INSTRUCTIONS FOR USE
3. SCOPE OF USE
The collector is designed to remove unwanted
debris, leaves, twigs, etc. according to the
instructions in this manual.
The collector is mounted after a ride-on lawn
mower or garden tractor and rotating brushes
efficiently collect loose material from the lawn
tan to the collector.
4. EVERYONE CONDITION
When working with collectors and towing
vehicles, the following points should always
be taken into account:
4.1 Arbitrary area
• Do not work in the dark or poor lighting.
• Keep children and unauthorised persons
outside the work of the Council.
4.2 Personal security
• Always read the manual before use.
• The collector must not be used without reading
the safety regulations and maintenance instructions.
• Pay special attention to the towing net warning
symbols and only use the collector in conjunction
with vehicles where driving experience already exists.
• Children and persons with reduced physical
or mental ability may not use the collector.
• It is not allowed to sit on the collector.
• Always attach the rope to the bag of the towing
vehicle so that it does not get stuck in wheels
or other rotating parts. Never hold the rope while
the ship is in operation.
• Drive slowly on difficult terrain, ditches and slopes
to avoid the risk of overturning with the vehicle.
• Maximum speed: 10 km/h.
• This product is not intended for use on public land.
• The stability of product use may be affected by
factors such as weight, Please check before use.
5. ASSEMBLE
Component diagram:
8. UNFOLDED DIAGRAM
Number
1
2
3
4
5
6
7
8
9
10
11
12
13
14
Quantity
1
1
1
1
1
1
2
2
2
1
2
2
1
1
Component Name
Left drag arm
Right drag arm
Traction device
Lock tray
Brush trolley
Viper tube
Upper sachet frame
Lower sachet frame
Bag frame
Bag rear frame
Support rod
Rope
Netframe
Connection Bar
5.1 Mounting
Tools needed at installation: Wrench, pliers
Open the package and check that the above details are included.
NOTE: "Right" and "Left" start from the brush car seen from the front.
Use 2 bolt M6X15 (T) to pass through brush trolley (6) and the holes corresponding
to the two sides of the connection bar (15), and use the locknut M6 (U) at the end.
(PICTURE 1)
Use a bolt M8x16 (t) to pass through the brush trolley (6) and the corresponding
holes corresponding to bending corner iron (s), and fix the locknut M8 (i) and flat
pad (H) at the end. (PICTURE 2)
Use 4 bolt M8x40 (C) to pass through the brush trolley (6) sides of the left drag
arm (1) and right drag arm (2), and use flange nut M8 (J) at the end. (PICTURE 3)
PICTURE 3
PICTURE 4
Using 2 bolts M8x40 (C), thread them longitudinally through the corresponding
holes on Joystick (5) and brush Trolley (6), and secure them at the end using
flange nut M8 (J). (PICTURE 5)
Use 1 bolt M8x16 (B), pass through the flat pad (H) and thick flat pad (G), as well
as the corresponding holes on lock tray (4) and bending corner iron (S), and fix at
the end with locknut M8 (I). (PICTURE 6)
PICTURE 5
PICTURE 6
PICTURE 7
Using one bolt M8x16 (B), thread it through the corresponding holes on the
joystick (5), flat pad (H), and lock tray (4), and secure it at the end using a hanging
nut (K). (PICTURE 7)
Using two sales axes with a diameter of 8x40 (N), thread them through the
corresponding holes on the left drag arm (1) and right drag arm (2) and Viper
tube (7), and connect them at the end using R-type sales with a diameter of 2 (P).
(PICTURE 8)
Rotate the two bag rear frames (11) so that the middle hole points downwards.
Thread the bag rear frame (11) through the loop sewn on the top inside of the
netframe (14). (PICTURE 9)
Using 2 sales axes φ 6x30 (M), pass through the corresponding holes on the bag
rear frame (11) and upper sachet frame (9) respectively, and use R type sales at
the end φ Connect 2 (P). (PICTURE 10)
5.2 Collection bag assembly
PICTURE 9
PICTURE 10
Using 2 sales axes φ 6x30 (M), pass through the corresponding holes on the bag
rear frame (11) and the lower sachet frame (8), and use R type sales at the end
φ Connect 2 (P). (PICTURE 11)
Using 2 sales axes φ 10x20 (M), pass through the corresponding holes on the
upper sachet frame (8) and the lower sachet frame (9), and use R type sales at
the end φ Connect 2 (P). (PICTURE 12)
PICTURE 11
PICTURE 12
Install the bag frame (10) along the dotted line into the netframe (14) and proceed
to the next assembly step. (PICTURE 13)
Thread the bag frame (10) into the netframe (14) using two sales axes with a
diameter of 6x30 (M), passing through the corresponding holes on the bag frame
(10) and upper save frame (8), and connect them at the end using R type sales
axeswith a diameter of 2 (P). (PICTURE 14)
PICTURE 13
PICTURE 14
Insert two support rods (12) into the corresponding holes on the inside of the bag
rear frame (11). Implement support for netframe (14). (PICTURE 15)
Please press the button in netframe (14) to the corresponding position on the
bottom panel to secure it. (PICTURE 16)
PICTURE 15
PICTURE 16
Using 2 Sales axes φ 10x70 (O), pass through the upper sachet frame (8) from
both sides, add 2 plastic rings (Q) at intervals, and pass through the corresponding
holes on the Viper tube (7). Use R type sales at the end φ Connect 2 (P).
(PICTURE 17)
PICTURE 18
6. WARNING SYMBOLS
The warning symbols draw attention to some
But not all possible dangers. Pay attention to the
warnings and also take general accident
prevention measures.
Pay special attention to the towing vehicle symbols
and follow them carefully.
General danger.
Read the instructions for use
before use.
Keep spectators at a safe distance
from the machine.
Always close the engine of the drive vehicle before setting up, cleaning or
performing any maintenance or leaving the mask unattended.
Using two sales axes with a diameter of 8x40 (N), thread them through the
corresponding holes on the left drag arm (1) and right drag arm (2) and viper tube
(7), and connect them at the end using R-type sales with a diameter of 2 (P).
(PICTURE 19)
7. HANDLING
7.1 Preparation for take-off
• Make sure the brushes reach the grass. See
Figures 4 and 5 for connection height adjustments.
• Make sure the work area is cleared of stone and
foreign objects.
• Check that all bolts and nuts are well tightened
before each use.
• Check that all parts, especially the moving ones,
are intact and are correctly assembled.
7.2 Use
• Always start at the lowest gear with low speed
and then increase the speed gradually.
• Drive slowly on difficult terrain, ditches and slopes
to avoid the risk of overturning the vehicle.
• Maximum speed: 10 km/h.
• The collector is designed to collect leaves, grass
and branches and not heavier objects such as
stones or metal objects.
• Always attach the rope to the bag of the towing
vehicle so that it does not get stuck in wheels or
other rotating parts. Never hold the rope while
the ship is in operation.
• The bag is easily emptied by pulling the rope from
the front. The bag should be emptied before it's
overflowing.
• Always turn off the engine of the towing vehicle
before any adjustments are made to the collecting
clean.
• Prevent accidental start-up by disconnecting
power before service and repair or when the
machine is not in use.
• Never leave the collector unattended when the
tractor engine is running.
• The braking capacity and stability of the towing
vehicle may be affected by the weight of the
collector. Do not fill the collector completely
without checking the driving characteristics of the
towing vehicle are not activated. Pay attention to
this. Avoid steep slopes.
• Stop and check the collector and towing vehicle
if an object has been on-run. Fix any damage
before resuming work.
• Beware of fire. Be aware that in dry conditions
the contents of the bag may self-ignite.
• This product is not intended for use on public
roads or streets. Observe for visibility when
working near busy roads.
• Only use the product for its intended use.
7.3 Care
• To avoid self-ignition, always empty the bag
before storing the collector.
• Replace the bag in case of damage or wear.
An ingress bag can lead to accidents.
• Clean the collector after use and service it
regularly.
• Lubricate wheels and moving parts if necessary.
• Store in a dry place when not in use.
WARNING!
• All users should always read this and the
tractor's manuals before starting.
• Do not let anyone use the collector without
first having received instructions in hand.
• Children and persons with reduced physical
or mental ability may not use the collector.
• Use eye protection when using the collector.
• Avoid driving or placing the collector next to
a fire, it may start to burn.
• Never touch brushes or axle when the
vehicle is in motion and the brushes rotate.
Do not exceed the maximum capacity of the
collector, 0.34 m3.
• Drive slowly on difficult terrain, ditches and
slopes to avoid the risk of overturning with
the vehicle. Pay attention to pits and other
dangers.
• This product is not intended for use on
public roads or streets. Observe for visibility
when working near busy roads.
• All bolts and nuts must be tightened for safe
operation.
• Stop and check the collector and towing
vehicle if an object has been on-run. Fix
any damage before resuming work.
• Follow the instructions in the associated
manual.
OBS!
OUTLINE
1. INTRODUCTION
2. TECHNICAL DATA
3. SCOPE OF USE
4. EVERYONE
5. ASSEMBLE
6. WARNING SYMBOLS
7. HANDLING
8. UNFOLDED DIAGRAM
1. INTRODUCTION
This manual contains important information about
the product’s use and safety risks, etc. All users
are encouraged to read the manual before use
and pay particular attention to the following
warnings:
2. TECHNICAL DATA
Model: TC5001B
Cleaning width: 42 inches
Number of brushes: 4
Hopper capacity: 12. cu. ft
Net weight: 28.9kg +
-
% (including all accessories)
Gross weight: 32.5kg Tolerance: +
-
%
(including all accessories and packaging materials)
Material: Q235A Q235 high-strength PP
J700 PVC+polyester fiber PA66+rubber
Risk of serious accident. All electrical and
motorized equipment can cause damage in
case of improper handling.
Risk of minor personal injury or machine damage.
We reserve the right that the illustratio down and
descriptions of individual details do not always
correspond fully with the product.
Keep the manual in a safe place connected to
the machine and in case of any sale, the manual
should accompany the machine.
WARNING!
3
4
3
4
7
8
11
7
8
9
10
5
6
5
6
1
2
1
2
PICTURE 1
PICTURE 2
Use 2 bolt M8x65 (E), passing through the side of the Traction device (3) and the
corresponding empty space in the front of the Left drag arm (1) and right drag
arm (2), is fixed at the end using flange nut M8 (J).
We continue to be committed to provide you tools with competitive price.
"Save Half", "Half Price" or any other similar expressions used by us only represents an
estimate of savings you might benefit from buying certain tools with us compared to the
major top brands and does not necessarily mean to cover all categories of tools offered
by us. You are kindly reminded to verify carefully when you are placing an order with us if
you are actually saving half in comparison with the top major brands.
USER MANUAL
LAWN SWEEPERS
LAWN SWEEPERS
Tie rope (13) to the middle position of the upper frame component behind
netframe (14). Use the original bandage buckle of Netframe (14) to bypass the
bag real frame (11), and tighten and fix Netframe (14) to the bag real frame (11).
(PICTURE 18)
11
12
8
8
9
10
9
1
3
2
4
5
7
7
6
11
13
14
PICTURE 19
PICTURE 17
PICTURE 8
TechnicalSupport and E-Warranty Certificate www.vevor.com/support
TC5001B
- 3 -
- 14 -
How to connect with the towing vehicle
The towbar of the lawn sweepers should be kept level with the ground during
the connection.
The following 6 lawn sweepers can be installed at different heights of the
tow tractor's attachment position.
- 15 -
Lawn sweepers height adjustment
Release the knob to adjust the height of the brush by adjusting the handle.
Note: After the brush height is confirmed, the knob should be tightened to
prevent loosening.
It is recommended that the contact depth between the brush and the
grass is 1/2 inch.
- 13 -
12
The assembly is complete.
Option 1 Option 2 Option 3
Option 4 Option 5 Option 6
Kept level with the ground
1/2inch(13mm)
Adjust the handle
Note:Components such as screws
and latches are pre-installed on the
above components.
The hexagon screw head
needs to be sunk into the
hexagonal hole.
E-CrossStu GmbH
Mainzer Landstr.69, 60329 Frankfurt am Main.
YH CONSULTING LIMITED.
C/O YH Consulting Limited Oce 147, Centurion House,
London Road, Staines-upon-Thames, Surrey, TW18 4AX
Manufacturer: Shanghaimuxinmuyeyouxiangongsi
Address: Shuangchenglu 803nong11hao1602A-1609shi, baoshanqu, shanghai 200000 CN.
Imported to AUS: SIHAO PTY LTD. 1 ROKEVA STREETEASTWOOD NSW 2122 Australia
Imported to USA: Sanven Technology Ltd. Suite 250, 9166 Anaheim Place, Rancho Cucamonga, CA 91730
