User's Manual

DSP-Controlled Home Theater Subwoofer

DLS

-R Series

• DLS-3500R

• DLS-3750R

• DLS-4000R

• DLS-5000R

Caution

To reduce the risk of electric shock, do not remove cover (or back). No user-serviceable parts inside. Refer servicing

to qualiﬁed service personnel.

The lighting ﬂash with arrowhead symbol is intended to alert the user to the presence of uninsulated "dangerous

voltage" within the product's enclosure that may be of sufﬁcient magnitude to constitute a risk of electric shock to

persons.

The exclamation point symbol is intended to alert the user to the presence of important operating and maintenance

(servicing) instructions in the literature accompanying the subwoofer.

1. Read Instructions -- All safety and operating instructions should be read before the subwoofer is operated.

2. Retain Instructions -- The safety and operating instructions should be retained for future reference.

3. Heed Warnings -- All warnings on the subwoofer and in the operating instructions should be adhered to.

4. Follow Instructions -- All operating and use instructions should be followed.

5. Water and Moisture -- The subwoofer should not be used near water -- for example, near a bathtub, washbowl,

kitchen sink, laundry tub, in a wet basement, near a swimming pool or the like.

6. Carts and Stands -- The subwoofer should be used only with a cart or stand recommended by the

manufacturer.

7. Wall or Ceiling Mounting -- The subwoofer should be mounted to a wall or ceiling only as recommended by

the manufacturer.

8. Ventilation -- The subwoofer should be situated so that its location or position does not interfere with its proper

ventilation. For example, the subwoofer should not be situated on a bed, sofa, rug, or similar surface that

may block the ventilation openings; or placed in a built-in installation such as a bookcase or cabinet that may

impede the ﬂow of air through the ventilation openings.

9. Heat -- The subwoofer should be situated away from heat sources such as radiators, heat registers, stoves,

or other subwoofers that produce heat.

10. Power Sources -- The subwoofer should be connected to a power supply only of the type described in the

operating instructions or as marked on the subwoofer.

11. Power-Cord Protection -- Power-supply cords should be routed so that they are not likely to be walked on or

pinched by items placed upon or against them, paying particular attention to cords at plugs, convenience

receptacles, and the point at which they exit from the subwoofer.

12. "Caution: To prevent electrical shock, match wide blade of plug to wide slot, fully inserted." "Attention: Pour

eviter les chocs electriques, introduire lame la plus large de la ﬁche dans la borne correspondante de la prise

et pousser jusqu' au fond".

13. Cleaning -- The subwoofer should be cleaned only as recommended by the manufacturer.

14. Nonuse Periods -- The power cord of the subwoofer should be unplugged from the outlet when left unused

for a long period of time.

15. Object and Liquid Entry -- Care should be taken so that objects do not fall and liquids are not spilled onto

the enclosure.

16. Damage Requiring Service -- The subwoofer should be serviced by qualiﬁed service personnel when:

a. The power-supply cord or plug has been damaged.

b. Objects have fallen or liquid has been spilled into the subwoofer.

c. The subwoofer has been exposed to rain.

d. The subwoofer does not appear to operate normally or exhibits a marked change in performance.

e. The subwoofer has been dropped or damaged.

17. Servicing -- The user should not attempt to service the subwoofer beyond what is described in the operating

instructions.

All other servicing should be referred to qualiﬁed service personnel.

NOITUAC

KCOHS CIRTCELE FO KSIR

NEPO TON OD

Congratulations!

Congratulations on your purchase of a Velodyne Distortion Limiting

System

Remote (DLS

-R) subwoofer. This system represents the

state-of-the-art in low frequency reproduction. Read and follow the

instructions below to insure safe and proper system operation.

Warning!

To prevent ﬁre or shock hazard, do not expose this equipment to rain

or moisture. To avoid electrical shock, do not open speaker enclosure

or amp chassis cover. Please observe all warnings on the equipment

itself. There are no user serviceable parts inside. Please refer all

service questions to your authorized Velodyne dealer.

Prior to Installation

Please unpack the system carefully. Remove all staples used to seal

the carton as they can scratch the cabinet. Please save the carton

and all packaging materials for future use. Record the serial number

in the space provided on the warranty card for future reference.

Product Features and Controls

• DSP-controlled

• 4 selectable presets for customized listening mode

• Night-mode setting

• Mute control

• Built-in 160 watt (RMS) power ampliﬁer (DLS-3500R)

• Built-in 185 watt (RMS) power ampliﬁer (DLS-3750R)

• Built-in 200 watt (RMS) power ampliﬁer (DLS-4000R)

• Built-in 1000 watt (RMS) power ampliﬁer (DLS-5000R)

• Adjustable (40 to 120 Hz) low-pass crossover with Subwoofer

Direct setting

• Speaker-level inputs and outputs

• 85 Hz high-pass crossover

• Line-level inputs

• Signal sensing auto turn on/off with bypass option

• Variable volume control

• Selectable phase control (0, 90, 180, or 270 degrees)

• Dual staggered low-pass crossover; 12 dB/octave initial,

24 dB/octave ultimate

• Anti-clipping circuit

• Over excursion protection

• Slot loaded design

Installation

Your new subwoofer system provides for a number of installation

options. Read all the installation information below in order

to determine which installation option is best for your system.

Remember to perform all installation procedures with system power

turned off.

Figure 1. DLS-3500R, DLS-3750R and DLS-4000R

Rear Panel Connections
