Version 1.00
Revision A
December 2012
U GSER UIDE
Trimble Juno T41 handheld
1

Corporate Office
10355 Westmoor Drive
Suite #100
Westminster, CO 80021
USA
www.trimble.com
Legal Notices
© 2012, Trimble Navigation Limited. All rights reserved.
Trimble,the Globe & Triangle logo are trademarks of Trimble Navigation
Limited, registered in the United States and in othercountries. Juno is a
trademark of Trimble Navigation Limited.
The Bluetooth word mark and logos are owned by the Bluetooth SIG,
Inc. and any use of such marks by Trimble Navigation Limited is under
license.
Android is a trademark of Google Inc.
Microsoft, Vista, Windows, and Windows Media are either registered
trademarks or trademarks of MicrosoftCorporation in the United States
and/or other countries.
All other trademarks are the property of their respective owners.
Release Notice
This is the January 2013 release (Revision A) of the Trimble Juno T41
handheld documentation.
Limited Warranty Terms and Conditions
Product Limited Warranty
Subject tothe terms and conditions set forth herein, Trimble Navigation
Limited (“Trimble”) warrants that for a period of (1) year from date of
purchase this Trimble product (the “Product”) will substantially conform
to Trimble's publicly available specifications for the Product and that the
hardware and any storage media components of the Product will be
substantially free from defects in materials and workmanship.
Product Software
Product software, whether built into hardware circuitry as firmware,
provided as a standalone computersoftware product, embedded in flash
memory, or stored on magnetic or other media, is licensed solely for use
with or as an integral part of the Product and is not sold. The terms of the
end user license agreement, as included below, govern the use of the
Product Software, including any differing limited warranty terms,
exclusions and limitations, which shall control over the terms and
conditions set forth in the limited Product warranty.
Warranty Remedies
If the Trimble Product fails during the warranty period for reasons
covered by this limited warranty and you notify Trimble of such failure
during the warranty period, Trimble will repair OR replace the
nonconforming Product with new, equivalent to new, or reconditioned
parts or Product, OR refund the Product purchase price paid by you, at
Trimble’s option,upon yourreturn of the Product in accordance with
Trimble's product return procedures then in effect.
How to Obtain Warranty Service
To obtain warranty service for the Product, please contact your Trimble
dealer. Alternatively, you may contact Trimble to request warranty
service at +1-408-481-6940 (24 hours a day) or email your request to
trimble_support@trimble.com. Please be prepared to provide:
– your name, address, and telephone numbers;
– proof of purchase;
– a copy of this Trimble warranty
– a description of the nonconforming Product including the model
number; and
– an explanation of the problem.
The customerservice representative may need additional information
from you depending on the nature of the problem.
Warranty Exclusions and Disclaimer
This Product limited warranty shall only apply in the event and to the
extent that (i) the Product is properly and correctly installed, configured,
interfaced, maintained, stored,and operatedin accordance with
Trimble's applicable operator's manual and specifications, and; (ii) the
Product is not modified ormisused. This Product limited warranty shall
not apply to, and Trimble shall not be responsible for, defects or
performance problems resulting from (i) the combination or utilization of
the Product with hardware or software products, information, data,
systems, interfaces, or devices not made, supplied, or specified by
Trimble; (ii) the operation of the Product under any specification other
than, or in addition to, Trimble's standard specifications for its products;
(iii) the unauthorized installation, modification, or use of the Product; (iv)
damage caused by: accident, lightning or other electrical discharge, fresh
or salt water immersion or spray (outside of Product specifications); or
exposure to environmental conditions for which the Product is not
intended; (v) normal wear and tearon consumable parts (e.g.,
batteries); or (vi) cosmetic damage. Trimble does not warrant or
guarantee the results obtained through the use of the Product or
Software, or that software components will operate error free.
NOTICE REGARDING PRODUCTS EQUIPPED WITH TECHNOLOGY
CAPABLE OF TRACKING SATELLITE SIGNALS FROM SATELLITE BASED
AUGMENTATION SYSTEMS (SBAS) (WAAS, EGNOS, AND MSAS),
OMNISTAR, GPS, MODERNIZED GPS OR GLONASS SATELLITES, OR
FROM IALA BEACON SOURCES: TRIMBLE IS NOT RESPONSIBLE FOR
THE O PERATIO N OR FAILURE OF OPERATION OF ANY SATELLITE
BASED POSITIONING SYSTEM OR THE AVAILABILITY OF ANY
SATELLITE BASED POSITIONING SIGNALS.
THE F OREGOING LIMI TED WARRANTY TERMS STATE TRIMBLE’S
ENTIRE LIABILITY, AND YOUR EXCLUSIVE REMEDIES, RELATINGTO THE
TRIMBLE PRODUCT. EXCEPT AS OTHERWISE EXPRESSLY PROVIDED
HEREIN, THE PRODUCT, AND ACCOMPANYING DOCUMENTATION AND
MATERIALS ARE PROVIDED “AS-IS” AND WITHOUT EXPRESS OR
IMPLIED WARRANTY OF ANY KIND, BY EITHER TRIMBLE OR ANYONE
WHO HAS BEEN INVOLVED IN ITS CREATION, PRODUCTION,
INSTALLATION, OR DISTRIBUTION, INCLUDING, BUT NOT LIMITED TO,
THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR
A PARTICULAR PURPOSE, TITLE, AND NONINFRINGEMENT. THE
STATED EXPRESS WARRANTIES ARE IN LIEU OF ALL OBLIGATIONS OR
LIABILITIES ON THE PART OF TRIMBLE ARISING OUT O F, OR IN
CONNECTION WITH, ANY PRODUCT. BECAUSE SOME STATES AND
JURISDICTIONS DO NOT ALLOW LIMITATIONS ON DURATION OR THE
EXCLUSION OF AN IMPLIED WARRANTY,THE ABOVE LIMITATION
MAY NOT APPLY TO YOU.
Limitation of Liability
TRIMBLE'S ENTIRE LIABILITY UNDER ANY PROVISION HEREIN SHALL BE
LIMITED TO THE AMOUNT PAID BY YOU FOR THE PRODUCT. TO THE
MAXIMUM EXTENT PERMITTED BY APPLICABLE LAW, IN NO EVENT
SHALL TRIMBLE OR ITS SUPPLIERS BE LIABLE FOR ANY INDIRECT,
SPECIAL, INCIDENTAL, OR CONSEQUENTIAL DAMAGE WHATSOEVER
UNDER ANY CIRCUMSTANCE OR LEGAL THEORY RELATING IN ANYWAY
TO THE PRODUCTS, SOFTWARE AND ACCOM PANYING
DOCUMENTATION AND MATERIALS, (INCLUDING, WITHOUT
LIMITATION, DAMAGES FOR LOSS OF BUSINESS PROFITS, BUSINESS
INTERRUPTION, LOSS OF DATA, OR ANY OTHER PECUNIARY LOSS),
REGARDLESS OF WHETHER TRIMBLE HAS BEEN ADVISED OF THE
POSSIBILITY OF ANY SUCH LOSS AND REGARDLESS OF THE COURSE OF
DEALING WHICH DEVELOPS OR HAS DEVELOPED BETWEEN YOU AND
TRIMBLE. BECAUSE SOME STATES AND JURISDICTIONS DO NOT
ALLOW THE EXCLUSION OR LIMITATION OF LIABILITY FOR
CONSEQUENTIAL OR INCIDENTAL DAMAGES, THE ABOVE LIMITATION
MAY NOT APPLY TO YOU.
PLEASE NOTE: THE ABOVE TRIMBLE LIMITED WARRANTY PROVISIONS
WILL NOT APPLY TO PRODUCTS PURCHASED IN THOSE JURISDICTIONS
(E.G., MEMBER STATES OF THE EUROPEAN ECONOMIC AREA) IN
WHICH PRODUCT WARRANTIES ARE THE RESPONSIBILITY OF THE
LOCAL DEALER FROM WHOM THE PRODUCTS ARE ACQUIRED. IN SUCH
A CASE, PLEASE CONTACT YOUR TRIMBLE DEALERFOR APPLICABLE
WARRANTY INFORMATION.
Notice to Australian Purchasers - The Australian Consumer
Law
Our goods come with guarantees that cannot be excluded under the
Australian Consumer Law. You are entitled to a replacement or refund
for a major failure and for compensation for any other reasonably
foreseeable loss or damage. You are also entitled to have the goods
repaired orreplaced if the goods fail to be of acceptable quality and the
failure does not amount to a major failure.
Trimble's warranty, as set out in the user manual accompanying this
statement, oras described in the warranty card accompanying the
Product you purchased, is in addition to any mandatory rights and
remedies that you may have under the Australian Consumer Law.
Trimble Juno T41 User Guide 2

Official Language
THE OFFICIAL LANGUAGE OF THESE TERMS AND CONDITIONS IS
ENGLISH. IN THE EVENT OF A CONFLICT BETWEEN ENGLISH AND
OTHER LANGUAGE VERSIONS,THE ENGLISH LANGUAGE SHALL
CONTROL
Registration
To receive information regarding updates and new products, please
contact your local dealeror visit the Trimble website at
www.trimble.com/register. Upon registration you may select the
newsletter, upgrade, ornew product information you desire.
Notices
FCC Regulations
This device complies with part 15 of the FCC Rules. Operation is subject
to the following two conditions: (1) This device may not cause harmful
interference, and (2) this device must accept any interference received,
including interference that may cause undesired operation.
This device has been tested and found to comply with the limits for a
Class B digital device,pursuant to Part 15 of the FCC Rules. These limits
are designed to provide reasonable protection against harmful
interference in a residential installation. This equipment generates, uses
and can radiate radio frequency energy and, if not installed and used in
accordancewith the instructions, may cause harmful interference to
radio communications. However, there is no guarantee that interference
will not occur in a particular installation if this equipment does cause
harmful interference to radio or television reception, which can be
determined by turning the equipment off and on. The user is
encouraged to try to correct the interference by one or more of the
following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
- Connect the equipment into an outlet on a circuit different from that to
which the receiver is connected.
- Consult the dealeror an experienced radio/TV technician for help.
Changes and modifications not expressly approved by the manufacturer
or registrant of this equipment can void your authority to operate this
equipment under Federal Communications Commission rules.
The radios in this device have been designed and manufactured to not
exceed stipulated emission limits for exposure to radio frequency (RF)
energy as required by the Federal Communications Commission of the
U.S. Government 47 C.F.R. § 2.1091 and 2.1093. The external antenna
connector provided in this device is for GNSS antennas only.
IC
Operation is subject to the following two conditions: (1) this device may
not cause interference, and (2) this device must accept any interference,
including interference that may cause undesired operation of the device.
This Class B digital apparatus complies with Canadian ICES-003.
Cet appareil numérique de la classe B est conforme à la norme NMB-003
du Canada.
This Category II radio communication device complies with Industry
Canada Standard RSS-310.
Ce dispositif de radiocommunication de catégorie II respecte la norme
CNR-310 d’Industrie Canada.
IMPORTANT NOTE:
IC Radiation Exposure Statement
This EUT is compliant with SAR for general population/uncontrolled
exposure limits in IC RSS-102 and had been tested in accordance with
the measurement methods and procedures specified in IEEE 1528. This
equipment should be installed and operated with minimum distance 0.5
cm between the radiator & your body.
This device and its antenna(s) must not be co-located or operating in
conjunction with any other antenna or transmitter. The County Code
Selection feature is disabled for products marketed in the US/Canada.
CE
a. Caution:
• Risk of explosion if battery replaced by an incorrect type.
• Dispose of used batteries according to the instructions.
b. Make sure the temperature for adapter will not be higher than 40 ˚C.
CE SARCompliance
This device meets the EU requirements (1999/519/EC) on the limitation
of exposure of the general public to electromagnetic fields by way of
health protection.
The limits are part of extensive recommendations for the protection of
the general public. These recommendations have been developed and
checked by independent scientific organizations through regular and
thorough evaluations of scientific studies. The unit of measurement for
the European Council's recommended limit for mobile devices is the
"Specific Absorption Rate" (SAR), and the SAR limit is 2.0 W/ kg
averaged over 10 gram of body tissue. It meets the requirements of the
International Commission on Non-Ionizing Radiation Protection (ICNIRP).
For body worn operation, this device has been tested and meets the
ICNIRP exposure guidelines and the European Standard EN 62311 and
EN 62209-2, for use with dedicated accessories. Use of other accessories
which contain metals may not ensure compliance with ICNIRP exposure
guidelines.
Canada
This digital apparatus does not exceed the Class B limits for radio noise
emissions from digital apparatus as set out in the radio interference
regulations of the Canadian Department of Communications.
Le présent appareil numérique n'émet pas de bruits radioélectriques
dépassant les limites applicables aux appareils numériques de Classe B
prescrites dans le règlement sur le brouillage radioélectrique édicté par
le Ministère des Communications du Canada.
Antenna Statement
Under Industry Canada regulations, this radio transmitter may only
operate using an antenna of a type and maximum (or lesser) gain
approved for the transmitter by Industry Canada. To reduce potential
radio interference to other users, the antenna type and its gain should be
so chosen that the equivalent isotropically radiated power (e.i.r.p.) is not
more than that necessary for successful communication. Conformément
à la réglementation d'Industrie Canada, le présent émetteur radio peut
fonctionner avec une antenne d'un type et d'un gain maximal (ou
inférieur) approuvé pour l'émetteur par Industrie Canada. Dans le but de
réduire les risques debrouillage radioélectrique à l'intention des autres
utilisateurs, il faut choisir le type d'antenne et son gain de sorte que la
puissance isotrope rayonnée équivalente (p.i.r.e.) ne dépasse pas
l'intensité nécessaire à l'établissement d'une communication
satisfaisante.
Licence exempt
This device complies with Industry Canada licence-exempt RSS standard
(s). Operation is subject to the following two conditions:
(1) this device may not cause interference, and
(2) this device must accept any interference, including interference that
may cause undesired operation of the device.
Le présent appareil est conforme aux CNR d'Industrie Canada applicables
aux appareils radio exempts de licence. L'exploitation est autorisée aux
deux conditions suivantes :
(1) l'appareil ne doit pas produire de brouillage, et
(2) l'utilisateur de l'appareil doit accepter tout brouillage radioélectrique
subi, même si le brouillage est susceptible d'en compromettre le
fonctionnement.
Europe / EUConformance
The following CE compliance
information is applicable to this device
that carry the following CE mark:
This product has been tested and found to comply with all requirements
for CE Marking and sale within the European EconomicArea (EEA).
The Trimble Juno T41 has Bluetooth wireless technology approval in
most EU countries and satisfies the requirements for Radio and
Telecommunication Terminal Equipment specified by European Council
Directive 1999/5/EC. These requirements provide reasonable protection
against harmful interference when the equipment is operated
appropriately in a residential or commercial environment.
Juno T41 handhelds equipped with wireless cellular modem radios are
intended forconnection to European Networks operating with GSM 900,
or GSM 1800. A copy of the CE Declaration of Conformity for the Juno
T41handheld can be accessed from
http://www.trimble.com/support.shtml.
Australia and New Zealand
This product conforms with the regulatory requirements of
the Australian Communications Authority (ACA) EMC and
Radiocommunications framework, thus satisfying the
requirements for C-Tick Marking and sale within Australia and New
Zealand.
Additionally, Juno T41 3.5G products that incorporate a
modem also comply with the requirements for A-Tick
Marking and sale in Australia.
Trimble Juno T41 User Guide 3

Taiwan – Battery Recycling Requirements
The product contains a removable Lithium-ion polymer battery.
Taiwanese regulations require that waste batteries are
recycled.
廢電 池請回收
European Union Customers:(WEEE)
Forproduct recycling instructions and more information, please go to
www.trimble.com/ev.shtml.
Recycling in Europe: To recycle Trimble WEEE (Waste Electrical and
Electronic Equipment, products that run on electrical power.), Call +31
497 53 24 30, and ask for the "WEEE Associate". Or, mail a request for
recycling instructions to:
Trimble Europe BV
c/o Menlo Worldwide Logistics
Meerheide 45
5521 DZ Eersel, NL
Trimble Juno T41 User Guide 4

Safety Information
Radio use
Depending on the model, the Trimble® Juno® T41handheld contains a Bluetooth® radio, a Wi-Fi
radio, and a cellular modem radio. In some situations, you may be required to turn off the radios.
For example, aviation authority regulations restrict the use of wireless transmission devices on
board aircraft.
To prevent the handheld from emitting radio signals, do one of the following:
lTo turn off the handheld, press and hold the Power button for 3 seconds to display the Phone
options menu, then tap .Power off
lTo put the handheld in airplane mode, press and hold the Power button for 3 seconds to
display the Phone options menu, then tap Airplane mode. This mode turns off all wireless
connections.
lTo turn off the Bluetooth, Wi-Fi, and wireless cellular modem radios only:
a. On the screen, tap , then tapHome Settings Wireless & networks.
b. If any radios are on, tap them to turn them off.
Note – You may need to deactivate the Wi-Fi and/or Bluetooth radio in the handheld if the country
in which you are working does not approve the use of Wi-Fi and/or Bluetooth wireless technology.
If you are unsure about whether the Juno T41 handheld’s radios are approved for use in your
country, check with your Trimble reseller.
RF Exposure Information (SAR)
This device meets the government’s requirements for exposure to radio waves. This device is
designed and manufactured not to exceed the emission limits for exposure to radio frequency (RF)
energy set by the Federal Communications Commission of the U.S. Government. The exposure
standard for wireless devices employs a unit of measurement known as the Specific Absorption
Rate, or SAR. The SAR limit set by the FCC is 1.6W/kg. Tests for SAR are conducted using standard
operating positions accepted by the FCC with the device transmitting at its highest certified power
level in all tested frequency bands. Although the SAR is determined at the highest certified power
level, the actual SAR level of the device while operating can be well below the maximum value. This is
because the device is designed to operate at multiple power levels so as to use only the poser
required to reach the network. In general, the closer you are to a wireless base station antenna, the
lower the power output.
The highest SAR value for the device as reported to the FCC when worn on the body, as described in
the user guide, is no more than 0.39 W/kg for GSM850 / 1.23 W/kg for PCS1900 (Body-worn
measurements differ among device models, depending upon available accessories and FCC
requirements.) While there may be differences between the SAR levels of various devices and at
various positions, they all meet the government requirement. The FCC has granted an Equipment
Authorization for this device with all reported SAR levels evaluated as in compliance with the FCC RF
exposure guidelines.
This device is compliant with SAR for general population /uncontrolled exposure limits in ANSI/IEEE
C95.1-1999 and had been tested in accordance with the measurement methods and procedures
specified in OET Bulletin 65 Supplement C. For body worn operation, this device has been tested
Trimble Juno T41 User Guide 5

and meets the FCC RF exposure guidelines for use with an accessory that contains no metal and the
positions the handset a minimum of 0.5 cm from the body. Use of other accessories may not ensure
compliance with FCC RF exposure guidelines. If you do not use a body-worn accessory and are not
holding the device at the ear, position the handset a minimum of 0.5 cm from your body when the
device is switched on.
Exposure to radio frequency radiation from Bluetooth and Wi-Fi transmitters
This device is approved as a portable device with respect to Radio Frequency (RF) exposure
compliance. The radiated output power of the internal wireless radio transmitters is less than 100
milliwatt, which results in exposure levels far below the FCC radio frequency exposure limits, even
when operated in close proximity to the body. The internal wireless radios operate within guidelines
found in international radio frequency safety standards and recommendations, which reflect the
consensus of the international scientific community. Trimble therefore believes the internal wireless
radios are safe for use by users. The level of electromagnetic energy emitted is hundreds of times
lower than the electromagnetic energy emitted by wireless devices such as mobile phones.
However, the use of wireless radios may be restricted in some situations or environments, such as
on aircraft. If you are unsure of restrictions, you are encouraged to ask for authorization before
turning on the wireless radios.
Exposure to radio frequency radiation from cellular wireless transmitters
Juno T41 handhelds equipped with wireless cellular modem radios have been designed and
manufactured to meet safety requirements for limiting exposure to radio waves. When used in
accordance with the instructions set forth in this manual, the equipment has been independently
verified to not exceed the emission limits for safe exposure to radio frequency (RF) energy as
specified by the Federal Communications Commission of the U.S. Government in 47 CFR §2.1093.
These limits are part of comprehensive guidelines and establish permitted levels of RF energy for the
general population. The guidelines are based on standards that were developed by independent
scientific organization through periodic and thorough evaluation of scientific studies. The standards
include a substantial safety margin designed to assure the safety of all persons, regardless of age
and health.
ACAdaptor safety
To charge the handheld’s battery, use the USB / power cable and adaptor kit provided with the
handheld (see Powering the handheld, page 12).
WARNING -To use ACadaptors safely
– Use only the AC adaptor intended for the handheld. Using any other AC adaptor can damage the handheld and
may void your warranty. Do not use the AC adaptor with any other product.
– Make certain that the input voltage on the adaptor matches the voltage and frequency in your location.
– Make certain that the adaptor has prongs compatible with your outlets.
– Do not use the AC adaptor in wet outdoor areas; it is designed for indoor use only.
– Unplug the AC adaptor from power when not in use.
Trimble Juno T41 User Guide 6

Electrostatic discharge
WARNING - Static electricity can harm electronic components inside your handheld. To prevent static damage:
- Discharge static electricity from your body before you touch any of the electronic components inside your device,
such as a memory module. You can do so by touching an unpainted metal surface.
The handheld is designed for outdoor conditions; however under conditions of low humidity
extremely high voltage discharge events are possible. Users are advised that the risk of causing
discharge to sensitive electronics can be minimized by avoiding finger contact to the recessed
connectors on the unit.
Battery safety
The rechargeable Lithium-ion polymer battery is supplied partially charged. Charge the battery
completely before using it for the first time (see Powering the handheld, page 12). If the battery has
been stored for longer than six months, charge it before use.
WARNING- Use only the battery intended for the product. Using any other battery can damage the handheld and
may void your warranty. If the battery becomes damaged or stops charging fully, replace it with a new battery.
WARNING - Do not damage the rechargeable Lithium-ion polymer battery. A damaged battery can cause an
explosion or fire, and can result in personal injury and/or property damage.
To prevent injury or damage:
–Do not use or charge the battery if it appears to be damaged. Signs of damage include, but are not limited to,
discoloration, warping, and leaking battery fluid.
–Do not store or leave your device near a heat source such as near a fireplace or other heat-generating
appliance, or otherwise expose it to temperatures in excess of 70 °C (158 °F) such as on a vehicle dashboard.
When heated to excessive temperatures, battery cells could explode or vent, posing a risk of fire.
–Do not immerse the battery in water.
–Do not use or store the battery inside a vehicle during hot weather.
–Do not drop or puncture the battery.
–Do not open the battery or short-circuit its contacts.
WARNING -Avoid contact with the rechargeable Lithium-ion polymer battery if it appears to be leaking. Battery
fluid is corrosive, and contact with it can result in personal injury and/or property damage.
To prevent injury or damage:
–If the battery leaks, avoid contact with the battery fluid.
–If battery fluid gets into your eyes, immediately rinse your eyes with clean water and seek medical attention.
Do not rub your eyes!
–If battery fluid gets onto your skin or clothing, immediately use clean water to wash off the battery fluid.
WARNING -Charge and use the rechargeable Lithium-ion polymer battery only in strict accordance with the
instructions. Charging or using the battery in unauthorized equipment can cause an explosion or fire, and can
result in personal injury and/or equipment damage.
To prevent injury or damage:
–Do not charge or use the battery if it appears to be damaged or leaking.
–Charge the Lithium-ion polymer battery only in a Trimble product that is specified to charge it. Be sure to follow
Trimble Juno T41 User Guide 7

all instructions that are provided with the battery charger.
–Discontinue charging a battery that gives off extreme heat or a burning odor.
–Use the battery only in Trimble equipment that is specified to use it.
–Use the battery only for its intended use and according to the instructions in the product documentation.
Storage card use
The handheld provides a storage card slot, providing an alternative storage location to the storage
memory in the handheld.
WARNING - Static electricity can harm electronic components inside your handheld. To prevent static damage:
- Discharge static electricity from your body before you touch any of the electronic components inside your device,
such as a memory module. You can do so by touching an unpainted metal surface.
WARNING- The presence of any dust or moisture in the memory card slot may adversely affect the device and
void your Trimble warranty. To prevent dust or moisture entering the memory card slot:
– Make certain that the storage card slot door is attached correctly when you are using the handheld outdoors.
–When inserting or removing a memory card, place the handheld on a dust-free indoor surface.
Trimble Juno T41 User Guide 8

About the Trimble Juno T41 handheld
The Trimble Juno T41 rugged handheld combines
a high sensitivity GNSS receiver with, depending
on the model of handheld, an integrated
3.75Gcellular modem, Bluetooth® wireless
technology, and Wi-Fi connectivity.
The Juno T41 handheld is powered by the
Android™ 2.3.4 operating system, is rated IP65 or
IP68 depending on the model, and has an
integrated 8MP camera with geotagging and dual
LED flash.
The integrated GNSS receiver provides accurate 2-
4 meter positioning information with
postprocessed or real-time differential
corrections. For more information, see Using the
GNSS receiver, page 36.
About this user guide
This user guide describes how to set up and use the Juno T41 handheld. The information in this
guide supplements the information in the Juno T41 Quick Start Guide, which you received with the
handheld.
Even if you have used other Global Navigation Satellite System (GNSS) or Global Positioning System
(GPS) products before, Trimble recommends that you spend some time reading this guide to learn
about the special features of the product.
Use and care of the handheld
When using the handheld:
lProtect the touch screen by using your finger or the capacitive stylus, and avoid using excessive
pressure and sharp or abrasive objects. To protect the touch screen from pressure and
abrasive objects, Trimble recommends that you apply a screen protector.
lKeep the outer surface free of dirt and dust.
lEnsure that the protective covers are appropriately fitted to the external antenna port, and
SIM / memory card slot, so that they are kept free from dirt, dust, fluid ingress, and
electrostatic discharge.
lProtect the handheld from extreme temperatures. For example, do not leave the handheld on
the dashboard of a vehicle.
lDepending on the model, the handheld is rated IP65 or IP68, but is not waterproof. Do not
immerse the handheld in water, and be careful not to drop the handheld or subject it to any
strong impact.
To clean the handheld, wipe it with a clean dry cloth.
Trimble Juno T41 User Guide 9

Technical assistance
Go to the Juno T41handheld webpage on the Trimble website www.trimble.com/Outdoor-Rugged-
Computers/junot41.aspx for the latest support information, including:
lsupport notes detailing support issues
ldocumentation
lthe latest files available for download
Additional help
If you still cannot find the information that you need, contact your Trimble reseller.
Parts of the Juno T41 handheld
This section describes the main features of the Juno T41 handheld, and provides the information
you need to get up and running with the handheld.
❶Power button ❼Charge / Notification LED
❷Headset connector ❽Microphone
❸Volume / Action buttons ❾Camera and flash
❹MicroSD and SIMcard slot ❿Speaker
❺Touch screen ⓫I/O / Power connector
❻GNSS antenna port ⓬Buttons:Home, Menu, Back, Search
Trimble Juno T41 User Guide 10

Powering the handheld
The Juno T41 handheld contains a rechargeable Lithium-ion polymer battery.
Note – Charge the battery completely before using the handheld for the first time. If the battery
has been stored for longer than six months, charge it before use. Trimble recommends charging
the battery for four hours to recharge it fully.
Note – Cold temperatures, or using Bluetooth wireless technology, Wi-Fi, or the cellular modem
consume additional battery power and so shortens battery life between charges.
Battery safety
WARNING- Use only the battery intended for the product. Using any other battery can damage the handheld and
may void your warranty. If the battery becomes damaged or stops charging fully, replace it with a new battery.
WARNING - Do not damage the rechargeable Lithium-ion polymer battery. A damaged battery can cause an
explosion or fire, and can result in personal injury and/or property damage.
To prevent injury or damage:
–Do not use or charge the battery if it appears to be damaged. Signs of damage include, but are not limited to,
discoloration, warping, and leaking battery fluid.
–Do not store or leave your device near a heat source such as near a fireplace or other heat-generating
appliance, or otherwise expose it to temperatures in excess of 70 °C (158 °F) such as on a vehicle dashboard.
When heated to excessive temperatures, battery cells could explode or vent, posing a risk of fire.
–Do not immerse the battery in water.
–Do not use or store the battery inside a vehicle during hot weather.
–Do not drop or puncture the battery.
–Do not open the battery or short-circuit its contacts.
WARNING -Avoid contact with the rechargeable Lithium-ion polymer battery if it appears to be leaking. Battery
fluid is corrosive, and contact with it can result in personal injury and/or property damage.
To prevent injury or damage:
–If the battery leaks, avoid contact with the battery fluid.
–If battery fluid gets into your eyes, immediately rinse your eyes with clean water and seek medical attention.
Do not rub your eyes!
–If battery fluid gets onto your skin or clothing, immediately use clean water to wash off the battery fluid.
WARNING -Charge and use the rechargeable Lithium-ion polymer battery only in strict accordance with the
instructions. Charging or using the battery in unauthorized equipment can cause an explosion or fire, and can
result in personal injury and/or equipment damage.
To prevent injury or damage:
–Do not charge or use the battery if it appears to be damaged or leaking.
–Charge the Lithium-ion polymer battery only in a Trimble product that is specified to charge it. Be sure to follow
all instructions that are provided with the battery charger.
–Discontinue charging a battery that gives off extreme heat or a burning odor.
–Use the battery only in Trimble equipment that is specified to use it.
–Use the battery only for its intended use and according to the instructions in the product documentation.
Trimble Juno T41 User Guide 11

Charging the battery
1. Connect the AC power adaptor to the Power socket on the handheld and then connect the
adaptor to main power. An international adaptor kit is provided with the handheld.
2. Check that the Charge / Notification LED on the handheld is solid orange, indicating that the
handheld is properly connected to the power source and the battery is charging.
Fully charging the battery from empty takes approximately four hours.
The Charge / Notification LED on the handheld indicates the battery power or charging status, and
operating system notifications, as shown below:
LEDState Handheld / battery state
Solid orange Battery is charging.
Flashing orange Battery is charging, operating system notification; or, operating system
notification, battery is not charging.
Solid red Low battery charge.
Flashing red Low battery charge, operating system notification.
Solid green Battery fully charged.
Flashing green Battery fully charged, operating system notification.
Avoid keeping the battery at full charge at high temperatures. For more information, see Use and
care of the handheld, page 10.
Note – The life of the battery can be significantly shortened if power is constantly supplied to the
handheld. To avoid this issue, connect the handheld to an external power source only when the
battery requires charging. Once fully charged, disconnect the external power source and allow the
battery to discharge through normal use.
Turning on and turning off the handheld
To turn on the handheld, press the button until the screen lights up.Power
To completely shut down the handheld, press and hold the button until thePower Phone options
menu appears, and then tap . All running applications are shut down, and the handheld isPower off
completely turned off.
You can also use the menu to put the handheld into silent mode or airplane mode.Phone options
Checking the level of battery power
To check the level of battery power remaining at any time while the handheld is on:
1. On the Home screen, tap the Launcher icon .
2. In the Launcher, tap /Settings About phone.
3. Tap .Status
The Status screen shows the battery status and battery level.
Trimble Juno T41 User Guide 12

Conserving power
Trimble recommends that you do the following to reduce power consumption:
lSet the handheld to automatically turn off when idle. For more information, see Display
settings, page 25.
lReduce the brightness setting for the backlight. For more information, see Display settings,
page 25.
lTurn off the integrated Bluetooth and Wi-Fi radios, and the handheld's cellular modem,
whenever you are not using them. For more information, see Turning on and turning off the
integrated radios, page 30.
Note – Do not disconnect from GNSS if you will be reconnecting within about five minutes. A GNSS
application can take up to 30seconds to reactivate the integrated GNSS receiver, so disconnecting
to save power can cost time.
Resetting the handheld to factory defaults
You can factory-reset the Juno T41 handheld if you forget the password that you use to lock the
device, or to delete all of your personal data from the handheld's internal storage, system and
application settings, and any downloaded applications.
Performing a factory data reset does not delete any system software updates.
1. On the Home screen, tap Settings Privacy Factory data reset, then tap / .
2. If required, select the checkbox to delete data on the SD card.
3. Tap Reset phone.
Storing data
The handheld has several types of memory available:
lProgram memory is similar to the RAM in a computer, and is used for running apps. You
cannot use it to save data.
lInternal storage is used for storing applications and private app data.
lInternal SD card is similar to the hard disk in a computer and is used for storing data and/or
apps.
lRemovable SD card refers to micro SD cards inserted into the handheld's removable SD card
slot.
The Juno T41 handheld's internal storage is where most applications and private data for those
applications are stored. The operating system manages and carefully guards internal storage,
because it can contain your private information; you cannot view its contents when you connect
the handheld to a computer with a USB cable.
The handheld's internal SD card (sometimes just called "SD card") is the primary non-removable
storage for data files. Some applications are also designed to be stored on this card, rather than in
internal storage, by default or as an option. This storage medium is actually an internal eMMC
component. It is referred to as an SD card and mounted as /sdcard in order to maintain Android
Trimble Juno T41 User Guide 13

compatibility. When the Juno T41 handheld is connected to a computer (see Connecting to an office
computer, page 29), you can copy files to and from the internal SD card.
The handheld also has a slot for a removable SD card. When a removable card is inserted, it is
mounted as /removablesdcard. Like the internal SD card, this storage device is accessible when the
Juno T41 handheld is connected to a computer.
To check the memory capacity on the handheld, in the Launcher, tap / .Settings Storage
Trimble recommends that you regularly copy important data to an office computer. For more
information, see Connecting to an office computer, page 29.
Deleting data
To quickly delete all data on the SD card, in the Launcher, tap , and then tap /Settings Storage Erase
internal SD card.
To quickly delete all the data on the handheld:
1. In the Launcher, tap , and then tap / .Settings Privacy Factory data reset
2. If you want to delete all the data on the SD card, select the option.Erase internal SDcard
Otherwise, leave this option unselected.
3. Tap .Reset phone
Memory cards
As an alternative to storage memory, you can save data to a memory card. Use a MicroSD memory
card to securely transfer data to and from another device that supports MicroSD memory cards.
WARNING- The presence of any dust or moisture in the memory card slot may adversely affect the device and
void your Trimble warranty. To prevent dust or moisture entering the memory card slot:
– Make certain that the storage card slot door is attached correctly when you are using the handheld outdoors.
–When inserting or removing a memory card, place the handheld on a dust-free indoor surface.
WARNING - Static electricity can harm electronic components inside the handheld. To prevent static damage,
discharge static electricity from your body before you touch any of the electronic components inside your device,
such as a memory module. You can do so by touching an unpainted metal surface.
To insert a memory card:
1. Turn off the handheld. See Turning on and turning off the handheld, page 13
2. In a dust-free indoor environment, remove the two small screws to remove the memory card
slot cover (on the left side of the handheld).
3. Insert the memory card into the card slot with the gold contacts facing up.
4. Replace the cover, tightening the two small screws.
5. When you select the Save As option in an application, the memory card appears in the list of
available storage locations as /removablesdcard.
Trimble Juno T41 User Guide 14
Produkt Specifikationer
Mærke: | Trimble |
Kategori: | Stregkodelæser |
Model: | Juno T41 M |
Kode for international beskyttelse (IP): | IP68 |
Bredde: | 82 mm |
Dybde: | 25 mm |
Højde: | 155 mm |
Vægt: | 400 g |
Produktfarve: | Black, Grey |
Batterikapacitet: | 3300 mAh |
Skærm diagonal: | 4.3 " |
Skærmopløsning: | 480 x 800 pixel |
Berøringsskærm: | Ja |
Kompatible hukommelseskort: | MicroSD (TransFlash), MicroSDHC |
Batteriteknologi: | Lithium polymer (LiPo) |
Opbevaringstemperatur (T-T): | -40 - 70 °C |
Relativ luftfugtighed ved drift (H-H): | 0 - 90 % |
Antal USB 2.0-porte: | 1 |
Udgange til hovedtelefoner: | 1 |
Driftstemperatur (T-T): | -30 - 60 °C |
Skærm: | TFT |
Intern hukommelse: | 0.512 GB |
Kabler inkluderet: | USB |
Operativsystem installeret: | Windows Embedded Handheld 6.5 |
Certificering: | FCC, CE, R&TTE, IC (Canada), A-tick, C-tick, GCF, RoHS, Section 508, PTCRB, SAR, AT&T network, Wi-Fi Alliance certified, CCX, MIL-STD-810G, IP65/IP68, MIL-STD-461E |
Batterilevetid (maks.): | 12 t |
GPS (satellit): | Ja |
Processorfrekvens: | 0.806 GHz |
Intern hukommelsestype: | SDRAM |
Flash-hukommelse: | 8 GB |
Indbygget mikrofon: | Ja |
Processorproducent: | Texas Instruments |
Maksimal størrelse på hukommelseskort: | 32 GB |
Tilslutning af hovedtelefoner: | 3,5 mm |
Infrarød dataport: | Ja |
Højttalere: | Ja |
Indbygget flash: | Ja |
Indbygget processer: | Ja |
Stemmeoptagelse: | Ja |
Telefonfunktion: | Ingen |
Tastaturopsætning: | Numerisk |
GPS nøjagtighed - position: | 4 m |
Intern modem: | Ja |
RFID-læser: | Ingen |
Stregkodelæser: | Ja |
Har du brug for hjælp?
Hvis du har brug for hjælp til Trimble Juno T41 M stil et spørgsmål nedenfor, og andre brugere vil svare dig
Stregkodelæser Trimble Manualer
16 August 2024
9 August 2024
8 August 2024
7 August 2024
6 August 2024
Stregkodelæser Manualer
- ZBA
- Datamax-O'neil
- Brady
- Tecno
- CipherLab
- Posiflex
- Digitus
- Metapace
- Manhattan
- Deltaco
- Motorola
- Unitech
- POSline
- IC Intracom
- Mach Power
Nyeste Stregkodelæser Manualer
7 August 2025
5 August 2025
5 August 2025
5 August 2025
5 August 2025
5 August 2025
5 August 2025
5 August 2025
2 August 2025
2 August 2025
