Model EHM-H11
Capacity 380mI
≥1500ppb
3min/10min
5~60℃
Food-grade material (BPA free)
Pyrex glass
Type-C
Hydrogen content
Electrolyzation time
Input water temperature
Lid & base material
Bottle body material
Charging port
3000mAhBattery capacity
5V/1AInput voltage
φ73*214mmProduct size
How To Operate：
Quick Start Guide：
1. Firstly, separate the lid and glass bottle from the hydrogen
generator base. Wash the lid and glass bottle with warm
water and a soft cloth. DO NO wash the hydrogen generator
base.
2. Unscrew plastic cover from the electrode plate.
3. Install the glass bottle on the hydrogen generator base. Fix it
tight to avoid leakage.
4. Filling water up with drinking water (the water level should
not exceed the upper part of the cup glass body to avoid
overflow.)
Press the ON/OFF button at the bottom of the base to start
making hydrogen water.
5. In order to keep the ion exchange membrane moist, some
bacteriostatic water will be stored in the electrode chamber.
After cleaning the cup, please continuously electrolyze 3
cups of water and discharge before drinking.
6. If the bacteriostatic water in the electrode chamber
become dry, before using, please add some hot water and
keep it standing for 2 hours, to moisten and re-activate the
ion exchange membrane.
1. Press power button at the bottom. The bottle working
indicator light will turn blue and start making hydrogen-rich
water for 3 minutes by default. Pressing the power button for
twice quickly, the bottle will turn the working mode to be 10
minutes.
During working, you can press the power button to turn it off.
2. After working for 3 / 10 minutes, the working indicator light will
turn off automatically. For higher concentration of H2, please
choose the 10 minutes working mode.
3. As hydrogen is very unstable and will disappear over time, it
is the best to drinking the hydrogen water as soon as it is
produced.
The Most Innovative Technology：
Product Overview：
Hydrogen Water Bottle
Bottle
Power button
Exhuast vent
1.DO not block the vent
2.Occasional water
Drainage is normal
SPE/PEM electrode
Type-C charging
port
Plastic cover
(protect the electrode plate)
Lid
H2
O2
SPE Technology
H2
≥1500+ ppb Self-cleaning Function
3000mAh Battery Multi-mode Using
Ti＋Pt
Titanium &
Platinum Electrodes
Cl2 O3
0 Chlorine &
Ozone Residue
01 02 03
