Side 1/5

1 947554

ISSUE 1

PagePro VIP-204B

SIP Paging Gateway

INTRODUCTION

The VIP-204B SIP Paging Gateway is designed

for use with virtually all IP based telephone

systems. The unit provides SIP addressable

groups and 4 analog outputs that may be

included as part of the SIP addressable groups.

The VIP-204B can control thousands of IP

speakers and/or analog speakers or provide an

interface to legacy paging systems.

Connection to a SIP server can be as individual

SIP Stations (extensions) or as a SIP trunk.

Station mode provides up to 8 SIP-addressable

groups. Trunk mode accepts up to 100 SIP

phone numbers for flexible grouping.

SPECIFICATIONS

Access Methods

 SIP

 Valcom Multicast Page Group

Features

 SIP – Addressable Groups (phone numbers)

 4 Analog Audio Outputs

 4 Programmable Form A Relay Closures

 RJ-45 for Network Connection

 Provides Audio for Valcom Analog One-Way

Self Amplified Speaker Assemblies or 25/70

Volt central amplifiers

 AUX Audio Input via RCA Jack for

Background Music Input, Music Mutes During

a Page

 Output Control Relay Closure Provided

During Paging Output

 2.5mm Jack for optional DC Power (non-

PoE)

 LED Status Indicator

 Network Activity LEDs

 Programmable Feedback Elimination/Page

Repeat

 Programmable Night Ring

Power Options

 Power over Ethernet (PoE) 802.3af, Class 3

Compatible

 Optional External Power Supply (VIP-324D)

Dimensions/Weight

1 Standard 19” Rack Unit:

 1.75” H x 16.5" W x 11.88" D

(4.45 cm x 41.9 cm x 30.18 cm)

 Weight: 4.0 lbs. (1.8 kg)

Nominal Specifications

AUX Input Impedance:

8 to 600 Ohms

AUX Input Level:

-10dBm nominal

Output Impedance:

50 Ohms

Output Level:

- 10dBm nominal

Relay Current Rating:

1 Amp @ 24VDC

Nominal Power Requirements

Via rear panel barrel connector:

Voltage:

24VDC

Current:

325mA

Via 802.3af PoE Ethernet Switch:

Class 3

Environment

Temperature:

0 to +40° C

Humidity:

0 to 85% Non-Precipitating

These products are intended for use with a UL

Listed power source marked “Class 2” or “LPS”

rated 24VDC, or 48VDC (PoE).

PoE and all interconnected ITE are intended for

intra-building.

Precautionary Designations

 WARNING-To Reduce The Risk Of Fire Or

Electric Shock. Do Not Expose This

Apparatus To Rain Or Moisture.

 AVERTISSEMENT - Afin de réduire les

risques d'incendie ou de décharge

électrique, évitez d'exposer le système à la

pluie ou à l'humidité.
