Owner’s Manual
DVI Over Cat5
2x2 Matrix Switch
Model: B140-202
1111 W. 35th Street, Chicago, IL. 60629 • www.tripplite.com/support
Copyright © 2012 Tripp Lite. All rights reserved.
Package Contents 2
Product Features 2
Mounting 4
Standard Installation 5
Remote Repeater Installation 7
Troubleshooting 9
Warranty & Warranty Registration 12
WARRANTY
REGISTRATION
Register online today for a
chance to win a FREE Tripp Lite
product www.tripplite.com/warranty
12-09-067-93323B.indd 1 11/9/2012 4:50:28 PM
2
Package Contents
Product Features
• B140-202 Local Transmitter Unit
• External Power Supply
(Input: 100-240V, 50/60Hz, 0.5A Output: 5V, 2A)
• Mounting Hardware
• Remote Control
• Owner’s Manual
• Share two DVI-D Single-Link sources between two monitors
• Allows either input to be routed to either output or the same input to be
routed to both outputs
• Transmits the signal over one Cat5e/6 cable to a remote monitor up to
200 ft. away
• A B140-Series remote receiver is needed at each monitor
• For longer distances: Use a B140-1A0 or B140-1A0-WP active remote
receiver to extend a 1920 x 1080 @ 60Hz signal up to 150 ft. from
the transmitter (or a 1024 x 768 @ 60Hz signal up to 200 ft. from the
transmitter)
• For shorter distances: Use a B140-1P0 or B140-1P0-WP passive
remote receiver to extend a 1920 x 1080 @ 60Hz signal up to 50 ft.
from the transmitter (or a 1024 x 768 @ 60Hz signal up to 100 ft. from
the transmitter)
• Use 24AWG, Solid Wire Cat5e/6 cable, such as Tripp Lite’s N202-Series,
to achieve maximum distance and resolution
• Further expand the range and number of monitors by adding B140-110
remote repeater units
• Add up to three repeaters on each of the B140-202 channels, for a total
of 4 displays per channel (An active remote receiver should be the last
unit in a channel)
12-09-067-93323B.indd 2 11/9/2012 4:50:28 PM
