This is a standard SFP optical module. It uses two single mode optical fibers and the speed
rate can up to 1.25Gbps, transmission distance up to 20km. This product need to use in pair
and match up with fiber converter and optical Ethernet switch with SFP port, it can be used in
Ethernet, telecom and optical fiber communication and other industries...
Please check the following items before installation. If any missing, please contact the dealer.
SFP Optical Module,1.25G Double Optical Fibers 20km 1pc
User manual 1pc
P
P
P
P Pl
l
l
lle
e
e
eea
a
a
aase f
se f
se f
se fse fo
o
o
ool
l
l
lll
l
l
llo
o
o
oow t
w t
w t
w tw th
h
h
hhe f
e f
e f
e fe fo
o
o
ooll
ll
ll
llllo
o
o
oow
w
w
wwi
i
i
iin
n
n
nng s
g s
g s
g sg st
t
t
tte
e
e
eep
p
p
pp
1) Please turn off the signal source and the device's power, installation with power on may
damage the device;
2) Plug 1.25G double optical fibers 20km SFP optical module into SFP socket;
3) Check if the installation is correct and device is good, make sure all the connection is
reliable and power up the system;
4) Make sure the optical communication is normal.
Use SFP packaging form LC connector support SFF8472 standard , , ;
Support hot plug ;
Use1310 FP laser and PIN-TIA ;
The data transmission distance of single mode optical fiber can up to 20km ;
Data input and output ports are comply with the low voltage emitter coupled logic(LVPECL) standard;
Low electromagnetic interference to the environment, strong ESD protection;
Meet IEC-60825 laser safety standard;
Meet RoHS standard.
2
连
连
连
连连接
接
接
接接接
接
接
接接口
口
口
口口
S
S
S
SSp
p
p
ppe
e
e
eec
c
c
cci
i
i
iif
f
f
ffi
i
i
iic
c
c
cca
a
a
aat
t
t
tti
i
i
iio
o
o
oon
n
n
nn
Product are subject to change without prior notice
T
T
T
TTr
r
r
rro
o
o
oou
u
u
uub
b
b
bbl
l
l
lle
e
e
ee S
S
S
SSh
h
h
hho
o
o
ooo
o
o
oot
t
t
tti
i
i
iin
n
n
nng
g
g
gg
Please confirm if the installation is correct;
Please confirm the module plugged is match with the requirement;
If the problem still exist, please contact the factory.
P
P
P
PPl
l
l
lle
e
e
eea
a
a
aase f
se f
se f
se fse fi
i
i
iin
n
n
nnd t
d t
d t
d td th
h
h
hhe f
e f
e f
e fe fo
o
o
ool
l
l
lllo
lo
lo
lolow
w
w
wwi
i
i
iin
n
n
nng s
g s
g s
g sg so
o
o
ool
l
l
llu
u
u
uuti
ti
ti
titio
o
o
oon w
n w
n w
n wn wh
h
h
hhe
e
e
een t
n t
n t
n tn th
h
h
hhe d
e d
e d
e de dev
ev
ev
evevi
i
i
iic
c
c
cce d
e d
e d
e de do
o
o
ooe
e
e
ees
s
s
ssn
n
n
nn't w
't w
't w
't w't wo
o
o
oor
r
r
rrk
k
k
kk
Item
Description
Power
Power Supply
The Host Power Supply
Voltage Range
DC 3.15V～3.45V
Consumption
1W
Optical
Characteristics
Optical Wave Length
1310nm
Emission Light Power
- ～-3dBm8
Receiver Sensitivity
-24 dBm
Transmission
Characteristics
Optical Fiber Type
Single mode 9/125um
Optical Fiber Port
LC
Transmission Distance
Single mode 20km
Protection
ESD
1a contact discharge 3 level
1b air discharge 3 level
Per：IEC61000-4-2
Environmental
Working Temperature
0℃~70℃
Storage Temperature
-40℃~70℃
Humidity (Non-
0~95%
Mechanical
Dimension (L×W×H)
55.4mm×13.7mm×6.25mm
Material
Stainless steel
Color
White
Weight
17g
SFP Optcial Module

Produkt Specifikationer

Mærke: UTEPO
Kategori: Ikke kategoriseret
Model: SFP-1.25G-20KM
Bredde: 55.4 mm
Dybde: 13.7 mm
Højde: 6.25 mm
Vægt: 17 g
Produktfarve: Hvid
Opbevaringstemperatur (T-T): -40 - 70 °C
Relativ luftfugtighed ved drift (H-H): 0 - 95 %
Driftstemperatur (T-T): 0 - 70 °C
Husmateriale: Stål
Indgangsspænding: 3.15 V
Maksimal dataoverførselshastighed: 1250 Mbit/s
SFP modtagertype: Fiberoptisk
Grænsefladetype: SFP
Fiber optisk strømstik: LC
Fiber kabeldiametre understøttes (kerne/beklædning): 9/125 µm
Enkelttilstand fiber (SMF) understøttet: Ingen
Multitilstand fiber (MMF) understøttet: Ingen
Maksimal overførselsafstand: 20000 m
Bølgelængde: 1310 nm
Maksimal spænding: 3.45 V

Har du brug for hjælp?

Hvis du har brug for hjælp til UTEPO SFP-1.25G-20KM stil et spørgsmål nedenfor, og andre brugere vil svare dig


Ikke kategoriseret UTEPO Manualer

UTEPO
