Side 1/3

In case of any query/issue with the product, please reach out to us at: support@v-tac.eu

For More products range, inquiry please contact our distributor or nearest dealers.

V-TAC EUROPE LTD. Bulgaria, Plovdiv 4000, bul.L.Karavelow 9B

MULTI-LANGUAGE

MANUAL QR CODE

Please scan the QR code to

access the manual in multiple languages.

INSTRUCTION MANUAL

MICROWAVE SENSOR

TECHNICAL DATA

MODEL VT-80301

SKU 23164

INPUT POWER AC: 220-240V, 50/60 Hz

RATED LOAD Max. 1200W

300W +LED

TIME DELAY Min. 10sec ±3sec

Max. 12min ±1min

DETECTION

RANGE 180°

DETECTION

DISTANCE 5-12m Adjustable

DETECTION

MOVING SPEED 0.6-1.5m/s

WORKING

TEMPERATURE -20°C to +40°C

POWER

CONSUMPTION Approx, 0.9W

AMBIENT LIGHT <3-2000 LUX (Adjustable)

INSTALLATION

HEIGHT 1.5-3.5m

POWER

CONSUMPTION Approx w0.9

DETECTION

MOTION SPEED 0.6-1.5 m/s

HF SYSTEM 5.8Ghz CW Radar, ISM

Band

DIMENSION 119.5x80x51.5 mm

INTRODUCTION & WARRANTY

Thank you for selecting and buying V-TAC product. V-TAC will serve you the best. Please read these instructions

carefully before starting the installation and keep this manual handy for future reference. If you have any another

query, please contact our dealer or local vendor from whom you have purchased the product. They are trained

and ready to serve you at the best. The warranty is valid for 5 years from the date of purchase. The warranty

does not apply to damage caused by incorrect installation or abnormal wear and tear. The company gives no

warranty against damage to any surface due to incorrect removal and installation of the product.

V-TAC LED

RANGE (UPTO 600W)

COMPATIBLE WITH

This marking indicates that this prod-

uct should not be disposed of with

other household wastes.

Caution, risk of electric shock.

FUNCTION

WARNING

1. Please make sure to turn o the power before starting the installation.

2. Installation must be performed by a qualiﬁed electrician.

1. Can identify day and night: It can work in the daytime and at night when it is adjusted on the

“sun” position (max). It can work in the ambient light less than 3LUX when it is adjusted on the

“3” position (min). As for the adjustment pattern, please refer to the testing pattern.

2. SENS adjustable: It can be adjusted according to using location. The detection distance of low

sensitivity could be only 5m and high sensitivity could be 15m which ﬁts for large room.

3. Time-Delay is added continually: When it receives the second induction signals within the ﬁrst

induction, it will restart to time from the moment.

4. Time–Delay is adjustable. It can be set according to the consumer’s desire. The minimum time

is 10sec±3sec. The maximum is 12min±1min.

NOTE: the high-frequency output of the HF sensor is

<0.2Mw- that is just one 5000th of the transmission

power of a mobile phone or the output of a microwave

oven, the baby can’t touch it

INSTALLATION

CONNECTION-WIRE DIAGRAM

• Loosen the screw on the bottom and unload the bottom (refer to the ﬁgure1).

• Pass the power wire through the hole with gasket in the bottom. Connect the power wire into

connection-wire column according to the connection-wire diagram.

• Fix the bottom with inﬂated screw on the selected position (refer to the ﬁgure2).

• Install back the sensor on the bottom, tighten the screw and then test it.

L (BROWN)

N (BLUE)

L (RED)

Figure 2Figure 1
