Side 1/18

SOL15/SOL16

AMORPHOUS SILICON SOLAR PANEL - 15W/40W

ZONNEPANEEL IN AMORF SILICIUM - 15 W / 40 W

PANNEAU SOLAIRE EN SILICIUM AMORPHE - 15 W / 40 W

PLACA SOLAR DE SILICIO AMORFA - 15 W / 40 W

SOLARZELLENPLATTE AUS AMORPHEM SILIZIUM - 15 W / 40 W

USER MANUAL

GEBRUIKERSHANDLEIDING

NOTICE D’EMPLOI

MANUAL DEL USUARIO

BEDIENUNGSHANDLEITUNG

SOL15/SOL16_v5 VELLEMAN 2

SOL15/SOL16 – AMORPHOUS SILICON SOLAR PANEL - 15W/40W

1. Introduction

To all residents of the European Union

Important environmental information about this product

This symbol on the device or the package indicates that disposal of the device after its lifecycle could harm the

environment. Do not dispose of the unit (or batteries) as unsorted municipal waste; it should be taken to a

specialized company for recycling. This device should be returned to your distributor or to a local recycling service.

Respect the local environmental rules.

If in doubt, contact your local waste disposal authorities.

Thank you for choosing Velleman! Please read the manual thoroughly before bringing this device into service. If the device was

damaged in transit, do not install or use it and contact your dealer. Refer to the Velleman® Service and Quality Warranty on

the last pages of this manual.

This solar module converts solar light into DC electricity, which is then leaded to rechargeable batteries. The thin-film

technology allows this module to be installed and used under cloudy conditions. Its resistant double-glass structure is strong

enough to withstand hails of up to 25mm in diameter.

2. Safety Instructions

• Damage caused by disregard of certain guidelines in this manual is not covered by the warranty and the dealer will not

accept responsibility for any ensuing defects or problems.

• Do not allow children and unauthorized persons near the solar modules.

• Do not install the solar panels where flammable gases or vapours are present.

• Handle the module with care. Carry the module with two or more persons. Wear non-slip gloves. Do not drop objects on

the surface of the module. Do not stand or step on the module.

• Do not use or install broken or damaged modules.

• Make sure the construction intended to install the modules can handle the weight of the module(s).

• Never modify or open the solar module. Do not treat the back or front with paints or adhesives.

• Only use the device for its intended purpose. All other uses may lead to short circuits, burns, electroshocks, crash, etc.

Using the device in an unauthorised way will void the warranty.

3. Installation

• Choose an installation spot which is not shaded by obstacles like buildings or trees. Pay attention to avoid partially shaded

modules.

• Mount the module at an angle for maximum sun exposure. This angle is generally the local latitude. Clearance between

the module frame and the mounting surface is required to allow cooling air to circulate around the back of the module, thus

avoiding condensation and moisture. Never seal the module to the mounting surface with sealants which prevent the air

from circulating under the module.

• Firmly fix the module at the four corners and the middl able to withstand loads such as e points so that the module will be

snow and wind. Use appropriate materials and do not drill extra holes in the module frame.

• Install according to the illustrations below.

ELECTRIC SHOCK HAZARD

Photovoltaic modules generate DC current when exposed to sunlight or other light sources. Although a

single module produces only low voltage and current, shocks and burns are still a potential hazard. The

shock hazard increases as modules are connected in series. Cover the whole front of the module with

a dense opaque material such as cardboard when installing and handling the module. Work under dry

conditions only.

Make sure you fully understand the instructions before installing the module. Contact a qualified

technician if in doubt.

Produkt Specifikationer

Mærke:	Velleman
Kategori:	Batterioplader
Model:	SOL15
Produktfarve:	Sort
Batterispænding:	12 V
Opbevaringstemperatur (T-T):	-40 - 85 °C
Driftstemperatur (T-T):	-40 - 85 °C
Dimensioner (BxDxH):	923 x 313 x 22 mm
Pakketype:	Kasse
Udgangsspænding:	17.5 V
Antal understøttede batterier:	1
Kapabilitet:	SOL/SPC1\nSOL4UCN2\nSOL7UC\nSOL30UC12V
Aktuel opladning:	850mA
Kemisk sammensætning:	amorphous silicon
Emballage:	Karton
