Side 1/36

Table of Contents

1. Important Safety Instructions 2

2. Overview 2

3. Feature Identification 3

4. Enclosure Installation 4

4.1 Preparation 4

4.2 Unpacking 4

4.3 Ground Connection 5

5. Enclosure Configuration 5

5.1 Door Locks 5

5.2 Cable Access and Management 5

5.3 Mounting Rails 6

5.4 Adjusting Mounting Rail Depth 6

6. Wall Mounting the Enclosure 7

7. Equipment Installation 10

8. Specifications 10

8.1 Unit Dimensions 10

8.2 Package Dimensions 10

9. Storage and Service 11

10. Warranty and Product Registration 11

Español 12

Francais 23

SmartRack

NEMA-4 Wall-Mount

Swinging Cabinet

General-Use Industrial Control

Models: SRN4G6US, SRN4G9US, SRN4G9USDP,

SRN4G12US, SRN4G12USDP

(Agency Series Number: AG-060A)

Owner’s Manual

WARRANTY REGISTRATION

automatically entered to win an ISOBAR

surge protector in our monthly drawing!

tripplite.com/warranty

1111 W. 35th Street, Chicago, IL 60609 USA • tripplite.com/support

• The enclosure is extremely heavy. Use caution when handling the enclosure. Do not attempt to unpack, move or install it

unassisted. Use a mechanical device such as a forklift or pallet jack to move the enclosure in the shipping container.

• Do not place any object on the enclosure, especially containers of liquid, and do not attempt to stack the enclosures.

• Inspect the shipping container and the enclosure for shipping damage. Do not use the enclosure if it is damaged.

• Leave the enclosure in the shipping container until it has been moved as close to the ﬁnal installation location as possible.

• Install the enclosure in a structurally sound area capable of handling the load, or on a level ﬂoor that is able to bear the

weight of the enclosure, all equipment that will be installed in the enclosure and any other enclosures and/or equipment that

will be installed nearby.

• This enclosure supports a maximum Conduit Trade Size 2 with a 2.5 inch hole.

• Use only NEMA 4 (or higher) rated conduit/ﬁttings to maintain the enclosure’s environmental protection rating.

• For permanent wall mounting, be sure to securely fasten the enclosure to the building structure before operation.

• Use caution when cutting packing materials. The enclosure could be scratched, causing damage not covered by the

warranty.

• Save all packing materials for later use. Repacking and shipping the enclosure without the original packing materials may

cause product damage that will void the warranty.

• Use of this equipment in life support applications where failure of this equipment can reasonably be expected to cause the

failure of the life support equipment or to signiﬁcantly affect its safety or effectiveness is not recommended.

Swinging wall-mounted NEMA 4 enclosures accommodate all standard 19-inch rack-mount equipment, regardless of vendor,

and ship fully assembled for quick and easy deployment. They have a NEMA 4 rating for protection against falling dirt, rain,

sleet, snow, windblown dust, splashing water, hose-directed water and external formation of ice. They feature adaptable,

heavy-duty cabinets in various heights. All models have a hinged design that lets the cabinet swing away from the wall bracket

for easy equipment access.

Swinging wall-mounted NEMA 4 enclosures have variable mounting depths, ideal for servers. The cabinets include a lockable,

removable front door and hinged swing cabinet body for convenient maintenance.

1. Important Safety Instructions

2. Overview

SAVE THESE INSTRUCTIONS

This manual contains instructions and warnings that must be followed during the installation and operation of

the product described in this manual. Failure to comply may invalidate the warranty and cause property damage

or personal injury.

Produkt Specifikationer

Mærke:	Tripp Lite
Kategori:	Server
Model:	SRN4G9US
Type:	Vægmonteret stativ
Bredde:	609.6 mm
Dybde:	763.3 mm
Højde:	478.3 mm
Vægt:	48440 g
Brugervejledning:	Ja
Produktfarve:	Grå
Pakkevægt:	72570 g
Pakkedybde:	863.6 mm
Pakkebredde:	711.2 mm
Pakkehøjde:	616 mm
Materiale:	Stål
Harmoniseret systemkode (HS):	8517.62.0090
Bæredygtighedscertifikater:	RoHS, REACH
Oprindelsesland:	Kina
Produkter pr. hovedkasse (udvendigt):	1 stk
Overholdelse af bæredygtighed:	Ja
Maksimal vægtkapacitet:	91 kg
Skruer inkluderet:	Ja
Rackkapacitet:	9U
Antal skruer:	24
Installationsmuligheder:	Vægmonteret
Nøglelås:	Ja
