Instruction Manual for

R200SS

Optical Tube Unit

Attaching the Telescope Tube to the Mount

Loosen both the dovetail tube-plate lock screw and safety screw until the tips of these screws no longer

extended into the inner part of the dovetail block. Slide the dovetail mounted scope into the dovetail

mounting block as shown in the figure. ighten the dovetail lock screw (centered on the notch) onto the T

dovetail tube plate until snug. Then tighten the small chrome safety screw onto the dovetail mounting

block until snug.

Attaching the Finder Scope

Loosen the finder bracket lock screw

on the telescope's finder bracket shoe.

Attach the 7x50 finder scope as shown

in the figure and tighten the finder

bracket lock screw securely.

The basic operations of the telescope

such as balancing the telescope and

adjusting the finder scope are described

in the instruction manuals for the Vixen

Equatorial Mount.

PREFACE

Thank you for your purchase of a Vixen astronomical telescope.

This manual applies to the R200SS telescope. You may occasionally find descriptions in the text not relevant to your particular

model. Read the instructions for your mount along with this manual if you purchased the telescope as a complete package.

CAUTION

Do not leave the optical tube uncapped in the daytime. Sunlight passing through the telescope or finder scope may cause a fire.

Do not use the product while moving or walking, injuries could result from a collision with objects or from stumbling or falling.

Keep small caps, plastic bags, or plastic packing materials away from children.

These may cause a danger of swallowing or suffocation.

Do not use the product in a wet environment and do not handle with wet hands.

Do not leave the product inside a car in bright sunshine, or in other hot places. Keep any strong heat sources away from the product.

When cleaning, do not use organic solvents such as paint thinner or similar products.

Do not expose the product to rain, water drops, dirt or sand.

Avoid touching any lens or mirror surfaces directly with your hands. In case a lens or mirror becomes dirty with fingerprints or general

smears, gently wipe it using a commercially available lens cleaner and a lens cleaning paper or cloth, or consult your local Vixen dealer.

Blow off dust on lenses using a commercially available blower brush.

For storage, keep the product in a dry place and do not expose to direct sunlight.

HANDLING AND STORAGE

WARNING!

Never look directly at the sun with the telescope or its finder scope or eyepiece.

Permanent and irreversible eye damage may result.

SETTING UP THE TELESCOPE

Refer to your mount instructions along with this manual.

(SXW mount and R200SS optical tube shown here.)

7x50 Finder Scope

with illuminator

Finder Bracket

Adjustment Screw

Optical ubeT

Finder Bracket Setscrew

Finder Bracket Shoe

Focus Knob

Tube Ring

Dovetail ube PlateT

Safety Screw

Dovetail Plate Lock Screw

(T his pa rt may be o pti ona l a t y ou r p art icu lar mode l.)

(This part may be optional at your particular model.)
