Side 1/22

- 29 -

User Manual ADR-out Network Analyser

English

Contents

■Safety warnings Page 30

■Technical specifications Page 30

■Description of instrument Page 31

■Keys Page 32

■Setting the parameters Page 32

■Displaying the measurement pages Page 39

■Measurement and calculation method Page 49

■Reference standards Page 50

■ADR-R out dimensions and connection diagrams Page 24-25

■ADR-D out dimensions and connection diagrams Page 26-27

- 30 -

User Manual ADR-out Network Analyser

English

■During the installation and operation of the instrument, the following

should be noted:

1) The instrument should be installed by a competent person

2) Follow the connection diagrams to the letter when installing the

instrument

3) When connecting the instrument, always use the TA x/5 A

4) The appliance should be installed in a panel where the terminals will be

inaccessible after installation

5) The voltage and current circuit terminals may be connected with a

maximum rated voltage of 300 V eff. with respect to earth

6) The panel should be wired in line with the relevant CEI standards

7) Do not power or connect the instrument if any part of it is damaged

■NOTE:

• The VEMER network analysers are designed for use in environments with

over-voltage category III and pollution level 2, in accordance with the

CEI-EN 61010-I standard.

• The electrical system of the building where the instrument is to be

installed should contain a switch or isolator. This should be close to the

instrument and within easy reach of an operator.

An over-current protection device should be fitted.

Important: when the power supply is cut off, there should be no signal

at the measurement inputs (current or voltage).

• Power supply: 230 VAC (-15%/+10%)

• Frequency: 50/60 Hz

• Maximum consumption: 5 VA

• Display: rear-lit LCD

• Voltmeter inputs: max 500 VAC, 47÷63Hz (phase-phase concatenated)

• Ammeter inputs: max 6 A, 47÷63 Hz

• Scales: 1 voltage with end of scale 500 V (phase-phase concatenated)

2 current with end of scale at 1.25 A and 6 A

• Precision:

- Voltage: 0.5% of the end of scale value (min 10 V)

- Current: 0,5% of the end of scale value (min. 20 mA)

- Power: 1% of the end of scale value

TECHNICAL SPECIFICATIONS

SAFETY WARNINGS
