 3.0 - 4.0 in.
76 - 101mm
3.4 - 3.9 in.
87 - 99mm
Exit Pupil .46 - .14 in.
11.7 - 3.5mm
.41 - .13 in.
10.5 - 3.4
Field of View
(Degrees) 20° - 2.53° 9.53° - 1.92°
Field of View
(@ 100 yd.)
(@ 100m)
105.8 - 13.2 ft.
35.3 - 4.4m
50.0 - 10.1 ft.
16.7 - 3.4m
Adjustments
1/4 MOA per click
0.1 MRAD per click
1/4 MOA per click
0.1 MRAD per click
Total Adjustment
Range Windage
100 MOA
29.1 MRAD
90 MOA
26.2 MRAD
Total Adjustment
Range Elevation
100 MOA
29.1 MRAD
90 MOA
26.2 MRAD
Return to Zero
No
Yes
Focal Plane
First
First
Dimensions
(L x W x H) 10.8 x 3.2 x 2.6 in.
13.1 x 3.24 x 2.6 in.
Weight 25.6 - 25.7 oz. 23 oz.
Tube Diameter 34mm 30mm
1-4x24
CR424 Series
CRHX424 Series
1-6x24
CR624 Series
CRHX624 Series
Magnification Range 1 - 4x 1 - 6x
Objective Lens Size 24mm 24mm
Eye Relief 2.6 - 3.9 in.
65 - 98mm
3.5 - 3.9 in.
88 - 100mm
Exit Pupil .69 - .2 in.
17.5 - 5.1mm
.47 - .16 in.
12 - 4.1mm
Field of View
(Degrees) 18° - 4.6° 21.4° - 3.58°
Field of View
(@ 100 yd.)
(@ 100m)
95 - 24.2 ft.
31.7 - 8.1m
113.4 - 18.8 ft.
37.8 - 6.3m
Adjustments
1/4 MOA per click
0.1 MRAD per click
1/4 MOA per click
0.1 MRAD per click
Total Adjustment
Range Windage
100 MOA
29 MRAD
100 MOA
29 MRAD
Total Adjustment
Range Elevation
100 MOA
29 MRAD
100 MOA
29 MRAD
Return to Zero No No
Focal Plane Second First / Second
Dimensions
(L x W x H) 10.5 x 2.7 x 1.9 in. 10.9 x 2.8 x 2.0in.
Weight 17.1 - 17.2 oz. 18.2 - 18.9 oz.
Tube Diameter 30mm 30mm
