MODEL VT-2412
SKU 23465, 23466
INPUT VOLTAGE DC: 12-24V
RATED LOAD 60W
INPUT CHANNEL 1 Channel
MAX OUTPUT
CURRENT 6A
MAX OUTPUT
POWER 72W/12V, 144W/24V (Max)
TYPE OF CONTROL By Touch
FUNCTIONS On/O and Dimming
DIMMING RANGE 10%-100%
CABLE LENGTH 1000mm
SURFACE
THICKNESS
≤25mm
(Applied to chipboard)
In case of any query/issue with the product, please reach out to us at: support@v-tac.eu
For More products range, inquiry please contact our distributor or nearest dealers.
V-TAC EUROPE LTD. Bulgaria, Plovdiv 4000, bul.L.Karavelow 9B
MULTI-LANGUAGE
MANUAL QR CODE
Please scan the QR code
to access the manual in
multiple languages.
INSTRUCTION MANUAL
HIDDEN TOUCH DIMMING SWITCH
TECHNICAL DATA
INTRODUCTION & WARRANTY
Thank you for selecting and buying V-TAC product. V-TAC will serve you the best. Please read these instructions
carefully before starting the installation and keep this manual handy for future reference. If you have any another
query, please contact our dealer or local vendor from whom you have purchased the product. They are trained
and ready to serve you at the best. The warranty is valid for 2 years from the date of purchase. The warranty
does not apply to damage caused by incorrect installation or abnormal wear and tear. The company gives no
warranty against damage to any surface due to incorrect removal and installation of the product.
V-TAC LED
STRIP LIGHTS
COMPATIBLE WITH
This marking indicates that this
product should not be disposed
of with other household wastes.
Caution, risk of electric shock.
WORKING
TEMPERATURE -20°C to +40°C
IP RATING IP20
MATERIAL XXXX
DIMENSION XXxXX mm
WARNING
DESCRIPTION
ON / OFF FUNCTION
DIMMING (ADJUSTING BRIGHTNESS)
INSTALLATION INSTRUCTIONS
1. Please make sure to turn o the power before starting the installation.
2. Installation must be performed by a qualified electrician.
3. For indoor use only.
The product is a small controller with a capacitive sensor. It has two operating functions: on/o and dimming
(adjusting the brightness of LED lighting) within wide ranges (10%-100%).
By a single quick hand touch on the surface above the mounted sensor, the LED is turned on. By a second quick
hand touch on the same place, the LED lighting is turned o.
By a long hand-touch on the surface above the mounted sensor, the brightness of the LED lighting is increased
or decreased. By second long hand-touch, the brightness is adjusted at the opposite direction.
1. Clean the inside of the door thoroughly and install the controller here.(FIG 1)
2. Peel o the protective film from the adhesive sticker. (FIG 2)
3. Stick the dimming switch on the mounting surface(FIG 1)
4. Connect the OUTPUT connector to the load and the INPUT connector to the power
supply for te LED lights.
Note: The dimming switch is intended exclusively for LED lighting. Aer a power loss and its restoration, the
switch remains in the o position.
NOTE
• Must be installed on the reverse side of the mounting surface.
• Surface thickness ≤ 25mm.
• Not suitable for installation behind mirrors or metal surfaces as it would not function.
Thickness: Max 25mm
FIG 1 FIG 2
Inside of the door
Dimmer Touch Location
Controller
Outside of the door
